LOCATION VALUE
D1 1N4148
D2 1N4148
D3 1N4148
D4 1N4148
D5 1N4148
D6 1N4148
D100 1N5817
IC1 JRC4580
IC2 JRC4580
BASS B1M
TREBLE B25K
PRESENCE B50K
VOLUME A100K
DRIVE B100K
VOICE DPDT
GAIN SPDT
Voice toggle switch must be Type-2 DPDT ON/ON/ON
STOMPBOXPARTS.COM (Long Bat)
https://stompboxparts.com/switches/dpdt-toggle-switch-on-on-on-solder-lug-long-bat/
STOMPBOXPARTS.COM (Short Bat)
https://stompboxparts.com/switches/dpdt-toggle-switch-on-on-on-solder-lug-short-bat/
100-DP6-T100B1M1QE (Long Bat)
https://lovemyswitches.com/taiway-dpdt-on-on-on-switch-solder-lug-long-shaft/
100-DP6-T200B1M1QE (Short Bat)
https://lovemyswitches.com/taiway-dpdt-on-on-on-switch-solder-lug-short-shaft/
1MD6T1B1C0M1QE (Long Bat)
http://smallbear-electronics.mybigcommerce.com/dpdt-on-on-on-solder-term/
Parthenon Overdrive
Parthenon Overdrive

Parts List (Page 2 of 2)

TYPE
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Schottky diode, DO-41
Dual op-amp, DIP8
Dual op-amp, DIP8
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Toggle switch, DPDT *** Type-2
Toggle switch, SPDT
