PedalPCB Covert Overdrive Wiring Diagram page 3

LOCATION VALUE
D100 1N5817
Q1 MPF4393
Q2 MPF4393
Q3 MPF4393
Q4 MPF4393
Q5 MPF4393
TREB B250K
MID B25K
BASS A1M
VOL B250K
PREAMP A1M
PRES 10K
SW1 4PDT
Covert Overdrive
Covert Overdrive
Parts List (Page 2 of 2)
TYPE
Schottky diode, DO-41
JFET transistor, N-channel
JFET transistor, N-channel
JFET transistor, N-channel
JFET transistor, N-channel
JFET transistor, N-channel
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Trim potentiometer, 10K
Toggle switch, 4PDT
Copyright © 2021 - PedalPCB.com
NOTES
*Alternate SMD - MMBF4393
*Alternate SMD - MMBF4393
*Alternate SMD - MMBF4393
*Alternate SMD - MMBF4393
*Alternate SMD - MMBF4393
3362P-style
4PDT (ON/ON)
Page 3 of 6
