Summary of Contents for Snap Fresh BBT-POB04
- Page 1 User Manual CORDLESS IMPACT DRIVER BBT-POB04 Please scan the QR CODE for more services. Read all safety rules and instructions carefully before operating this tool. geprufte Sicherheit...
-
Page 2: Table Of Contents
CONTENTS Contents ......................................2 ......................................Symbols Safety instructions ................................4-7 ................................8-9 Machine information ......................................9-11 Operation ....................................Maintenance ......................................Warranty... -
Page 3: Symbols
SYMBOLS The rating plate on your tool and the manual cover may show certain symbols. These represent important information about the product or instructions on its use. Hearing, sight and respiratory Before use, read the handbook carefully. protection must be worn. 1h charging time. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Read the enclosed safety warnings, the additional safety warnings and the instructions. Failure to follow the safety warnings and the instructions may result in electric shock, fire and/or serious injury. Save the safety warnings and the instructions for future reference. GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. - Page 5 Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. Remove any adjusting key or wrench before turning the power tool on.
- Page 6 Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredi- ctable behaviour resulting in fire, explosion or risk of injury. Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130 °C may cause explosion.
- Page 7 ADDITIONAL SAFETY RULES FOR CHARGERS • Before using the charger, read all instructions and cautionary markings on the charger and battery pack as well as the instructions on using the battery pack. • Only charge your batteries indoors as the charger is designed for indoor use only. •...
-
Page 8: Machine Information
MACHINE INFORMATION 1. 1/4” Hex Chuck 5. LED Light 4. Variable Speed Trigger Control 2. Lock/ Forward/ Reverse Knob 3. Handle 7. 20V 2.0Ah Battery 6. Belt Clip 1 x Carry Bag 4 x Socket Adapters 1 x 20V Charger 7 x Screwdriver Bits 1 x 2.0Ah Battery COMPONENTS AND CONTROLS... -
Page 9: Operation
TECHNICAL SPECIFICATION Model Number BBT-DC20A Model No. BBT-POB04 Battery Type Lithium-ion Rated voltage Voltage No load speed 0-2200 rpm Capacity 2.0 Ah Recommended charger BBT-YFT20V Impact rate 0-3000 bpm Weight 0.3 kg 150 Nm Max torque Model Number BBT-YFT20V Charger input... - Page 10 Selecting correct driver bit/socket bit Always use the correct size driver bit/socket bit. Use only the driver bit/socket bit shown in below picture. Do not use any other driver bit/socket bit. An incorrect size bit will result in inaccurate and inconsistent fastening torque and /or damage to the bolt or nut.
-
Page 11: Maintenance
Variable speed This tool has a variable speed switch that delivers higher speed and torque with increased trigger pressure. Speed is controlled by the amount of switch trigger depression. LED light The LED work-light can light prior to motor running if you press the switch lightly, which keep the work area to be lighted for checking clearly at first, and it lights also during your operation. -
Page 12: Warranty
WARRANTY Ningbo Babytec Technology Co., Ltd (Hereinafter referred to as Babytec) warrants this product against defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the original purchaser(’Warranty Period’). The following circumstances are excluded from this guarantee: Repairs and or alterations have been made or attempted to the machine by unauthorized service centers;...
