Summary of Contents for Snap Fresh BBT-ZOY01
- Page 1 User Manual CORDLESS MULTI-TOOL BBT-ZOY01 Please scan the QR CODE for more services. Read all safety rules and instructions carefully before operating this tool. geprufte Sicherheit...
-
Page 2: Table Of Contents
CONTENTS ....................................Contents ....................................... Symbols ..............................Safety instructions .............................. Machine information ..................................Assembly 10-13 ....................................Operation ..................................Maintenance ................................... Environment ....................................Warranty... -
Page 3: Symbols
SYMBOLS The following symbols are used in the user manual or on the product: Indoor use only. Read the user manual. Denotes risk of personal injury, loss of Class II machine - Double insulation - life or damage to the tool in case of You don’t need any earthed plug. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Read the enclosed safety warnings, the additional safety warnings and the instructions. Failure to follow the safety warnings and the instructions may result in electric shock, fire and/or serious injury. Save the safety warnings and the instructions for future reference. GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. - Page 5 3) Personal safety Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. Use personal protective equipment.
- Page 6 5) Battery tool use and care Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
- Page 7 • Only use accessories with the correct dimensions. • Do not use accessories that require liquid coolants. Risk of electric shock. • Make sure that the accessories are properly mounted. Do not use adapters or other aids to mount accessories with another spindle diameter. •...
-
Page 8: Machine Information
1.5mm . If you use an extension cable reel, always fully unroll the cable. MACHINE INFORMATION Intended use Your cordless multi-tool has been designed for light sanding, sawing and scraping applications. TECHNICAL SPECIFICATIONS Model Number BBT-DC20A Model No. BBT-ZOY01 Battery type Lithium-ion Rated voltage Voltage Capacity 2.0 Ah No load speed... - Page 9 Wear hearing protection. Only use the following batteries of the SnapFresh power 20V battery platform. Using any other batteries could cause serious injury or damage to the tool. BBT-DC20A 20V, 2Ah Lithium-ion BBT-DC40A 20V, 4Ah Lithium-ion The following charger of the can be used to charge these batteries. BBT-YFT20V Quick charger The batteries of the SnapFresh power 20V battery platform are interchangeable with all the SnapFresh...
-
Page 10: Assembly
ASSEMBLY... - Page 11 Before any work on the power tool, remove the battery. The battery must be charged before first use. DESCRIPTION The numbers in the text refer to the diagrams on page 10-11. 1. On/off switch 7. Battery 2. Speed adjustment wheel 8.
- Page 12 Inserting the battery into the machine (Fig. C) Ensure that the exterior of the battery is clean and dry before connecting to the charger or machine. • Insert the battery (7) into the base of the machine as shown in Fig. C. Push the battery further forward until it clicks into place.
- Page 13 The charger has 2 LED indicators (12) which indicate the status of the charging process: Red LED Status Green LED status Charger status No power Standby mode: -No battery is inserted or, -Battery inserted but charging has nished Battery charging in progress •...
-
Page 14: Operation
OPERATION Switching on and off (fig. A) • To switch on the machine, slide the on/off switch (1) to the front. • To switch off the machine, slide the on/off switch (1) to the rear. Setting the speed (fig. A) The speed adjustment wheel is used for setting the speed. -
Page 15: Environment
ENVIRONMENT Faulty and/or discarded electrical or electronic apparatus have to be collected at the appropriate recycling locations. WARRANTY Ningbo Babytec Technology Co., Ltd (Hereinafter referred to as Babytec) warrants this product against defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the original purchaser (’Warranty Period’).
