TWS bluetooth headset
AirBuds 1/AirBuds 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirBuds 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Blackview AirBuds 1

  • Page 1 TWS bluetooth headset AirBuds 1/AirBuds 2...
  • Page 2: Product Overview

    Product Overview Multifunctional Area Microphone Charging Port Indication of LED Device Connectivity First Pairing 1. Open the cover and the wireless earphones will automatically turn on. Then entering the pairing state, the red and blue indicator lights on the right earphone will flash alternately and quickly.
  • Page 3: Wearing Method

    2. Turn on the Bluetooth on the device, select "AirBuds 1", click and connect. The voice "Connected" represents successful pairing. AirBuds 1 Note: The above is the first pairing method. In subsequent use, the earphones will automatically turn on and connect after being taken out from the earphone box.
  • Page 4: Operation Method

    Operation Method L Airbud R Airbud Play /Pause Click once Click once Previous Click twice Next Click twice Volume+ Long press Volume- Long press Answer Click twice Click twice Ring off Click twice Click twice Long press Reject Long press for 2 seconds for 2 seconds Voice Assistant Click 3 times...
  • Page 5: Specifications

    Specifications Model: AirBuds 1 Bluetooth Version: 5.0 Battery Type: Li-ion Ploymer(3.7V,55mAh) Bluetooth Frequency: 2.402GHz-2.480GHz Bluetooth Trasmitted Modulation: GFSK, π/4 DQPSK, 8DPSK Dynamic Driver: 8.0mm Dynamic Frequency Response: 20Hz-20KHz Battery Capacity(Charging Box): 390mAh Charging Time(Charging Box): <2hrs Battery Life(Earbuds): About 5hrs Charging Time(Earbuds): <2hrs...
  • Page 6 Answers for common questions (1) Bluetooth headset cannot be turned on. Reason: The battery of the Bluetooth headset is low or dead. Solution: Put the earphones in the charging case, close the cover and charge them for more than 1 hour before turning on the earphones.
  • Page 7 Solution: 3. Please make sure that the mobile phone and earphones are used within 10 meters, meanwhile there are no obstacles. (4) The earphone cannot convey the voice or the voice is very low. Reason: 1. The Bluetooth headset is too far away from the mouth.
  • Page 8 (6) The headset is not disconnected after closing the earphones box. Reason: 1. The charging box is completely out of power. Reason: 2. If the headset is not put in the box correctly, it will cause abnormal communication between the headset and the base.
  • Page 9: Maintenance

    Attention - Please do not disassemble this product by yourself. - Please use standard charging cable and adapter to avoid damage and accidents. - Please aviod using corrosive cleaning detergent to clean this product. - Plase avoid product usage in the rain and keep away from heating or fire.
  • Page 10 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This manual is also suitable for:

Airbuds 2
