Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2021 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
21c
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Harbor Freight Tools drillmaster 91062n
Summary of Contents for Harbor Freight Tools drillmaster 91062n
- Page 1 No portion of this manual or any artwork contained herein may be reproduced in Failure to do so can result in serious injury. any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing SAVE THIS MANUAL.
-
Page 2: Table Of Contents
table of contents Safety ............2 Maintenance ..........14 Specifications ..........8 Parts List and Diagram ......18 Setup ............8 Warranty ............ 20 Operation ............ 9 WarninG SyMBOLS anD DEFinitiOnS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. -
Page 3: Safety
Electrical Safety 1. power tool plugs must match the outlet. 4. Do not abuse the cord. never use the cord never modify the plug in any way. for carrying, pulling or unplugging the Do not use any adapter plugs with grounded power tool. - Page 4 If unreadable or missing, contact loss of control and serious injury. Harbor Freight Tools for a replacement. 2. Hold the power tool by insulated gripping 12. Avoid unintentional starting. surfaces only, because the cutter may contact Prepare to begin work before turning on the tool.
- Page 5 Vibration Safety This tool vibrates during use. 2. Do not smoke during use. Nicotine reduces Repeated or long-term exposure to vibration may the blood supply to the hands and fingers, cause temporary or permanent physical injury, increasing the risk of vibration-related injury. particularly to the hands, arms and shoulders.
- Page 6 Grounding tO prEVEnt ELEctric SHOcK anD DEatH FrOM incOrrEct GrOunDinG WirE cOnnEctiOn: check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the tool. never remove the grounding prong from the plug.
- Page 7 Extension cords 1. Grounded tools require a three wire extension cord. 7. Make sure the extension cord is properly wired Double Insulated tools can use either and in good electrical condition. Always replace a two or three wire extension cord. a damaged extension cord or have it repaired by a qualified electrician before using it.
-
Page 8: Specifications
Specifications Electrical Requirements 120VAC / 60Hz / 5.5A Drum Speed 16,000 RPM Cutting Speed 32,000 Cuts per minute (2-knife drum) Max. Planing Width 3-1/4" Max. Planing Depth 1/16" Per Pass (Adjustable) Number of Blades Setup - Before use: read the EntirE iMpOrtant SaFEty inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. -
Page 9: Operation
Operating instructions read the EntirE iMpOrtant SaFEty inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. tool Set up tO prEVEnt SEriOuS inJury FrOM acciDEntaL OpEratiOn: Make sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section. - Page 10 9. Place a straight edge or straight piece of wood c. Locate the Set Screws (33) on the along one of the side surfaces of the Front and Knife Holder. See Figure F:. Rear Base Plates. Slide the Knife against the Set Screws straight edge or piece of wood so that it aligns (33)
- Page 11 Depth adjustment The Planer may be adjusted to cut to a depth of up to 1/16" per pass along the workpiece. • To increase the depth of cut, nOtE: For a rough-cut workpiece use a deeper cut, turn the Depth Knob clockwise. but do not exceed 1/16".
- Page 12 Workpiece and Work area Set up 1. Designate a work area that is clean and well lit. 3. Secure loose workpieces using a vise or clamps The work area must not allow access by children (not included) to prevent movement while working. or pets to prevent distraction and injury.
- Page 13 rabbeting Rabbeting is creating a step on the edge of a workpiece. 2. Set the Fence to determine the Rabbeting is typically used in door and window jambs. width of the rabbet cut. When rabbeting, the Rabbet Depth Gauge will 3.
-
Page 14: Maintenance
Maintenance and Servicing procedures not specifically explained in this manual must be performed only by a qualified technician. tO prEVEnt SEriOuS inJury FrOM acciDEntaL OpEratiOn: Make sure that the trigger is in the off-position and unplug the tool from its electrical outlet before performing any procedure in this section. - Page 15 replacing the Belt Before beginning, turn the Depth 4. Place the new Belt around the Large Pulley, Adjustment Knob to the “0” setting. making sure that the Belt is centered on the Pulley. See Figure L. 1. Remove the Screws (3) that attach the Belt Cover (2) to the Planer, then remove the Belt Cover.
- Page 16 troubleshooting problem possible causes Likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker. If breaker is tripped, make sure circuit is right capacity for tool and circuit has no other loads.
- Page 17 pLEaSE rEaD tHE FOLLOWinG carEFuLLy THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
-
Page 18: Parts List And Diagram
parts List and Diagram parts List part Description part Description Brand Label Switch Spring (2) Belt Cover Button Connector Screw Pin Ø2.5 Small Pulley Switch Spring (3) Bearing Screw St4x13 Screw Handle Cover Washer Trigger Spring (1) Ring (a) Trigger Belt Air Reflector Left Housing... - Page 19 assembly Diagram Item 91062 Page 19 For technical questions, please call 1-888-866-5797.
-
Page 20: Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
