Accel Hobby
Pitts S2C ARF
Electric Almost-Ready-To-Fly 3D Aerobatic Model
Instruction Manual
READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION. IT CONTAINS IMPORTANT INSTRUCTIONS AND
WARNINGS CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.
Electric Almost-Ready-to-Fly 3D Aerobatic Model
TOTAL LENGTH
WING SPAN
FLYING WEIGHT
MOTOR
32 in
28 in
14-16 ounces
Himax 2015, 2025, Razor
350 or equiv
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pitts S2C ARF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Accel Hobby Pitts S2C ARF

Summary of Contents for Accel Hobby Pitts S2C ARF

  • Page 1 Accel Hobby Pitts S2C ARF Electric Almost-Ready-To-Fly 3D Aerobatic Model Instruction Manual Electric Almost-Ready-to-Fly 3D Aerobatic Model TOTAL LENGTH 32 in WING SPAN 28 in FLYING WEIGHT 14-16 ounces Himax 2015, 2025, Razor MOTOR 350 or equiv READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION. IT CONTAINS IMPORTANT INSTRUCTIONS AND...

  • Page 2: Table Of Contents

    Academy of Model Aeronautics 5151 East Memorial Drive Table of Contents Muncie, IN 47302-9252 Tele. (800) 435-9262 Fax (765) 741-0057 Or via the Internet at: http://www.modelaircraft.org Introduction……………………………………………..2 Important Safety Precautions ........2 Decisions You Must Make..........3 Engine Selection.............3 Radio Equipment ............3 Protect your model, yourself and Additional Items Required...........3 Hardware and Accessories..........3...

  • Page 3: Decisions You Must Make

    Additional Items Required Hardware Four-Channel Radio with four micro servos (9 gram) © 2004 Accel Hobby "Y" Harness for Aileron Motor - See Motor Selection All rights reserved. Propeller(refer to your engine's instructions for proper size)

  • Page 4: Kit Contents

    Kit Contents Before starting to build, use the Kit Contents list to take an inventory of this kit to make sure it is complete and inspect the parts to make sure they are of acceptable quality. If any parts are missing or are not of acceptable quality, or if you need assistance with assembly, contact our support staff.

  • Page 5: Wing Assembly

    Wing Assembly Trim away the covering from the 2 servo mounting holes on the lower wing and then slide the lower wing into the fuselage cutout and get it centered by using a piece of string. Tape the string to the tail of the aircraft and mark the distance from one wingtip and use that mark to line up the other wingtip.
  • Page 6 Before mounting the lower wing use a pencil and lightly draw a line through the lower wing mount that exactly cuts the cutout in half. This is the incidence of the lower wing. Make sure the pencil mark is visible on the fuselage because we will need it to set the incidence of the upper wing.

  • Page 7: Install The Stabilizer And Elevator

    Horizontal Stabilizer Assembly The next piece to be assembled is the horizontal stabilizer. Slide it into the slot in the rear of the fuse and use a ruler or tape measure to make sure you have equal amounts on each side of the fuse..in other words, make sure it's in the center! It is recommended that you use a square to make sure the horizontal stabilizer was sitting square to the fuse.

  • Page 8: Install The Fin And Rudder

    Control Surface Assembly You have 2 options for mounting the control surfaces: The supplied CA hinges or tape. Using CA Hinges Using your knife, cut slots in the ailerons, elevator and rudder and the corresponding location in the wing, vertical stabilizer and horizontal stabilizer.

  • Page 9: Radio Installation

    Radio Installation The picture on the right shows the locations for the receiver, speed control and aileron servos. The other picture shows the rudder and elevator servo locations in the fuselage. The receiver can be hot glued or taped on using double sided tape.
  • Page 10 The servos go in the lower wing and we use pushrods connecting the lower ailerons to the upper ailerons. Locate the balsa mounting blocks in the upper and lower ailerons and mount the control horns. Put the lower control horn as close to the inner edge of the balsa block and the upper control horn as close to the trailing edge as possible.

  • Page 11: Motor And Battery Installation

    Motor and Battery Installation Landing Gear Installation (Optional) This plane is designed for the GWS style “motor on a stick” mount system. If you are using a different mounting system or On this plane, landing gear is optional. Due to the light weight, outrunner motor you will have to modify the nose of the plane to you can easily land on grass or other soft surfaces without accept the motor of your choice.

  • Page 12: Final Assembly

    Control Throw Adjustment Control Surface Throws By moving the position of the clevis at the control horn toward Note: Throws are measured at the widest part of the elevators, the outermost hole, you will decrease the amount of throw of rudder and ailerons.

  • Page 13: Balance Your Model

    Balance Your Model Construction Checklist □ Wing Assembly and Installation □ Note: This section is VERY important and must NOT be Install the Stabilizer and Elevator omitted! A model that is not properly balanced will be unstable and possibly unflyable. □...
