Summary of Contents for VWR UV-A
- Page 1 UV Hand Lamps Instruction Manual 81-0315-01 Rev A...
- Page 2 UV Blocking Eyewear should be worn as well. Additional UV protective wear can be ordered including spectacles, goggles and faceshield. UV Hand Lamp Specifications Dimensions: 11.9”L x 2.5”H x 3.8”W (302 x 64 x 97 mm) Model Part Number Volt/Hz/Amp Wavelength___________ UV-A 89131-488 115/60/0.32 365nm (two tubes) 89131-490 230/50/0.32 UV-AC 89131-492 115/60/0.16...
- Page 3 UV Hand Lamps Page 3 Operation Safety Precautions Shortwave and midrange UV radiation will cause damage to unprotected eyes and skin. Before operating any unit, be sure all personnel in the area are properly protected. UV Blocking Eyewear should be worn as well. Using the Lamp Plug power cord into a properly grounded electrical outlet.
- Page 4 UV Hand Lamps Page 4 Service Procedures Cleaning and Care Clean unit surface with a damp soft cloth or sponge. Never use abrasive cleaners (can damage the UV filter surface). Replacing Tubes Disconnect the lamp from the electrical supply before replacing tubes. Remove the two Phillips Head screws located in the end cap.
- Page 5 Reassemble the lamp. Do not pinch wires during assembly. Replacement Parts/Accessories For replacement parts or components not shown here, please call VWR Customer Service at (800) 932- 5000. Please have the lamp model available when you call. Replacement Part Description...
- Page 6 UV Hand Lamps Page 6 Warranty UVP's quality instruments are guaranteed to be free of defects in materials, workmanship, and manufacture for one (1) year from date of purchase. Transilluminators are similarly warranted for two (2) years from the date of purchase. Consumable and disposable products, including, but not limited to lamps or light tubes, filters, or rechargeable batteries are guaranteed to be free from defects in manufacture and materials for ninety (90) days from date of purchase.
