Summary of Contents for Maag Audio PREQ2
- Page 1 PREQ2 ™ DUAL MIC PREAMP WITH EQ / AIR BAND ® USER MANUAL WWW.MAAG.AUDIO COPYRIGHT © 2022 MAAG AUDIO, LLC...
-
Page 2: Product Registration
PRODUCT REGISTRATION Please complete the product registration form for your Mäag Audio equipment to be registered for warranty and product updates. CLICK HERE TO REGISTER NOW PROTECT YOUR EQUIPMENT We will keep the model number and date of purchase of your new Mäag Audio product on file to help you refer to this information in the event of an insurance claim such as loss or theft. -
Page 3: Safety Instructions
Refer all servicing to a qualified service apparatus has been exposed to rain or moisture, engineer, through the appropriate Maag Audio does not operate normally, or has been dropped dealer. 13. CAUTION: To disconnect the unit complete- ly from the MAINS, unplug the unit. - Page 4 FEATURES: · The PREQ2™ uses a mic input transformer tuned for clarity, detail, and transparency. · The Instrument Input is designed to receive signals from many sources or instruments. · Includes the mythical Air Band® shelf boost used on countless hit records.
-
Page 5: Technical Specifications
MICROPHONE PREAMP The Mäag Audio two channel PREQ2™ uses a microphone input transformer tuned for clarity, detail, and transparency. This transformer provides a signal voltage gain of 4.87dB and is paired with amplifier electronics to obtain a maximum gain of +71dB. 71dB gain dual channels with infinite variable settings. - Page 6 EQ SECTION The PREQ2™ has three equalizer/filters sections; the layout and control compliment are iden- tical for both channels. The equalizer design is specifically designed for both recording and/or subtle touchup tonality changes and euphonic enhancements. On the left side of the channel is the first control for the 2nd order, 12dB/octave high pass filter.
- Page 7 LINE INPUT: Balanced XLR inputs. Line Input Switch w/Green LED: Routes Line Input through High Pass Filter and 2-band EQ section to Balanced XLR Line Out connectors. COPYRIGHT © 2022 MAAG AUDIO, LLC...
-
Page 8: Warranty And Registration
The express warranty will not apply tion of Maag Audio, free of charge. All warranty to defects or damage caused by post purchase service will be conducted through authorized shipping and transportation, storage, careless Maag Audio dealers only. - Page 9 Mäag Audio, LLC...
