TP499
Infinity Leap Trampoline
Instructions for assembly, maintenance and safe use.
We constantly strive to improve our assembly instructions. To see the most current version of this
instruction for assembly, maintenance and safe use. Please visit the product page at tptoys.com
Patent GB2516510B
Patent Pending PCT/GB2018/053589
TP499 Infinity Trampoline_Ritter IN0499CH Issue-E 10.21.indd 1
TP499 Infinity Trampoline_Ritter IN0499CH Issue-E 10.21.indd 1
Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
www.tptoys.com
WARNINGS!
THIS PRODUCT CONTAINS SMALL PARTS
AND IS NOT SUITABLE FOR CHILDREN
UNDER 36 MONTHS. SMALL PARTS ARE A
CHOKING HAZARD.
ONLY FOR DOMESTIC USE. FOR OUTDOOR
USE ONLY.
TOY MUST BE ASSEMBLED BY AN ADULT
BEFORE USE.
CHILDREN MUST NOT USE THE EQUIPMENT
UNTIL PROPERLY INSTALLED.
ADULT SUPERVISION IS REQUIRED.
ONLY ONE USER. COLLISION HAZARD.
REMOVE ALL PACKAGING BEFORE GIVING
TO YOUR CHILDREN.
RETAIN PACKAGING FOR FUTURE
REFERENCE.
SHOES NOT TO BE WORN WHILE JUMPING.
ALWAYS CLOSE THE NET OPENING BEFORE
JUMPING
4 Hrs
x2
Build Time
ALWAYS JUMP IN THE MIDDLE OF THE MAT.
DO NOT EAT WHILE JUMPING.
DO NOT EXIT BY A JUMP.
DO NOT USE THE MAT WHEN WET.
EMPTY POCKETS AND HANDS BEFORE
USING THE TRAMPOLINE.
LIMIT THE TIME OF CONTINUOUS USAGE
(MAKE REGULAR STOPS).
DO NOT USE IN STRONG WIND CONDITIONS
AND SECURE THE TRAMPOLINE.
THE NET SHOULD BE REPLACED EVERY 2
YEARS.
THIS PRODUCT IS INTENDED FOR USE BY
CHILDREN AGED 6 YEARS +.
WARNING: MAXIMUM SINGLE USER
WEIGHT 120KG
