Summary of Contents for iCEBOX iBOX flipscreen

Page 1 Owner’s Manual Version 2 (EU)
Page 3: Table Of Contents
General Warnings and Cautions ... 1 Protection Against Electric Shock ... 2 Information About Repair Service ... 3 Setting Up Your iCEBOX ... 6 Installing the Batteries ... 6 Connecting a TV Cable or Antenna ... 8 Connecting an S-Video Source ... 9 Connecting a Camera, VCR or Video Game.
Page 4 Television Mode ... 27 DVD & CD Mode ... 30 Internet Mode ... 32 Radio Mode ... 39 Video Mode ... 41 Cleaning the iCEBOX ... 43 Getting Help ... 44 Troubleshooting ... 45 FAQs ... 46 Accessories ... 51 Privacy Policy ...
Page 5 Privacy of Children ... 51 Other Web Sites ... 51 Security Information ... 52 Specifications ... 53 iCEBOX™ FlipScreen Warranty ... 54 Index ... 57...
Page 6 FlipScreen Owner’s Manual...
Page 7: Important Safety Instructions
Read and understand all iCEBOX instructions. Follow all warnings and cautions on the product and in these operating instructions. Do not use the iCEBOX for anything other than its intended use. Warning statements warn of hazards or unsafe practices Warning: that could result in serious personal injury or death.
Page 8: Protection Against Electric Shock
Carts and Stands. The iCEBOX should be placed on a cart or stand designed to securely support the weight of the unit. When mounted on a cart or stand, the iCEBOX should be moved carefully. Sudden stops, exces- sive force, or uneven surfaces may cause the cart to overturn.
Page 9: Information About Repair Service
Information About Repair Service Important Safety Instructions Servicing. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other haz- ards. Refer all servicing to qualified service personnel. Damage requiring service. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power-supply cord or plug is damaged.
Page 10 FlipScreen Owner’s Manual...
Page 11: Getting Started
Getting Started Getting Started Welcome to the iCEBOX™—the ultimate Information, Communication, and Entertainment system designed specifically for the kitchen. With the iCE- BOX™ FlipScreen, you can watch television, browse the Internet, play DVDs or CDs, check your Email, and monitor other areas of your home, all from the convenience of your kitchen.
Page 12: Setting Up Your Icebox
FlipScreen Owner’s Manual Setting Up Your iCEBOX Before you turn on your iCEBOX, you will need to install the batteries in the remote and keyboard and set up the connections to support the many fea- tures of the iCEBOX. These connections may include: •...
Page 13 To install the batteries for your keyboard On the back of the keyboard, remove the battery cover by loosening both large screws on either end of the battery panel (fig. 3). Keep the attached washers with each screw. Remove the rubber gasket. Install two AA batteries, ensuring that the polarity (+ and –) on the bat- teries matches the + and –...
Page 14: Connecting A Tv Cable Or Antenna
FlipScreen Owner’s Manual Connecting a TV The iCEBOX is a 125-channel, cable-ready, stereo television. To use your iCEBOX as a television, you must first connect it to a TV signal source. Cable or Antenna To connect the TV cable •...
Page 15: Connecting An S-Video Source
• back of the iCEBOX. Connecting the You can use the iCEBOX to listen to your favorite local FM radio stations in FM Radio Mode. Enclosed with your iCEBOX FlipScreen is a dipole FM FM Radio radio antenna and an adapter.
Page 16: Connecting To The Internet
Your iCEBOX accessories box includes a PCMCIA Network card which supports an Ethernet connection to a DSL or cable modem. Because the iCEBOX uses the Windows CE .NET platform, we cannot ensure that an alternate network card will work. Please contact customer support for a current list of alternate supported cards.
Page 17: Wireless Broadband Connectivity
Wireless Broadband Connectivity There are two ways to connect the iCEBOX to your wireless network: • Using an approved wireless PCMCIA Network card; or, Using a wireless bridge connected to the ethernet PCMCIA card. • Because the iCEBOX uses the Windows CE .NET platform, we cannot ensure that all wireless network cards will work.
Page 18: Dial-Up Connectivity
AOL is an example of an ISP that will not work with the iCEBOX because of their download requirements, although you can still retrieve AOL mail using the iCEBOX Internet browser. Insert the modem card into the PCMCIA slot on the back of the iCEBOX.
Page 19: Connecting Other Devices
Printer Devices You can print Web pages with a compatible printer. Connect a printer to one of the USB ports on the bottom of your iCEBOX (fig. 4). For more information on using printers with your iCEBOX, visit support.iceboxllc.com. External Speakers You can route sound through a home stereo or other amplified audio sys- tem.
Page 20 FlipScreen Owner’s Manual...
Page 21: Using The Icebox Controls
Using the iCEBOX Controls Before turning on your iCEBOX FlipScreen for the first time, take a moment to familiarize yourself with the controls. When you turn your iCEBOX on for the first time, it will be in Television Mode. See Television Mode on page 27 for information on programming the television channels.
Page 22: Led Indicator
FlipScreen Owner’s Manual LED Indicator The LED indicator on the front panel of the iCEBOX tells you what the cur- rent power status is for your iCEBOX. Displays onscreen menus for your current Options mode. Turns your iCEBOX on. Press again Power On/Off to put iCEBOX in Sleep Mode.
Page 23: Remote And Keyboard
The buttons on the remote and keyboard are laid out in sections and are color coded. The following table shows which colors are associated with the various modes. Mode Television Mode Internet Mode DVD & CD Mode The iCEBOX Remote FIGURE 6. Using the iCEBOX Controls Color of Buttons Purple Orange Green...
Page 24: Mode And Power Buttons
Options menu for the current mode. Mode and Power Buttons FIGURE 7. Turns the iCEBOX on. Press again to Power put iCEBOX in Sleep Mode. (See LED Indica- tor on page 16) Television Television Mode sion Mode so that you can watch your favorite shows.
Page 25: Television Mode Buttons
Press Volume –/+ to decrease the volume. Press to jump to the last viewed Last Channel channel. Press to turn off all sound from the iCEBOX. Mute To resume sound, press again or press Volume –/+...
Page 26: Internet Mode Buttons
FlipScreen Owner’s Manual Internet Mode Buttons The Internet Mode buttons do the following: Internet Mode Buttons FIGURE 9. Press to move the selection indicator Jump to Target to the target area and back again. Press to display your list of favor- Jump to Favorites ite Web sites.
Page 27 Using the iCEBOX Controls The directional buttons and the GO button are shown in figure 10. Directional Buttons and GO Button FIGURE 10. In Internet Mode, use the directional buttons around the GO button to move the colored selection box around the screen to select a link. To fol- low the link, press GO.
Page 28: Dvd & Cd Mode Buttons
FlipScreen Owner’s Manual DVD & CD Mode Buttons The DVD & CD Mode buttons do the following: DVD & CD Mode Buttons FIGURE 11. Press to begin or resume playing a disc. Play Press to pause the DVD or CD in its present Pause track.
Page 29 Subtitle Display Zoom Angle 3D Audio Using the iCEBOX Controls Press to toggle between different repeat modes, such as track or disc. Press to have chapters or tracks play in a random order. Press again to cancel random play. Press to toggle among available audio tracks on DVDs, such as dubbed languages or director com- mentary.
Page 30: Adjusting The Image And Sound
FlipScreen Owner’s Manual Adjusting the In any mode (see Using the iCEBOX Modes on page 27), you can adjust aspects of the image and the sound that your iCEBOX produces. Once Image and Sound made, these adjustments are in effect for all modes.
Page 31: Stylus & Touch Screen
Tap a text box to select it. • Tap the arrow of a drop-down list to display the options, then tap an • item in the list. Drag a scroll bar to scroll the Web page. • Using the iCEBOX Controls...
Page 32 FlipScreen Owner’s Manual...
Page 33: Using The Icebox Modes
Also, you can program the television channels that are available in your area. Choosing the Television Signal Source For your iCEBOX to work properly in Television Mode, you need to select the signal source that is plugged into the iCEBOX. To select the television signal source If not already in Television Mode, press Television.
Page 34: Programming The Television Channels
To set a satellite signal source coming in through the TV In coaxial con- nection, select the Cable option when choosing the Signal Source. You may also want to remove all the iCEBOX channels except 3 or 4 (if needed) to prevent the Channel +/- buttons from having any effect.
Page 35: Changing Channels
Changing Channels You can change television channels on your iCEBOX using either of the fol- lowing methods. To change channels Using the number keys, enter the channel number that you want to • view. After a few seconds, the new channel appears.
Page 36: Dvd & Cd Mode
FlipScreen Owner’s Manual DVD & CD Mode Playing DVD and CDs In DVD & CD Mode, the iCEBOX can play DVDs and music CDs. To play a DVD or CD General Commands The following table lists additional tasks and commands: Press on the front panel of the iCEBOX to open the disc tray.
Page 37 3D Audio is an optional audio setting that may enhance the listening qual- ity of some DVD and CDs. To listen with 3D Audio Press 3D Audio. Press again to turn 3D Audio off. Using the iCEBOX Modes On the remote or keyboard, press Zoom Press again to see other zoom options.
Page 38: Internet Mode
FlipScreen Owner’s Manual Internet Mode You can browse the Internet on your iCEBOX using Internet Mode. Using the remote, keyboard and touch screen, you can browse web sites, check email and look up useful information in the kitchen. You can specify a default home and email web page for quick access.
Page 39: Configuring Connection Settings
Configuring Connection Settings The iCEBOX can connect to the Internet in three different ways: • Wired (Ethernet) Broadband Wireless (802.11b) Broadband • Dial-Up • Configuring a Wired Broadband Connection If you’ve installed the included PCMCIA Network card for a wired (ether- net) Broadband connection, further configuration may not be needed.
Page 40 Select the IP button. The MAC Address of the wireless card is displayed. Write it down so you can enter it when configuring your router for the iCEBOX. The iCEBOX does not currently support any ISPs that require downloading or installing software. At the time of the printing of...
Page 41: Configuring Browser Settings
Enter the address of the Web page that you want as your home page. For example: www.yahoo.com Select the Email URL field. Enter the address of the Web page you want as your Email service. For example: www.hotmail.com Set the current Date and Time. Choose OK. Using the iCEBOX Modes...
Page 42: Browsing The Internet
Internet. The Selection Box Unlike a desktop or laptop computer, the iCEBOX does not have a cursor. Instead, a colored outline or highlight, also known as the selection box, indicates the active element of the screen. Buttons, links to other pages, boxes in forms, and other interactive elements on Web pages are selected when highlighted.
Page 43 With the stylus, tap the on the touch screen. –Or– On the remote or keyboard, press Select the Favorite that you want to delete. Choose the Delete button. Choose OK. Using the iCEBOX Modes www.iceboxeurope.com switches the focus between the Web...
Page 44 FlipScreen Owner’s Manual Other Internet Mode Commands The following table lists additional tasks and commands. To... Do This... Disconnect a Dial-Up con- nection to the Internet Go back to the previous On the remote or keyboard, viewable Web page press –...
Page 45: Radio Mode
Radio Mode With the iCEBOX, you can listen to your favorite FM Radio stations. The iCEBOX can receive radio signals from either the included FM Antenna or your cable service, if it is offered. If you want to listen to your local radio stations, we recommend using the FM Antenna.
Page 46 FlipScreen Owner’s Manual To name a saved station To remove stations With the iCEBOX in Radio Mode, choose Manage Stations. In the Saved Stations list, select the station you want to name. Select the Station Name box. Type a name (up to 25 characters) for the selected station.
Page 47: Video Mode
Video Mode The iCEBOX can be connected to a video camera which you can use to monitor another part of the house. For example, you can monitor the activ- ity in a child’s room or see who is at the front door.
Page 48 FlipScreen Owner’s Manual...
Page 49: Caring For Your Icebox
Unplug the iCEBOX from the wall. Clean the exterior of the iCEBOX using a slightly damp, lint-free cloth. Gently clean the LCD screen with a slightly damp, lint-free cloth. Using a soft, nonabrasive sponge and mild detergent or dish soap, wash the remote and keyboard and rinse under the faucet in the sink.
Page 50: Getting Help
FlipScreen Owner’s Manual Getting Help If you have questions while using the iCEBOX, access the built-in Help to find answers. This comprehensive Help contains information that you can use to solve most problems that you may encounter. Note: To get help •...
Page 51: Troubleshooting
The unit has stopped responding. Turn the • unit off at the power switch on the back panel and unplug the unit for five seconds. Plug the it back in and turn it on. More Troubleshooting tips are available in the iCEBOX Help.
Page 52: Faqs
Can I add more memory to the iCEBOX? No, you cannot add more memory to your iCEBOX. However, the amount of RAM currently installed in the iCEBOX is more than adequate to handle all of its functions. Can you print from the iCEBOX? Printing is currently available with a variety of printers.
Page 53 Both items are water resistant. They can be washed with a mild detergent and water and then rinsed under the kitchen faucet. How do I clean the touch screen display of my iCEBOX FlipScreen? Any household cleaner that does not contain vinegar is appro- priate.
Page 54 BOX Help. What does it mean when the same Web site viewed on my iCEBOX looks slightly different from how it looks on my PC? If this occurs, it will occur very rarely. It is a result of very minor differences between your iCEBOX browser and the browser on your PC.
Page 55 FM radio reception. You may be able to improve reception by using a more powerful antenna. Does touch screen work with the FM radio mode? Yes. The touch screen works with all the functionality of the Radio mode. Caring for Your iCEBOX...
Page 56 FlipScreen Owner’s Manual...
Page 57: Additional Information
Additional Information Accessories Your iCEBOX can connect to a variety of accessories. For information on which devices and accessories are compatible with your iCEBOX, contact customercare@iceboxeurope.com. Privacy Policy Icebox, Europe is committed to protecting the privacy and security of iCE- BOX users.
Page 58: Security Information
Therefore, we must advise you that no security system is perfect and that your use of the iCEBOX product constitutes a waiver of any claim against Icebox, Europe for direct, consequential, and all other damages arising...
Page 59: Specifications
Specifications Size - with speakers 600 mm x 275 mm x 97 mm (23 5/8 in x 10 13/16 in x 3 7/8 in) Weight 10.9 kg (24 lb) Power Source 230-240 V AC, 50 Hz Display 800 x 600 pixels 12.1 TFT-LCD with backlight Touch Screen E-Fast Resistive touch screen Activation force <130 g...
Page 60: Icebox™ Flipscreen Warranty
ICEBOX LLC will, at its option either repair or replace your product, if it is found to be defective in the warranty period, at no charge with new or recon- ditioned parts or products.
Page 61 Except in respect of death or personal injury caused by ICEBOX LLC’s negli- gence or liability for defective products under the Consumer Protection Act 1987, ICEBOX LLC shall not be liable to you by reason of any representation (unless fraudulent), or implied warranty, condition or other term, or any duty...
Page 62 FlipScreen Owner’s Manual...
Page 63: Index
Index Numerics 3D Audio 23, 31 accessories 2, 51 Adjust 24 adjusting image & sound 24 analog phone line 12 Angle 23, 30 antenna 28 antenna grounding 2 attachments 1 Audio 23, 31 Audio Out 13 Autoscan Channels 28 Back 20, 38 batteries brightness 24 Broadband...
Page 64 5–?? GO 21, 31, 36 Help 44 Home 38 home page 20, 38 Home Page URL 35 hue 24 iCEBOX before using 1 cleaning 1, 43 controls 15–?? modes 27–?? servicing your 3 setting up 6–?? using for first time 15...
Page 65 21 Selection Box 36 selection frame moving 36 serial number 44 servicing 3, 44 setting up your iCEBOX 6–?? signal source 27 choosing 28 Skip Forward 22, 30 Skip Reverse 22, 30 sleep mode 16 sound adjusting 24...
Page 66 FlipScreen Owner’s Manual track, go to specific 31 troubleshooting 45 TV channels TV In 8 TV, cable 28 USB ports 13 User Name 34 VCR 41 video camera 13 video games 41 Volume –/+ 15, 19 using 36 changing 29 Email 35 Home Page 35 Warnings and Cautions 1...
Page 67 Index...
Page 68 FlipScreen Owner’s Manual...
Page 69 • Your license rights under this EULA are non-exclusive. • You agree that Icebox and/or Macromedia may audit your use of the Software fro compliance with these terms at any time, upon reasonable notice. • NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT. Icebox LLC HAS INDEPENDENTLY DETERMINED HOW TO USE THE SOFTWARE IN THE DEVICE, AND MACROMEDIA HAS RELIED UPON Icebox LLC TO CONDUCT SUFFICIENT TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE FOR SUCH USE.
Page 70 • ATE A WARRANTY OR IN ANY WAY INCREASE THE SCOPE OF ANY WARRANTY PROVIDED HEREIN. (USA only) SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPE- CIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER LEGAL RIGHTS THAT VARY FROM STATE TO STATE.
Page 72 BFS04-401N-EU...
