OWNER'S/OPERATOR'S
MANUAL
SXS300
Designed and manufactured
for OFF-ROAD use only!
For age of 16 and up
only to operate!
CHEETAH 150 | CHEETAH 150X | CHEETAH 200 | CHEETAH 200X
CHEETAH 200-E | CHEETAH 200E-X | CHEETAH 300-E
CHEETAH 300E-X | CHEETAH 300 | CHEETAH 300X
Provincial/Municipal governments have different regulations pertaining to owning and
operating an off-road vehicle, learn the regulations in your area.
This operation manual is made for UTV models:
READ THIS MANUAL CAREFULLY!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SXS300 and is the answer not in the manual?

Questions and answers

Related Manuals for Thumpstar SXS300

Summary of Contents for Thumpstar SXS300

  • Page 1 OWNER’S/OPERATOR’S MANUAL SXS300 Designed and manufactured for OFF-ROAD use only! For age of 16 and up only to operate! This operation manual is made for UTV models: CHEETAH 150 | CHEETAH 150X | CHEETAH 200 | CHEETAH 200X CHEETAH 200-E | CHEETAH 200E-X | CHEETAH 300-E...

  • Page 2: Table Of Contents

    Welcome Introduction Content WELCOME INTRODUCTION Thank you for purchasing our Products. We hope you will enjoy it. Before you start to operate the BUYERS SAFETY AGREEMENT vehicle, please read through this owner’s manual IMPORTANT MANUAL INFORMATION carefully as it contains important safety and maintenance information.

  • Page 3: Buyers Safety Agreement

    Buyers Safety Agreement Buyers Safety Agreement (1/2) (2/2) Always be careful when skidding or sliding. On extremely slippery surfaces such Always read the owner’s manual carefully before riding and follow the operating as ice, go slow and be very cautious in order to reduce the chance of skidding procedures described in the owner’s manual.

  • Page 4: Important Manual Information

    Important Manual Information Location of Warning Stickers Read and understand all of the labels on your vehicle. They contain important NOTE: information for safe and proper of your vehicle. Never remove any labels from The operator, passenger, parents or guardian must read, study and understand your vehicle.
  • Page 5 Location of Warning Stickers Safety Information This off-highway utility vehicle handles differently from other vehicles including cars and ATVs. Where INJURY OR DEATH can result if you do not follow these instructions: Read this manual and labels carefully and follow the operating procedures described.

  • Page 6: Safety Information

    Safety Information Description and Always go slowly and be extra careful when operating on unfamiliar terrain. Always be alert to changing terrain conditions when driving the vehicle. Never operate on excessively rough, slippery, or loose terrain until you have learned and practiced the skills necessary to control the vehicle on such terrain. Always be especially cautious on these kinds of terrain.
  • Page 7 Description and Description and 17. Head Cover 26. R-Washer 35. Steering Wheel 44. Steering Gear Adjusting Bolt 18. Front Panel 27. Locking Nut M8 36. Steering Bolt Cover 45. Parking Brake Lever Assy 19. Head Lamps Shade Decoration, 28. Ceiling Bracket 37.
  • Page 8 Control Functions Control Functions MAIN SWITCH Functions of respective switch position are as follows: CONTROL PANEL 1. Headlight switch (High/Low Beam) OFF: 2. Turning Light switch All electrical circuits are switch off. The key can be removed in this position. 3.

  • Page 9: Control Functions

    Control Functions Control Functions PARKING BRAKE LEVER The parking brake lever is located in between the driver seat and passenger seat.. It will help hold the vehicle from moving while parked. To set the parking brake, press the release button and pull up on the lever. To release the parking brake, press the (for reference only, seat belt feature may vary) release button and release the lever.
  • Page 10 Control Functions Pre-Operating Checks Before using this Vehicle, check the following Items: ITEM ROUTINE Check operation, free play, fluid level Brakes and fluid leakage. Fill with DOT 4 brake fluid if necessary. Check for proper operation, condition Parking Brake and free play. Check fuel level.

  • Page 11: Pre-Operating Checks

    Pre-Operating Checks Pre-Operating Checks BRAKE PEDAL FUEL Check for correct brake pedal free play. If the brake pedal free play is incorrect, Make sure there is sufficient gasoline in the tank. have a dealer adjust it. Check the operation of the brake pedal. It should move smoothly and three should be a firm feeling when the brake is applied.

  • Page 12: Operation

    Pre-Operating Checks Operation ! WARNING SEAT BELTS Make sure that both seat belts are not frayed or damaged. POTENTIAL HAZARD: Operating vehicle without being familiar with all controls The seat belt must move smoothly when pulled out and retract on its own when released.
  • Page 13 Operation Operation ! WARNING WARMING UP To get the maximum engine life, always warm up the engine before starting off. POTENTIAL HAZARD: Never accelerate hard with a cold engine! To see whether or not the engine is Improperly operating in reverse. warm, check if it responds to the throttle normally with the starter (choke) turned off.

  • Page 14: Driving Your Vehicle

    Driving your Vehicle Operation GETTING TO KNOW YOUR VEHICLE GOING DOWN HILL This off-highway utility vehicle will handle and maneuver differently from an Check the terrain carefully before going down a hill. When possible, choose a ordinary passenger car or other vehicle. path that lets you drive your vehicle straight downhill.
  • Page 15 Periodic Maintenance and Adjustment Periodic inspection, adjustment and lubrication will keep your vehicle in the safest and most efficient condition possible. Safety is an obligation of the 150/200 Periodic Maintenance / Lubrication vehicle owner. The most important points of vehicle inspection, adjustment and lubrication are explained on the following pages.
  • Page 16 Periodic Maintenance and Adjustment INITIAL EVERY Month Whichever 300 Periodic Maintenance / Lubrication ITEM ROUTINE 1200 2400 2400 4800 Comes First (MI) (200) (750) (1500) (1500) (3000) Hours I: Inspection, including check, clean, lubricate, refuel, repair or replacing if necessary. A: Inspection, adjusting if necessary C: Cleanin R: Replacing...

  • Page 17: Periodic Maintenance And Adjustment

    Periodic Maintenance and Adjustment Periodic Maintenance and Adjustment ENGINE OIL AND OIL FILTER CARTRIDGE SERVICE SPARK PLUG The Engine oil level should be checked before each operation. In addition, the oil 1. Remove the spark plug and inspect it each time must be changed and oil filter cartridge replaced at the intervals specified in the you change the oil.
  • Page 18 Periodic Maintenance and Adjustment Periodic Maintenance and Adjustment SERVICE AIR FILTER FRONT WHEEL REPLACEMENT Service air filter every 20 hours of use Do not disassemble the castle nuts when you 1. Remove cleaner cover by removing the Phillips replace the front wheels. head screws 2.

  • Page 19: Troubleshooting

    Periodic Maintenance and Adjustment Troubleshooting SERVICE BRAKE FLUID LEVEL Although vehicles receive a rigid inspection before shipment from the factory, Insufficient brake fluid may let air enter the trouble may occur during operation. Any problem in the fuel, compression, or brake system, possibly causing the brakes ignition system can cause poor starting and loss of power.

  • Page 20: Cleaning And Storage

    Cleaning and Storage Cleaning and Storage A. CLEANING B. STORAGE Frequent, thorough cleaning of your vehicle will not only enhance its appearance Long term storage (60 days or more) of your vehicle will require some preventive but will improve its general performance and extend the useful life of many procedures to guard against deterioration.
  • Page 21 ENGINE (300CC) DIMENSIONS Type Single cylinder, water & cooled, 4 stroke CHEETAH CHEETAH 150 150X CHEETAH CHEETAH Type CHEETAH Engine Displacement 275.6cc CHEETAH 300/300E 300X/300EX 200/200E 200X/200EX Bore x Stroke 72.5*66.8 Overall length 2340mm 2340mm 2340mm 2340mm Carburetor/ECU Y28V1L / HZE-C-15 Overall width 1400mm 1400mm...
  • Page 22 Spare Part Catalogue Spare Part Catalogue 1. FRAME COMP CODE NAME 57100-K7 FRAME COMP.(R.S.B)  57870805512505 BOLT M8X55 ,GB5787 61870800012505 LOCKING NUT M8， GB6187 8010047250G000 R- WASHER 58430-K5 C.B.C.CUSTOM J-BAR.LSIDE(R.S.B) 7010016250G000 TUBE SEAT φ32 58410-K5 C.B.C.CUSTOM CROSS BARTOP.FR(R.S.B) 7010017250G000 TUBE SEAT φ25 Rear Decora�ve Pole （...
  • Page 23 Spare Part Catalogue Spare Part Catalogue...
  • Page 24 Spare Part Catalogue Spare Part Catalogue...
  • Page 25 Spare Part Catalogue Spare Part Catalogue...

  • Page 26: Spare Part Catalogue

    Spare Part Catalogue 1. FRAME COMP CODE NAME 27-1 14210-K7 27-2 61870800012505 NUT M8 ,GB6187 27-3 7020005250G000 250 Fuel Tank Rubber Mount 27-4 5800400300K000 Fuel Tank Collar 27-5 57890603010005 BOLT M6X30 ,GB5789 27-6 14012-K7 27-7 14011-K7 27-8 7.090.044 TUBE CLAMP φ16-25 27-9 14004-K7 Water Pipe (Iron)
