Fulham FIREHORSE FHS2-20WFL-20W Manual

- Emergency LED Fixture
- 90 Min Backup time at 20W in power failure condition.
- Programable Output Power 5W to 20W.
- Inbuilt Self Diagnostic feature for fault detection
1 2 3 4 5 6 7 8 9 # # # # # # # # # # # # # #

Electrical Specifications

Rated Input Voltage *
Operating Input Voltage Range *
Input Power *
Standby Input Power *
Output Power (Emergency mode)
Battery Discharge Time

Optical Specifications

CCT *
Lumen (at 20W) *
Efficacy (at 20W) *
CRI *
Beam angle
Estimated Lumen Maintenance at Max Ta
Color Consistency

General Specifications

Fixture
Overall Size
Units per Master Carton
IP Rating
IK Rating
Storage temp. range
Operating temperature range (Ta)
Service Life
Battery Life
Warranty

Lumen Vs Backup Time

3500
3000
2500
2000
1500
1000
500
0
30
NOTES :
1-
* - All Parameters are applicable for the Charging mode operation.
*- Maintains a tolerance of ±7% on flux and power measurements, Nominal CCT as defined by ANSI standard measurements 5700K (+/-355) and a tolerance of
2-
±2% on CRI measurements.
Fulham extends a limited warranty only to the original purchaser or to the first user from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog
(www.fulham.com). Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in
design or construction to the equipment described. © Fulham Company Limited, All Rights Reserved.
FHS2-20WFL-20W EMERGENCY FLOOD LIGHT
60 90 120 150
Backup Time (Min.)
- Inbuilt LiFePo4 Battery pack
- Fault detection and indication through test switch
- Suitable for Non maintained Application.
# # # # # # # # # # # # # # # # # # # # # # # 48
100-277VAC, 50/60Hz
100-277VAC, 50/60Hz
6W MAX (Charging mode)
< 0.8W
1.2W to 20W Max
90 Min. at 20W Backup power; 360 Min. at 5W Backup Power
5700K
2800 LM
140 LM/W
70 CRI
Type II, 135° x 85°
L70: > 60,000hrs.; L90: 48000hrs.;
Binning per ANSI C78.377-2015 @ 25°C Tj; 5 SDCM
Aluminum Die cast
221mm x 181mm x 111mm
1 Pcs.
IP 65
IK 08
-20°C to 70°C
0°C to 40°C
50,000 Hrs
2,000 cycles
3 years @ Max. Tc from the date of manufacturing
180 210 240 270 300 330
Page 1 of 3
2022-02 Rev. 00
PM-FR-004 Rev. 00
20W
15W
10W
5W
360
