Summary of Contents for Snap Fresh BBT-ZE33
- Page 1 User Manual CORDLESS LAWN MOWER BBT-ZE33 Scan here to contact us [24Hrs Online] https://snapfresh.afterservice.vip Read all safety rules and instructions carefully before operating this tool. geprufte Sicherheit...
-
Page 2: Table Of Contents
CONTENTS ....................................Contents ....................................Symbols ..............................Safety instructions Technical speci cations ................................................................Assembly ............................... Instructions for use 12-17 ................................Tips on lawn care ................................Maintenance 17-19 ..................................Environment .................................... Warranty... -
Page 3: Symbols
SYMBOLS Symbols Used In This Manual WARNING! Denotes impending danger. Non-observance of this warning may result in death or extremely severe injuries. CAUTION! Denotes a potentially dangerous situation. Non-observance of this warning may result in injury or damage to property. NOTE Denotes application tips and important information. - Page 4 Symbols On The Power Tool General safety warning! Before switching on the power tool, read the operating manual! Remove the safety key before carrying out any work on the unit and before leaving the unit. Keep third parties away from the danger area! Always maintain a safe distance from the garden tool when it is working! Ejected objects and rotating parts can cause serious injuries.
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS WARNING! Before using the garden tool, read and follow: these operating instructions, the user instructions of associated/supplied accessories (charger, battery), the currently valid site rules and the regulations for the prevention of accidents. User This garden tool is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and know-ledge, unless they have been given supervision or instruction concerning use of the machine by a person responsible for their safety. - Page 6 Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
- Page 7 Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations di erent from those intended could result in a hazardous situation. Keep handles and grasping surfaces dry, clean and free from oil and grease.
- Page 8 Switch the unit o and remove the safety key under the following conditions: • if the unit is left unattended; before checking, cleaning or performing other work on the unit; before removing blockages; • if a foreign object is hit; Check the lawn mower for damage, and have any damage repaired at a quali ed technician or a service centre.
- Page 9 • Before removing the grass catcher, switch the motor o and wait until the cutter bar has come to a standstill. After emptying the grass catcher, carefully re-attach it and ensure that the grass catcher is attached securely to the lawn mower. •...
-
Page 10: Technical Speci Cations
TECHNICAL SPECIFICATIONS Model Number BBT-DC40A Model No. BBT-ZE33 Battery type Lithium-ion Voltage Rated voltage Capacity 4.0 Ah Recommended charger BBT-YFT20V Cutting width 330 mm Weight 0.6 kg Capacity grass catcher Model Number BBT-YFT20V Charger input 100-120V~60Hz 65W Speed 3400 r.p.m. -
Page 11: Assembly
ASSEMBLY A. Upper handle B. Knob C. Lower handle D. Grass catcher E. Battery cover F. Wheels G. Start Button H. Brake Level... -
Page 12: Instructions For Use
INSTRUCTIONS FOR USE Before initial operation Unpack the garden tool and accessories and check that no parts are missing or damaged. NOTE The batteries (optional; depending on delivery scope) are not fully charged on delivery. Prior to initial operation, charge the batteries fully. See user manual of the battery charger. Safety key The unit has a security key. - Page 13 Assembling WARNING! Before performing any work on the garden tool, remove the safety key. Attaching the handle bar CAUTION! • Tools are not required to attach the handle bar. • Fold the lower handle upwards. • Insert the lower handle into the two bolts and fasten the bar with the knobs. •...
- Page 14 Attaching the grass catcher 1. Assembling grass catcher. 2. Lift the back cover of the mower. 3. Hook the grass catcher bag into the lawn mower. 4. Fold the back cover down again.
- Page 15 Attaching the mulching plug The mulching plug helps to curve the inside of the mower deck for more e cient mulching. Install and remove the mulching plug by raising the rear discharge guard as shown. The mulching plug only ts one way. Remove the mulching plug when using a grass bag. Note: Optional function, not all models have this function.
- Page 16 Inserting/replacing the battery 1. Charging the battery as described in the user manual of the charger. 2. Open the battery cover. 3. Press the charged battery into the power tool until it clicks into place. 4. Close the battery cover. CAUTION! Protect the battery contacts when the battery is not being used.
-
Page 17: Tips On Lawn Care
Switching o Release the On-/O -switch(2). WARNING! After release the On/O switch, the cutter bar continues running brie y. Risk of injury! Removing and emptying the grass catcher If the grass catcher bag is full and should be emptied immediately. 1. - Page 18 • Remove the grass catcher. • After mowing, always clean the lawn mower with a hand brush.the grass catcher. • Remove grass residues carefully out of the cutting area. Remove stuck clipping deposits • using a stick. • Keep the ventilation slits clean and dust-free. Grass catcher For thorough cleaning, the grass catcher can be cleaned with a hose.
-
Page 19: Environment
Storage • Remove the safety key and remove the battery from the mower before storing. • Store the unit in a dry and frost-free place (10-25 °C). • Store the battery and the unit separately. • Charge the battery before storing the unit in winter. •... -
Page 20: Warranty
WARRANTY Ningbo Babytec Technology Co., Ltd (Hereinafter referred to as Babytec) warrants this product against defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the original purchaser (’Warranty Period’). The following circumstances are excluded from this guarantee: •...
