OPERATING MANUAL

Thank you for purchasing a SEABORG 300FB. To take full advantage of the reels

many useful functions, please read this manual carefully before using. Retain this

manual for future reference.

Reference

pursuetheoutdoors.com/schematics

Table of Contents

Need help?

Do you have a question about the Seaborg 300FB and is the answer not in the manual?

Questions and answers

Summary of Contents for Daiwa Seaborg 300FB

Page 1 OPERATING MANUAL Thank you for purchasing a SEABORG 300FB. To take full advantage of the reels many useful functions, please read this manual carefully before using. Retain this manual for future reference. Reference Reference pursuetheoutdoors.com/schematics...
Page 2 Daiwa braided line 9,10 The input method is simple: all you have to do is When line length is known 11,12 just to input data for spooling the reel with Daiwa shelf sensor bright. with backing line 13,14 Inputting the drawer...
Page 3 Caution Precautions 1. Be careful to keep fingers clear of the levelwind mechanism. It can pinch your fingers and cause injuries. 2. When the clutch is engaged and the line feeding motor is in operation, be careful not to catch your fingers to avoid any injury. 1.
Page 4: Power Source
Power source Black How to connect the reel to the power source Attach the cord clips to the battery. Red covered clip is the plus (+), and the black covered clip is the minus (-). Insert the connector into the reel. After this, the display appears as below.
Page 5: About Maintenance
Maintenance About maintenance This is a washable reel. Wash away salt residue and grit after fishing Maintenance procedure Wash the reel with a dish washing detergent and a soft sponge. Do not use solvents. Do not use soap or other detergents. Other soaps or solutions may damage the reel both externally and internally.
Page 6 Maintenance Handling and maintenance of the power cord Follow the restrictions below to avoid cord problems. Do not cut or connect your cord by yourself as it can cause unintended problems. Do not hang the reel Do not wind the power by the power cord.
Page 7: Names And Functions Of Each Part
Names and functions of each part Free spool adjustment strong weak Power lever Waterproof tournament loosen tighten drag Push ON clutch button Level wind One hand clutch lever Enclosed items Reel seat protector pursuetheoutdoors.com/schematics Power cord Storage bag Reel guard oil Levelwind threader Manual CD-R...
Page 8: Enclosed Items
Names and functions of each part Free spool adjustment - It adjusts brake tension on the spool to prevent backlash or line slack caused by dropping the line with hook and sinker. Power lever - You can freely adjust winding power, or winding speed, from zero(ON/OFF) to maximum, by 32 steps, by using the lever.
Page 9: Mode Button
Names of the buttons and the display RESET BUTTON INVERSE COUNTER BUTTON JIG/PICKUP BUTTON MODE BUTTON Depth counter Mode display Inverse counter Chumming timer (Power indicator, time to wind up, timer display) RESET BUTTON This button resets the depth counter to zero. The chumming timer is reset.
Page 10 Names of the buttons and the display JIG/PICKUP BUTTON Selection between pickup and jigging can be done in the mode setting display.(One of them should necessarily be chosen.) Pickup -You can wind only while pressing this button. This function is useful to wind up line slack and attract fish. -Winding speed can be changed within the range of 0-Hi with the mode setting display.
Page 11 Line data input (Daiwa braided line) All you have to do is just to input line data spooling the reel with Daiwa Braided Line. It is a useful method because it requires less data input. Run line through the levelwind guide and tie it onto the spool.
Page 12 (JIG/PICKUP) BUTTON. This completes the operation and returns to (0.0m). The SEABORG 300FB has data PE4-300m for the above Daiwa braided lines stored in the reel’s memory. Therefore, when winding these lines, there is no need for additional data input.
Page 13 Line data input (When line length is known) This method is used when the line length is known before winding. In the example below, PE4-250m is wound. Run line through the levelwind guide and tie it onto the spool. Levelwind Guide The levelwind threader makes this process easier.
Page 14 Line data input (When line length is known) Pull the lever back to the OFF position, after winding. Do not reel in the end of the line Power lever Do not wind the end of the line onto the spool because it causes incorrect length calculation.
Page 15 Line data input (With backing line) This method requires use of Daiwa braided line that is color coded to show length and has a total length greater than 100 m. Run the backing line through the levelwind guide and tie it onto Levelwind Guide the spool.
Page 16 Line data input (With backing line) When the line length input screen appears, press the MODE (JIG/PICKUP) BUTTON again to let the back line 1 input screen appear. will be blinking. Wind on another 100 m of line, keeping line tension at the suggested level.
Page 17 Line data input (Inputting the drawer) This method is applied to data re-input which is to be made after the main line is wound up. This method requires a main line of 100m or longer specific length. Turn on the electricity. While “0.0”...
Page 18 Line data input (Inputting the drawer) Press the RESET BUTTON for 2 seconds. This will show the digits in the lower area of the counter. Pull an additional 50m of line from the spool. Press the RESET BUTTON for 2 seconds to show 100.0 the upper counter.
Page 19 Functional setting operation (1. Mode setting display) How to set the many functions available There are many useful functions in the mode. While “0.0” is shown in the display, press INVERSE COUNTER BUTTON JIG/PICKUP BUTTON simultaneously and hold for 2 seconds, until the display shows on left area of the display.
Page 20 Functional setting operation (1. Mode setting display) Use the power lever to set numerical values. Power lever At its MAX position, numbers count upward rapidly. At the OFF position, numbers count downward rapidly. Around mid position, numbers change at a slower pace. Press MODE BUTTON to complete the setting.
Page 21 Functional setting operation (2. Before you begin fishing.) Surface depth setting Before you begin fishing, make sure the counter is set to zero at the waterʼs surface. This is extremely important to ensure accurate fishing depth readings. Connect the reel to the battery, put the line through all the guides, and prepare your terminal rig.
Page 22 Functional setting operation (3. Auto stop function) Auto stop setting The Auto stop depth may be set to meet your own specific needs. - Auto stop adjusts to operate at depths from 1 m to 5 m (in 10 cm increments). - It prevents accidentally winding swivels, terminal rigs etc.
Page 23 Functional setting operation (3. Auto stop function) Auto stop Auto stop automatically brings your terminal rig to the surface, stopping consistently at your pre-set depth preference. It eliminates the need to constantly monitor depth as it comes up. - The auto stop function assists when winding with the power lever, jigging, or winding with the chumming timer. - After the rig is ready, reset the depth counter to zero by pressing the RESET BUTTON.
Page 24 Functional setting operation (4. Line feeding function) Line feeding function The line feeding function lets our line with the motor assisting the spool. Simultaneously hold down the INVERSE COUNTER BUTTON and the MODE (JIG/PICKUP) BUTTON to display the setting mode. Then, press the MODE (JIG/PICKUP) BUTTON display the “line feeding output adjustment”...
Page 25 Functional setting operation (5. Inverse counter) Inverse counter Two counters are better than one. This reel has counters from both the surface and from the bottom. In the following example, intended fishing range is 94 m, which is 6 m from the bottom. Clutch OFF to send the rig to the bottom At the bottom, move the clutch to ON by turning the reel handle or flipping the clutch lever.
Page 26 Functional setting operation (6. Chumming timer ) Chumming timer This function provides a useful timer. - This function displays the time passed after the presentation of your bait or lure. It can be used for chumming, jigging timing or reeling in your rig. - The chumming timer starts from 7.0 m on the counter, unless a specific fishing range has been entered into memory.
Page 27 Functional setting operation (7. Chumming timer winding) Chumming timer winding The chumming timer helps ensure you check baits at even intervals, a real help when dropping multiple lines. - After pre-set 5 minutes have passed, the reel automatically winds up. T - When the timer is set, the timer indicator is shown in the...
Page 28 Functional setting operation (7. Chumming timer winding) Press MODE BUTTON (JIG/PICKUP BUTTON).When the display goes back to depth counter, then the procedure is completed. will be lighting. The time set can be checked by pressing the INVERSE COUNTER BUTTON. If the INVERSE COUNTER BUTTON and the chumming timer are simultaneously in use, auto winding is possible within the...
Page 29 Functional setting operation (8. Jigging) Jigging Jigging is an extremely valuable function. While “0.0” is shown in the display, press INVERSE COUNTER BUTTON JIG/PICKUP BUTTON simultaneously and hold for 2 seconds, until the display shows on left area of the display.
Page 30 Functional setting operation (9. Jigging master) Jigging master You can choose the jigging pattern, range, waiting time and length you require. - Pressing the JIG/PICKUP BUTTON, starts jigging, with the display showing the indicator. (Pressing the button once more cease jigging.) The power lever controls jigging speed. - Shifting of jigging speed is done easily with the lever control.
Page 31 Functional setting operation (9. Jigging master) 3. Waiting time You can choose the waiting time between jigs. The interval time is set in seconds. Example) Three-step jigging Three-step jigging (Preference setting) 5 seconds interval time MODE BUTTON Interval time (5sec) Three-step jigging Interval time (5sec)
Page 32 Functional setting operation (10. Display revision) Display revision You can recalibrate the counter should it not indicate an accurate depth compared to depth markings on your line. The counter setting can be changed while fishing. Example below is the case in which, though the counter shows 103 m, color markings on the line indicate 100 m.
Page 33 Functional setting operation (10. Display revision) Move the power lever to change the displayʼs reading to 100.0. (Occasionally, for the revision rate, the exact number cannot DOWN be attained.) Setting exactly to 100.0 may be difficult. If so, set the display as close as possible.
Page 34: Display Light
Functional setting operation (11.Useful functions) Various alarms Many kinds of information are indicated by audible alarms. Power lever alarm - Placing the Power lever at MAX or OFF positions evokes an alarm. Auto stop alarm - While winding up, starting 6 m below the auto stop depth, an alarm beeps at two meter intervals. Upon reaching the auto stop depth, a long alarm sounds.
Page 35: Reel Specifications
Reel Specifications Reel Specification list Product name SEABORG 300FB Product code 40801241 Gear ratio(manual winding) 4.8 : 1 Weight (g)/(oz) 530 g / 18.7 oz Max Drag power (kg)/(lb) 8kg/17lb Line Capacity (m) DAIWA BRAIDED BRAIDED PE3(40lb)-400m(450yds) 30lb-400m(450yds) PE4(55lb)-300m(330yds) 40lb-300m(330yds)
Page 36: Parts List
Parts List SEABORG 300FB SEABORG 300FB Parts No, Parts Name Parts No, Parts Name Parts No, Parts Name 6G696201 FRAME 6F853501 MECHANICAL BRAKE WASHER(A) 63424001 POWER LEVER NUT 6F823603 SPACER(R) 63749102 MECHANICAL BRAKE WASHER(B) 6G673001 POWER LEVER 6F823703 SPACER(L) 6G503501 SET PLATE 6B962701 POWER LEVER NUT 6G202701...
Page 37: Troubleshooting
Trouble shooting Ref. Symptom Possible causes To do page It is a normal function to avoid over winding. Press RESET BUTTON The counter displays continue winding. Motor does not respond to the Did not pull the lever to OFF Pull the lever to OFF and then move power lever position.
Page 38: Limited Warranty Terms
Reference COMPANY DAIWA CORPORATION NAME 12851 MIDWAY PLACE ADDRESS CERRITOS CA 90703 U.S.A TEL NO. (562)-802-9589 LIMITED WARRANTY TERMS WARRANTY WILL EXPIRE WHEN ONE OF THE FOLLOWING HAS BEEN SURPASSED. *ONE YEAR FROM DATE OF ORIGINAL PURCHASE. *200 TOTAL HOURS OF USE.
