Smoke & CO Alarm
Models: SMAZB-141, SMAZB-143, SCAZB-141, SCAZB-143
INSTALLATION MANUAL
Table of contents
......................................................................................................................................................................... 1
Type. ........................................................................................................................................................................ 1
.................................................................................................................................................................... 1
You should know about carbon monoxide
.................................................................................................................... 2
........................................................................................................................................... 4
............................................................................................................................................................................... 4
............................................................................................................................................. 5
.................................................................................................................................................... 5
................................................................................................................ 5
......................................................................................................................................... 5
......................................................................................................................................... 6
................................................................................................................................................................. 6
....................................................................................................................................................................... 6
................................................................................................................................................................ 6
Version 1.0
............................................................................................ 2
..................................................................... 2
............................................................................................ 2
.............................................................................................. 2
.......................................................................................................... 3
........................................................................ 5
Introduction
The electrochemical Carbon Monoxide / Photoelectric smoke detector is
effective for detecting any buildup of carbon monoxide and smoke, in your home
or office. The features of your detector as below:
• Easy to install.
• Monitoring for carbon monoxide in a continuous manner.
(Note: This feature is only available on models SCAZB-141 and SCAZB-143)
• Monitoring for smoke in a continuous manner.
• Giving a loud alarm (85 dB)
• Having a Test button for you to test the alarm anytime.
• Self-diagnostic testing its operative function continuously.
• Five-year life type
(Note: This feature is only available for models SMAZB-143 and SCAZB-143)
SMAZB-143 and SCAZB-143 Five-year life type employing a
WARNING:
non-replaceable battery and activate power by installed bracket.
Model Type
Model
Detection type
Power source
Replaceable battery autonomy At least : Two years
End of life
Model
Detection type
Power source
Replaceable battery autonomy At least : Five years
End of life
Model
Detection type
Power source
Replaceable battery autonomy At least : Two years
End of life
Model
Detection type
Power source
Replaceable battery autonomy At least : Five years
End of life
Product view
FRONT
Alarm sounder
1
SMAZB-141
Smoke
Panasonic CR123A or Duracell DL123A
3V lithium battery (Replaceable)
Ten years
SMAZB-143
Smoke
Panasonic CR123A or Duracell DL123A
3V lithium battery (Replaceable)
Energizer L91
L91 lithium battery (NOT replaceable)
Ten years
SCAZB-141
CO & Smoke
Panasonic CR123A or Duracell DL123A
3V lithium battery (Replaceable)
Ten years
SCAZB-143
CO & Smoke
Panasonic CR123A or Duracell DL123A
3V lithium battery (Replaceable)
Energizer L91
L91 lithium battery (NOT replaceable)
Ten years
Test / Silence button
LED indicator
