- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 800265 BOOKCASE REVISION 0 : 04/20/2017 PAGE 1 OF 8 COASTERFURNITURE.COM REVISION 1 : 06/17/2019 REVISION 2 : 01/20/2020...
-
Page 2: Assembly Tips
800265 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. - Page 3 800265 ITEM: STEP 1 A x2 4 x16 2 x8 Apply glue on all wooden dowels to ensure integrity of the structure. STEP 2 3 x16 D x4 C x4 2 x32 Apply glue on all wooden dowels to ensure integrity of the structure.
- Page 4 800265 ITEM: STEP 3 Apply glue on all wooden dowels to ensure integrity of the structure. PAGE 4 OF 8 COASTERFURNITURE.COM...
- Page 5 800265 ITEM: STEP 4 STEP 5 Apply glue on all wooden dowels to ensure integrity of the structure. PAGE 5 OF 8 COASTERFURNITURE.COM...
- Page 6 800265 ITEM: STEP 6 5 x12 Apply glue on all wooden dowels to ensure integrity of the structure. STEP 7 COMPLETE PAGE 6 OF 8 COASTERFURNITURE.COM...
- Page 7 800265 ITEM: 824mm(32.44") 165mm(6.5") 555mm(21.85") 165mm(6.5" ) 361mm(14.21") 283mm(11.14") 361mm(14.21") 165mm(6.5" ) 165mm(6.5" ) 361mm(14.21") 361mm(14.21") 165mm(6.5" ) 165mm(6.5" ) 361mm(14.21") 361mm(14.21") 555mm(21.85") 165mm(6.5" ) 165mm(6.5" ) 361mm(14.21") 361mm(14.21") 165mm(6.5" ) Note : Dimension tolerance ±5% PAGE 7 OF 8...
- Page 8 ANTI-TIPPING INSTALLMENT INSTRUCTIONS FURNITURE TIPPING RESTRAINT WARNING Injury may result from tipping furniture. This restraint may protect against tipping furniture. Do not allow children to climb on furniture. This restraint is not a substitute for proper adult supervision. Failure to detach this restraint before moving the furniture may result in injury and damage.
