- Page 1 Prius Brief Guide...
-
Page 3: Table Of Contents
Instrument Cluster Introducing Prius Thank you for buying a Prius. We trust this Brief Guide will enable you to become familiar with your vehicle’s basic operations and assist you in enjoying your vehicle. This brief guide does not replace or substitute the Owner’s Manual, which you will find in the vehicle’s glove compartment. -
Page 4: High Voltage Components
High voltage components 1. Air conditioning compressor. 5. Service plug. 2. High voltage cables (orange colour). 6. Hybrid battery (Traction battery). 3. Power control unit and DC/DC converter. 7. Electric motor (Traction motor). 4. Caution label. Take care when handling the hybrid system, as it contains a high voltage system and some parts become extremely hot. -
Page 5: Accessing Your Vehicle
Accessing your vehicle Smart entry & start system 1. Electronic keys - Operate smart entry & start system - Operate the wireless remote control function 2. Mechanical keys 3. Key number plate Lock all doors and boot/rear door Unlock all doors and boot/rear door The wireless remote control can be used to lock and unlock your vehicle from the outside. -
Page 6: Electric Windows And Windows Lock
Electric windows and windows lock The electric windows can be opened and closed as follows: 1. One touch closing* *Pushing the switch in the opposite 2. Closing direction will stop the window travel 3. One touch opening* partway 4. Opening Pressing the switch (right) locks the passenger windows... -
Page 7: Seat And Seat Belt Adjustment
Seat and seat belt adjustment Front seats 1. Seat position adjustment lever. 2. Seatback angle adjustment lever. 3. Vertical height adjustment lever*. 4. Lumbar support adjustment switch*. *: For driver's side Head restraint height adjustment Press and hold Pull to move The centre of the head lock release to upwards. -
Page 8: Steering Wheel Adjustment
Steering wheel adjustment Steering wheel Hold the steering wheel and press the lever down. Adjust the position by moving the steering wheel horizontally and vertically. Adjust to the ideal position by moving the steering wheel horizontally and vertically. After adjustment, pull the lever up to secure the steering wheel. -
Page 9: Instrument Panel Overview
Instrument Panel Overview Headlight switch Windscreen wipers and Indicator lever washer switch. Fog light switch* Rear window wiper and washer switch Gauges and meters Multi-information display Navigation system* Audio system* Bonnet opener Hazard Light Switch Parking brake pedal Fuel filler SRS knee airbag door opener Tilt and telescopic steering lock release lever... -
Page 10: Multi-Information Display
Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the clock. Gauges and meters The following gauges and meters illuminate when the “POWER” switch is in ON mode. 1. Fuel gauge Displays the quantity of fuel remaining in the tank. -
Page 11: Instrument Cluster
There may be a malfunction if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota Centre. Lights The headlights can be operated manually... -
Page 12: Wipers
Wipers Wiper with interval adjuster Wiper interval can be adjusted for intermittent operation when is selected). 1. Intermittent wiper operation. 2. Low speed wiper operation. 3. High speed wiper operation. 4. Temporary operation. 5. Intermittent frequency. Wiper with rain-sensing function (AUTO) With ‘‘AUTO’’... -
Page 13: Power (Ignition) Switch
Power (ignition) switch Starting the hybrid system Check that the parking brake is set. Sit in the driver’s seat and firmly depress the brake pedal. The POWER switch indicator turns green. If the shift position is “N”, the hybrid system cannot start. -
Page 14: Heating, A/C And De-Misting
Heating, A/C and de-misting Airflow and outlets are automatically adjusted according to the temperature setting. Temperature Fan speed display Air outlet display setting display Temperature control Fan speed control Windscreen demister Pollen removal Automatic mode mode Changes the air outlets used Outside air or Air conditioning ON/OFF switch recirculated air mode... -
Page 15: Setting The Clock
Setting the clock Setting the clock Select “CLOCK” by pressing the “DISP” switch. Press and hold the “DISP” switch to enter the setting mode. Select “12h” or “24h” by pressing the “DISP” switch. Press and hold the “DISP” switch to finish setting. 1. -
Page 16: Gear Change
Gear change Shift position Function Parking the vehicle or starting the hybrid system Reversing Neutral Normal driving Engine braking position* *Shown only while in “D” position When shifting to “D” or “R”, move the shift lever along the shift gate. To shift to “N”, slide the shift lever to the left and hold it. -
Page 17: Fuel Tank Opening
Fuel tank opening Opening the fuel tank cap Turn the fuel tank cap slowly to open. Hang the fuel tank cap on the back of the fuel filler door. Pull the lever. Take care to select the correct fuel. Bonnet opening Release the lock from the inside of the vehicle to open the bonnet. -
Page 18: Eco-Driving
Eco-Driving What is ‘‘Eco-Driving’’?’ • Eco-Driving = Driving in a more careful and environmentally responsible way • Eco-Driving = Reduced fuel costs • Eco-Driving = Reduced Environmental impact Saving of CO emissions. á Eco-Driving Savings Total potential saving of 20 - 30%. Open windows increase fuel Roof load...
