- Page 1 User Manual vMixKeyboard Controller...
-
Page 2: Introduction
Introduction Thank you very much for using our portable broadcast platform products!please read the manual carefully before using this product. This manual describes in detail the functions, installation and operation of the portable broadcast station general principles or methods. This series of portable broadcast station is a high performance, multi - function product of live broadcast switching station. -
Page 3: Warranty Terms
Warranty only valid in the country or region of purchase. Shipping expenses are at Oton for any delivery claim - you get a defective piece at box just opened. What Is Not Covered It is important to note that our warranty is not an unconditional guarantee for the duration of the Program. - Page 4 Manufacturer reserves the right to refuse to service any product which has been altered, modified or repaired by any non-authorized personnel Register for 2-year Warranty Visit https://otontechnology.com/warranty/ or scan below QR code to register 2-year warranty for your Oton switcher.
-
Page 5: Table Of Contents
Table of Content Introduction.................................2 Warnings and Precautions..........................2 Warranty Terms..............................3 Overview................................6 Key Features............................... 6 Tech Specs................................6 Instant Shortcut Configuration........................7 Configure Button Indicator..........................12... -
Page 6: Overview
Overview Oton KB12 is a cost effective video switcher for live streaming or small venue multimedia control. vMix has complete integration with the device allowing any key or control to be assigned to virtually any function and triggering our backlight LEDs to indicate active inputs, streaming, and recording status. -
Page 7: Instant Shortcut Configuration
Step 1: Connect KB12 with your computer via USB2.0 cable Step 2: Open vMix software and click [Settings] on the top-right hand corner. Note: * User need to register vMix software with vMix company. Oton doesn’t supply the software, we only... - Page 8 Step 3: Click [Shortcuts] on the side menu, then click [MIDI Settings], if you see [SMC75-vMix] shown in the list, then it means KB12 is connected successfully.
- Page 9 Add Shortcuts Step 1: Click [Shortcuts] on the side menu, then click [Add] Step 2: Click the arrow next to the [Function] dropdown box and the Select Function window appear with a number of commands or macros to choose from, organized by category.
- Page 10 Step 3: Click [Find], a dialog box will popup, promoting: press 1 button on the control panel, press the hold 1 button, the popup will then display :MIDINoteOn CH.., if you release the button, it will show:MIDINoteOff CH...,at this time the button has been recognized by vMix software, click’OK’...
- Page 11 Import Preset Shortcuts KB12 includes a list of pre-configured shortcuts so you can easily import them to improve efficiency. Step 1: Click [Shortcuts] on the side menu, then click [Import] at the bottom left corner.
-
Page 12: Configure Button Indicator
Configure Button Indicator 1. Open vMix software and click [Setting] 2. Click [Activators], then click [Add]... - Page 13 3. Click [Event], select event and Type in the drop-down menu. 4. Click [Find], a dialog box will popup, prompting you to press the switcher button...
- Page 14 5. press the hold the button, the popup will then display :MIDINoteOn CH.., if you release the button, it will show:MIDINoteOff CH...,at this time the button has been recognized by vMix software, click’OK’...
