10/21
Product Code: 1032T
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment
by
Trade" reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
professional
users.
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
AIR CONDITIONER
Specifications:
•
Cooling Capacity: 4.5KW / 15300Btu
•
Power Unit: 240V 50Hz
Rated Power: 2000W
•
•
Rated Current: 9.0A
•
Max. Air Flow: 800m3 per hour
•
Noise Level: 60dB(A)
Operating Temperature: 18° - 45°C
•
•
Suction Pressure: 2.5Mpa (Max.)
•
Discharge Pressure: 4.5Mpa (Max.)
•
Speed Control: 2-speed
Refrigerant: R410/800g
•
Condensation Tank Capacity: 8 Litres
•
•
Castor Wheels: 75mm Dia (2 with
brakes)
•
Dimension: 1035(H) x 520(W) x 480(D)
Nett Weight 70kg
•
•
Carton 1of2: 1110 x 610 x 570mm
•
Carton 2of2: 370 x 350 x 260mm
Gross Weight 78kg
•
With
proven
and
Product Code: 1032T
trusted "Made
for
the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1032T and is the answer not in the manual?

Questions and answers

Related Manuals for TradeQuip 1032T

Summary of Contents for TradeQuip 1032T

  • Page 1 Carton 1of2: 1110 x 610 x 570mm • Carton 2of2: 370 x 350 x 260mm Gross Weight 78kg • About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made...

  • Page 2: Table Of Contents

    10/21 Product Code: 1032T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works.

  • Page 3: Standard Operating Procedure

    • Servicing must be carried out by a qualified service technician. Use only TradeQuip identical replacement parts. Use of any other parts will void the warranty. Ensure the Air Conditioner is disconnected from power before servicing. •...

  • Page 4: Operation, Preventitive Maintenance

    All models are equipped standard with heavy- duty castors for easy portability. TradeQuip Portable Industrial Air Conditioners bring in air from an outside source to cool its condenser, cycling hot air to an outside source. This provides a fresh cool air room temperature with high efficiency. Just wheel it in, plug it in and it goes to work immediately, giving high cooling capacity to help wherever and at whatever point you require it.
  • Page 5 10/21 Product Code: 1032T 2. BEFORE USE Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked joins and damaged, loose, or missing parts. If the supply cord is damaged, it must be replaced by the manufacturer, service agent or similarly qualified persons in order to avoid a hazard.
  • Page 6 10/21 Product Code: 1032T Minimum Clearance When the appliance is running, ensure the filter screen and the cold air ducting are 300mm minimum from the wall or other obstacles, and the hot exhaust pipe is 900mm minimum from the ceiling or other obstacles.

  • Page 7: Troubleshooting

    10/21 Product Code: 1032T 5. STORAGE This Air Conditioner should always be stored in a dry location on a level surface in an upright position. When you stop using this Air Conditioner, you should clean the filter and keep it in a dry place, be careful not to damage the Air Conditioner or filter.

  • Page 8: Parts Diagram & Parts List

    10/21 Product Code: 1032T PARTS DIAGRAM & PARTS LIST Part # Description Part # Description Part # Description Connector 1 Wind Mill 1 Tank Cover Plate Cooling Tube Cold Wind Spiral Case Condensation Tank Tube 1 Connect Bracket Chassis Tube 1 Fix Frame...

  • Page 9: Warranty

    WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
