- Page 1 PRT-MNR2-DIN Protege Module Network Repeater Installation Manual...
- Page 2 Protege® Logo are registered trademarks of Integrated Control Technology Limited. All other brand or product names are trademarks or registered trademarks of their respective holders. Copyright © Integrated Control Technology Limited 2003-2021. All rights reserved. Last Published: 28-Oct-21 10:50 AM PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual...
-
Page 3: Table Of Contents
Power Indicator Status Indicator Fault Indicator Ethernet Indicator COM Indicators Mechanical Diagram Mechanical Layout Technical Specifications New Zealand and Australia European Standards FCC Compliance Statements Industry Canada Statement Disclaimer and Warranty PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... - Page 4 PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual...
-
Page 5: Introduction
The current features of the network repeater include: ⦁ 3 isolated RS-485 connections ⦁ 10/100 ethernet ⦁ RS-485 or ethernet network expansion ⦁ Secure encrypted RS-485 module communications PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 6: Installation Requirements
Installation Requirements This equipment is to be installed in accordance with: The product installation instructions ⦁ AS/NZS 2201.1 Intruder Alarm Systems ⦁ The Local Authority Having Jurisdiction (AHJ) ⦁ PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 7: Grounding Requirements
(RS-485 N+, N-, NA, NB) DIN Rail Enclosure Additional DIN Rail Enclosure(s) Controller Reader Expander Dialer’s Earth Ground Connection Input Expander Power Supply Output Expander AC Mains Wiring Earth Ground Link Connection PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... - Page 8 Sector or Building #3 Note that the DIN rail enclosure earth terminal is connected to the power supply V- terminal. There must be only one single earth grounding point per system. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual...
-
Page 9: Mounting
A Protege DIN rail module can be removed from the DIN rail mount using the following steps: Insert a flat blade screwdriver into the hole in the module tab clip. Lever the tab outwards and rotate the unit off the DIN rail mount. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 10: Power Requirements
Note that there is no onboard regulation or isolation for these outputs; they are a fused feed-through from the N+ N- input terminals. When using these outputs to supply other devices, be sure not to exceed the rating of the internal fuses as outlined in the Technical Specifications (see page 24). PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 11: Powering The Spurs
Power Supply V1+ V1+ V1+ V1+ V1+ V- V- NB NA N- N+ N- Module Network Repeater Mains Input To other Modules on Network Gel Cell Backup Batteries PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 12: Encrypted Module Network
Network Power Supplied By Network Module: + AUX - Z1 COM AUX power from module or external power supply Controller or module supplying power to networked devices Next module on network PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 13: Module Wiring
330R 330R From Next Previous Module Module The PRT-MNR2-DIN Module Network Repeater would typically be the first module on the RS-485 module network, but this may not always be the case. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 14: Ethernet 10/100 Network Connection
Always consult the network or system administrator and ask them to provide you with a fixed IP address that can be assigned to the module. Ethernet 10/100 Switch Hub Connection: Temporary direct connections can be used for onsite programming by using a standard ethernet cable. Ethernet 10/100 Direct Connection: PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 15: Network Expansion
The ethernet solution enables the network repeater to communicate via UDP through a switch or router. Expander Keypad Switch / Router Expander Controller Network Expander Expander Keypad Main RS-485 Module Network Expander Expander Isolated RS-485 Networks PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... - Page 16 With RS-485 you can insert the network repeater anywhere within the LAN to strengthen communications or resolve network issues. Network Expansion using RS-485: Keypad Expander Expander Controller Expander Network Expander Keypad Expander Main RS-485 Network Isolated RS-485 Networks PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual...
-
Page 17: Network Repeater Configuration
Programming the IP address, subnet mask, and default gateway requires knowledge of the network and subnet that the system is connected to. You should always consult the network or system administrator before programming these values. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... - Page 18 UDP mode: When UDP is selected, all of the RS-485 ports can be used to connect to isolated module networks*. All ICT module network packets received on the RS-485 connections will be forwarded to the controller over UDP to the IP and port specified in the configuration.
-
Page 19: Device Information
To edit a user, click on the appropriate checkbox, then click Edit. This opens a new page where the user settings can be changed. For security reasons, we recommend you change the password of the admin user before deployment. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 20: Led Indicators
The ethernet indicator will show the status of the ethernet connection. State Description Constantly on (green) 'Live' ethernet connection detected Constantly off No ethernet connection detected Continuous (green) fast flash Ethernet packet transmitted/received PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 21: Com Indicators
COM Indicators The COM indicators shows the status of the three COM ports. State Description Constantly on (red) COM port is not powered Constantly on (green) COM port is powered PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 22: Mechanical Diagram
NB NA N- N+ COM3 COM2 POWER Status Indicators ETHERNET COM2 COM3 COM Port Indicators STATUS FAULT COM1 N+ N- NA NB 12VDC IN /OUT RS 485 NETWORK ETHERNET RS-485 COM Port Ethernet Connection PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 23: Mechanical Layout
Mechanical Layout The mechanical layout shown below outlines the essential details needed to help ensure correct installation and mounting. All measurements are shown in millimeters. 78.40 Front 78.40 39.20 39.20 Back 67.18 PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 24: Technical Specifications
Integrated Control Technology continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (www.ict.co) for the latest documentation and product information. -
Page 25: New Zealand And Australia
New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 26: European Standards
Tests EMC (operational) according to EN 55032:2015 Radiated disturbance EN 55032:2015 Power frequency magnetic field immunity tests (EN 61000-4-8) EN50131 In order to comply with EN 50131-1 the following points should be noted: PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... - Page 27 ATTACK, comply with the EN 50131 standards. Tamper protection against removal of the cover as well as removal from mounting is provided by tamper switch. Warning: Enclosures supplied by 3rd parties may not be EN50131-compliant, and should not be claimed as such. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual...
-
Page 28: Fcc Compliance Statements
NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 29: Industry Canada Statement
Industry Canada Statement ICES-003 This is a Class A digital device that meets all requirements of the Canadian Interference Causing Equipment Regulations. CAN ICES-3 (A)/NMB-3 (A) PRT-MNR2-DIN | Protege Module Network Repeater | Installation Manual... -
Page 30: Disclaimer And Warranty
Integrated Control Technology Ltd nor its employees shall be liable under any circumstances to any party in respect of decisions or actions they may make as a result of using this information. In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice. - Page 31 In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
