TRANSPORTER
Engineering Excellence
Voyager S7
Car Transporter Driver Loading Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Voyager S7 2017 and is the answer not in the manual?

Questions and answers

Related Manuals for Transporter Voyager S7 2017

Summary of Contents for Transporter Voyager S7 2017

  • Page 1 TRANSPORTER Engineering Excellence Voyager S7 Car Transporter Driver Loading Manual...

  • Page 3: Table Of Contents

    Loading the Transporter: Loading Ramps Loading the Transporter: Top Deck Front Flap Loading the Transporter: Top Deck 13 - 14 Loading the Transporter: Swan Neck & Kick Up 15 - 16 Loading the Transporter: Kick Up 17 - 18 Loading the Transporter: Final Car...

  • Page 4: Deck Maximum Loads & Safety Signs

    • The above criteria apply subject to the transporter and all its equipment being correctly maintained. • If you are in any doubt never operate a deck or move a transporter without first contacting your manager. oPeration anD Safety SignS • Operation signs are located next to all controls.

  • Page 5: Paintwork & General Safety

    • Do not make any adjustments that you do not understand. • Do not move the decks whilst on the transporter. Never go under an unsupported deck. • Other persons must be kept at a safe distance while the vehicle or its equipment is in operation.

  • Page 6: Safety Checks & Power Take Off (Pto)

    Safety CheCkS A visual inspection should be conducted daily on the following items: All routine driver checks as set out in the Guide to Maintaining Roadworthiness should be performed to the vehicle. In addition the following items must be checked. • Safety hand rails are all secure and complete with no visual damage (see the hand rails section, page 8) • Securing straps and bollards/ratchets are working correctly, with no cuts to straps or...

  • Page 7: Hydraulic Valve Controls

    hyDrauLiC VaLVe ControLS A hydraulic control valve bank is fitted to the nearside of the vehicle. The levers are colour coordinated and have a corresponding air lock button where necessary. • Top Deck: Red levers with corresponding air lock buttons. • Swan Neck Flap: Blue lever, no air lock.

  • Page 8: Operating Decks

    oPerating DeCkS iMPortant! all personnel must be clear of the vehicle before operating any controls. Always check that the control levers return to neutral when released. Lifting DeCkS • Pull the relevant control handle towards you from its neutral position. The deck should now rise as the handle is held in this position.

  • Page 9: Loading Lights & Hand Rails

    The transporter has been fitted with a hand rail system that meets Health and Safety Regulations at time of manufacture, compliance with any retrospective change in the legislation after the vehicle has entered service is the responsibility of the operator.

  • Page 11: Loading The Transporter: Loading Ramps

    LoaDing the tranSPorter - LoaDing raMPS FULLY ExTEND BOTH O/S AND N/S HYDRAULIC LOADING RAMPS. UNLOCK THE MANUAL RAMPS BY FOLDING OVER THE LOCKING BAR. FULLY ExTEND THE MANUAL LOADING RAMPS BY LIFTING AND PULLING THE RAMP BY THE ORANGE STRAP. ONCE FULLY ExTENDED, LOCK THE RAMP IN PLACE WITH THE...

  • Page 12: Loading The Transporter: Top Deck Front Flap

    LoaDing the tranSPorter - toP DeCk front fLaP POSITION THE FRONT OF THE TOP DECK ONTO THE SUPPORT PINS LOCATED ON THE FRONT PILLARS. THE TOP DECK FRONT RAMP CAN BE SET AT T WO DIFFERENT ANGLES. THE PICTURE SHOWS THE RAMPS SPRING LOADED PINS SET TO GIVE THE MINIMUM DROP ANGLE.

  • Page 13: Loading The Transporter Top Deck

    LoaDing the tranSPorter toP DeCk FULLY LOWER THE “PROP” DECK AND THE REAR KICK UP DECK. ENSURE WHEEL STOPS ON THE REAR KICK UP ARE FOLDED OVER TOWARDS THE LOADING RAMPS, THEN LOWER THE TOP DECK REAR ONTO THE REAR KICK UP DECK. RELEASE THE TOP DECK WHEEL STOP LOCKS AND LOWER THE WHEEL STOPS.
  • Page 14 LoaDing the tranSPorter toP DeCk FULLY RAISE THE TOP DECK BY LIFTING THE REAR OF THE TOP DECK FIRST AND THEN THE FRONT AND REAR IN EqUAL AMMOUNTS.

  • Page 15: Loading The Transporter Swan Neck & Kick Up

    LoaDing the tranSPorter Swan neCk & kiCk uP FULLY RAISE THE KICK UP PROP AND THE FRONT KICK UP RAMP. ADjUST THE HEIGHT OF THE SWAN NECK FLAP TO LEVEL UP WITH THE FRONT OF THE KICK UP RAMP.
  • Page 16 LoaDing the tranSPorter Swan neCk & kiCk uP LOAD VEHICLE ONTO THE FIFTH WHEEL DECK AND SECURE VEHICLE TO THE TRANSPORTER. RAISE THE SWAN NECK FLAP TO MAxIMUM AND LOWER THE FRONT KICK UP TO BE LEVEL WITH THE TOP OF THE CHASSIS FRAME.

  • Page 17: Loading The Transporter Kick Up

    LoaDing the tranSPorter kiCk uP LOAD VEHICLE ONTO THE FRONT KICK UP RAMP AND SECURE THE VEHICLE TO THE TRANSPORTER. REVERSE VEHICLE ONTO THE REAR KICK UP RAMP AND SECURE THE VEHICLE TO THE TRANSPORTER.
  • Page 18 KICK UP TO A HEIGHT TO ALLOW THE LOADING OF THE LAST CAR. BEFORE LOADING THE LAST CAR FOLD OUT THE WHEEL STOPS. NOTE: WHEN UNLOADING THE TRANSPORTER REMEMBER TO FOLD THE WHEEL STOPS BACK OVER TO THE STOWED POSITION...

  • Page 19: Loading The Transporter: Final Car

    LoaDing the tranSPorter finaL VehiCLe DRIVE THE LAST VEHICLE ONTO THE TRANSPORTER. PLACE A WHEEL CHOCK IN FRONT OF EITHER THE FRONT OR REAR WHEELS AND SECURE THE VEHICLE TO THE TRANSPORTER.
  • Page 20 LoaDing the tranSPorter RETURN THE MANUAL LOADING RAMPS INTO THE STOWAGE AND FULLY RETRACT BOTH O/S AND N/S HYDRAULIC LOADING RAMPS. CHECK BOTH RAMPS ARE FULLY CLOSED AND ARE LOCKING THE MANUAL RAMPS INTO THE STOWAGE RAMPS. LOWER THE SWAN NECK FLAP AND THE REAR KICK UP RAMP THEN LOWER THE FRONT AND REAR OF THE TOP DECK.
  • Page 24 Transporter Engineering Limited Transporter House, Gosfield Business Park, Gosfield, Essex, CO9 1SA Tel: +44 (0)1787 478490 | Fax: +44 (0)1787 476047 www.transporter-eng.com...
