Stop Woofer DBC-SW-DC638 Manual

Dog bark collar
Hide thumbs Also See for DBC-SW-DC638:

Advertisement

Quick Links

Download this manual
Stop W oofer Dog Bark Collar
Thank you for purchasing the
StopWoofer Bark Collar
The product has been specifically
designed for dogs and their owners
Dear dog lovers, our company and its employees
love pets and don't want to do any harm to them.
That's why in our bark correction collars only
humane ways of influence such as sound warning
and vibration are used.
Based on testing different models of the
StopWoofer it achieves efficiency of 75-80%
with the dogs that stopped barking within
one week, 10-15% of dogs need up to two
Manual
DBC-SW-DC638

Advertisement

loading
Need help?

Need help?

Do you have a question about the DBC-SW-DC638 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stop Woofer DBC-SW-DC638

Summary of Contents for Stop Woofer DBC-SW-DC638

  • Page 1 Manual Stop W oofer Dog Bark Collar DBC-SW-DC638 Thank you for purchasing the StopWoofer Bark Collar The product has been specifically designed for dogs and their owners Dear dog lovers, our company and its employees love pets and don’t want to do any harm to them.

  • Page 2: Basic Concepts

    weeks and about 5% of dogs need more time. Unfortunately, 3-5% of dogs aren’t susceptible to bark correction though exposure to sound and vibration. IMPORTANT! In case our product didn’t help you to solve the problem with the excessive barking, please feel free to contact our support team support@stopwoofer.com and we will help you or reimburse the...
  • Page 3 Digits from 1 to 7 are displayed when you tune the sensitivity level, where 1 - is the minimum level of the sensitivity, 7 - is the maximum level of the sensitivity. While making the settings in the sensitivity mode the red icon is on the display.
  • Page 4 The latest technology of the processor protects the collar from false detection. Vibration contact points — contacts installed on the collar through which the dog receives the vibration impact. Silicone contact point guards — are an addition to vibration contact points. They can help to reduce chafing of your dog’s skin from direct contact with the vibration contact points.
  • Page 5 EQUIPMENT the STOPWOOFER bark collar with an adjustable strap 2 pairs of silicone contact point guards USB cable Testing device LifeTime Warranty User manual Package box...

  • Page 6: Technical Characteristics

    TECHNICAL CHARACTERISTICS It works in two modes “Vibration” and “Vibration+Sound” 7 levels of sensitivity 7 levels of bark correction in the mode “Vibration” 7 levels of bark correction in the mode “Vibration+Sound” It is suitable for dogs ranging in size from 6-110 lbs An adjustable strap from 5,9 to 21,65 inches...

  • Page 7: Working Principle

    WORKING PRINCIPLE The main element of the StopWoofer bark collar is the sensor. It recognizes and detects throat vibration (barking) of your dog. The sensor detects barking and the collar gets activated and influences the dog with a vibration or vibration & sound warning depending on the selected mode of the bark collar.
  • Page 8 IMPORTANT! The impact of the collar on each dog can vary as each dog has a different level of sensitivity to the impact, and it also depends on the sensitivity, thickness and structure of the skin, fat and muscles, nervous excitability etc. In accordance with the requirements of humanity the StopWoofer Bark Collar has a special system of restrictions for the duration...
  • Page 9 LEVELS OF CORRECTION IN THE MODE “VIBRATION”: Vibration 0.5 second 1 bark: Vibration 1 second 2 bark: Vibration 1.5 second 3 bark: Vibration 2 seconds 4 bark: Vibration 2.5 seconds 5 bark: Vibration 3 seconds 6 bark: Vibration 4 seconds 7 bark: Sleep mode.
  • Page 10 LEVELS OF CORRECTION IN THE MODE “VIBRATION+SOUND”: Sound Warning 1.6 second then 1 bark: Vibration 0,5 second Sound Warning 2.8 seconds then 2 bark: Vibration 1 second Sound Warning 5 seconds then 3 bark: Vibration 1,5 second Sound Warning 5 seconds then 4 bark: Vibration 2 seconds Sound Warning 5 seconds then...
  • Page 11 IMPORTANT! The collar moves to the next level of correction consistently and only if the dog continues to bark. If the dog does not bark for 30 seconds, then the collar returns to the first level of correction. After “sleep mode” activation the collar returns to the first correction level.

  • Page 12: Device Overview

    DEVICE OVERVIEW Vibration Vibration+Sound Mode of operation Sensitivity Battery On/Off/ charging level Level tune Silicone point Sensor USB charging guards port...
  • Page 13 COLLAR SETTING IMPORTANT! Before using the collar please test the full cycle of correction. Step 1: Place the silicone contact point guards on the vibration contact points (for lessening of the chafing of the dog’s skin) Step 2: Turn on the collar by pressing the button on the top panel of the collar till the digital display lights up.
  • Page 14 Step3: Test the collar Activate the collar with the help of the Testing device that comes with the collar. Put the testing device’s speaker as close as possible to the hole on the back panel of the collar (where the sensor is) and turn on the testing device (toggle the switch into ON position on the side panel of it).
  • Page 15 To test the full cycle of correction in the mode “Vibration” choose the mode “Vibration” by pressing the button. The green icon will be on the screen. Use the testing device to check the full cycle of correction in the current mode. Step 4: Tune the Sensitivity Level By pressing the button choose the mode...
  • Page 16 IMPORTANT! The higher the level of sensitivity the easier the sensor will get activated. After turning off and turning back on the collar your settings will remain. While tuning the sensitivity, the numbers will be on the digital display. Settings recommended for dogs of different size and weight size weight...
  • Page 17 IMPORTANT! The correct settings of the sensitivity level makes the efficiency of the collar’s work higher. Step 5. Tune the vibration level “Vibration” mode By pressing the button choose the “Vibration” mode. The green icon will be on the screen. By pressing the button adjust the vibration level from 1-5, where 1 - is the minimum vibration level, 5 - is the maximum...
  • Page 18 IMPORTANT! The collar setting should be individually adjusted. We recommend starting with the minimum level - 1, and level up gradually till the maximum level - 5. You should choose and apply that level of vibration, that will make the collar correct your dog’s barking and its unwanted behavior most effectively.
  • Page 19 Put the dog in a comfortable position for it and for you to apply the collar correctly Put the collar on your dog — high under the jaw and tighten the strap tight.The receiver (main body) of the collar must be located exactly in the middle of the neck, a couple of centimeters above or below your dog’s Adam’s apple...
  • Page 20 Let your dog wear the collar for a couple of minutes and then check again if it fits well. When the dog gets used to the collar, double check the correct placement of the collar. IMPORTANT! If you don’t tighten the strap tight enough, it won’t work correctly.
  • Page 21 THE FIRST USAGE When using the collar for the first time, we recommend using it for 2-3 hours to let your dog get used to the collar. (To turn it off press button on the top panel of the collar till the display goes out) When you find your dog being used to the collar, you can proceed to correct barking.
  • Page 22 choose and apply that level of vibration that will make the collar correct your dog’s barking and its unwanted behavior most effectively. IMPORTANT! Efficiency of the collar’s influence on the dog depends on the correct vibration level setting. Also, tuning the sensitivity level we recommend starting with the minimum level - 1, and level up gradually till the maximum level - 7.
  • Page 23 that. When you activate the collar for the first time we recommend giving commands such as “Hush”, “No”, “Stop” or something similar when the dog starts barking. Don’t use the collar when your dog is agitated, barking constantly, jumping, unexpectedly squealing etc.

  • Page 24: Charging The Collar

    CHARGING THE COLLAR When the icon starts blinking, the battery is discharged. Please charge the device. For battery protection the collar turns off in 30 seconds automatically. Use the USB cable that comes with the device to charge the collar. While charging the batter, there is a running icon that shows the battery getting charged.
  • Page 25 IMPORTANT! The work time of the battery can vary depending on the frequency of the collar activation. Power Bank USB Outlet Сharging adapter PC/Laptop...
  • Page 26 Is the collar waterproof? Yes, it is. You can use the collar in any weather conditions. The current model of the bark collar is designed to be waterproof. Is the collar rechargeable or do I need batteries? The current model of the bark collar is rechargeable.
  • Page 27 Why doesn’t the collar activate when my dog barks? Make sure the icon isn’t blinking (in this case you need to charge the device using the USB cable). Test the collar. If the collar is tested correctly then you will need to increase the sensitivity of the sensor.
