Summary of Contents for Dreamus Astell&Kern AK UW100
- Page 1 AK UW100 INSTRUCTION BOOK User Guide...
-
Page 2: Table Of Contents
CONTENTS Getting Started Before Using the Product Included Items Parts Names Charging Power Management Connections Connecting to a device Using the Device Using the Earbuds Listening to Music Making a Phone Call Voice Recognition Using the App Miscellaneous Safety Precautions Troubleshooting Copyright Certifications... -
Page 3: Before Using The Product
User Guide Before The descriptions contained in this instruction book are based on the product's default settings. Using the The contents of this instruction book may differ from the Product actual product due to changes in the manufacturer’s specifications. The images shown in this instruction book may differ from the actual product. -
Page 4: Included Items
User Guide Included Components may change without prior notice to improve the performance or quality of the product. Items TWS earbuds Ear tips (5 sizes) Charging case Charging cable Quick Start Guide & Warranty Card Ear tips: Select the ear tips that best fit your ears and affix them onto the earbuds. -
Page 5: Parts Names
User Guide Parts The appearance of the product as well as the information printed and engraved on the product may vary depending on Names the manufacturer's specifications. Ear tips Proximity sensor Touch button Charging pin Microphone Charging pin LED indicator Charging port (USB Type-C) Ear tips: Select the ear tips that best fit your ears and affix them onto the earbuds. -
Page 6: Charging
User Guide Charging Wired charging 1. Notice the direction of the earbuds when replacing them in the charging case so they come in contact with the charging pins. 2. Connect the [charging port] on the back of the charging case with the charger using the USB Type C cable included in the package. - Page 7 User Guide Be sure to use the USB Type C cable provided with the product. Cables that do not meet the specifications may cause product failure. Recommended charger specifications: DC 5V/2A Using a charger that does not meet the product’s specifications may cause the product to fail.
- Page 8 User Guide LED indicator (Charging case) Color Status Blue: Blinks repeatedly Earbuds: Charging in progress Blue: Turns off Earbuds: Charging complete Green: Blinks repeatedly Cradle: Charging in progress Green: Turns off Cradle: Charging complete Blue/Green: Earbuds/Cradle: Blinks repeatedly in turn Charging in progress (Both) Blue/Green: Turns off Earbuds/Cradle: Charging complete (Both)
-
Page 9: Power Management
User Guide Power Turn on/off Manage- 1. The earbuds power on automatically when they are removed from the charging case. ment 2. The earbuds power off automatically when they are placed into the charging case. Reset If the earbuds are not operating properly or have stopped operating, reset them and try again. - Page 10 User Guide Connec- Insert the ear tips tions 1. Select the ear tips that fit you best among the five sets of ear tips that have been provided. 2. Take out the ear tip and flip the cover over backwards. 3.
-
Page 11: Connections
User Guide Connecting Connecting to a mobile device to a device 1. When the earbud is removed from the charging case, it automatically powers on and enters pairing standby mode. 2. Turn on your mobile device’s Bluetooth feature: [Settings > Connections > Bluetooth] 3. - Page 12 User Guide If one earbud gets disconnected during use, touch the disconnected earbud for 20 seconds to reconnect. Bluetooth pairing mode will turn off if the earbuds and mobile device are not connected within 3 minutes outside the range. If you put the product in the charging case and take it out, the earbuds will enter Bluetooth pairing mode.
- Page 13 User Guide Connecting to a different mobile device 1. Turn off the Bluetooth feature in the connected mobile device at [Settings > Connections > Bluetooth] or unregister the earbuds from [Registered Devices]. 2. Press one earbud for 3 seconds to enter Bluetooth pairing mode.
-
Page 14: Using The Device
User Guide Using the Using the touch button Earbuds Touch the outside of the earbud to use various features such as playing or pausing music. Action Right Stand by/Playing media Receiving a call (Press once) Play/Pause Accept/end a call (Press twice) Play the next track Decline a call (Press three times) -
Page 15: Listening To Music
User Guide Listening Playing music to Music You can listen to music playing on a mobile device by connecting the earbuds to the mobile device. Play the music stored in your mobile device or stream music while connected. Controlling the volume Touch the right earbud for 2 seconds or longer to increase the volume, and touch the left earbud for 2 seconds or longer to reduce the volume. -
Page 16: Making A Phone Call
User Guide Making Answering a call a Phone When your earbuds are connected to your mobile device, you can check and answer calls from your mobile device. Call Accept/decline a call When a call is received while you are wearing the earbuds, the earbuds will emit a sound as well as a voice notification to inform you of the phone number or name saved in your contacts for that incoming call. -
Page 17: Voice Recognition
User Guide Voice Voice Recognition Recogni- You can use the voice recognition features supported by your mobile device. Touch the left earbud 3 times to activate the tion voice recognition features. Supported voice recognition features may vary depending on the specifications of the mobile device manufacturer. -
Page 18: Using The App
User Guide Using Using the AK TWS app, you can connect the earbuds to a smart device to check the status of the earbuds and set up the App the environment to use the earbuds. Downloading the app 1. Search for the AK TWS app at the store for your smartphone and install. - Page 19 User Guide App screen Product Displays battery status, Bluetooth status, status device name, etc. Ambient Ambient mode and ambient mode level control are supported. Home screen Goes to the Home screen. Goes to the EQ screen. Settings Goes to the Settings screen. Tap action Goes to the tap action settings screen.
- Page 20 User Guide App settings Set up the device according to the user's needs. The structure of the settings menu may vary depending on the firmware version. Device settings Language: Select the language for the device. Reset settings: Reset all of the app’s settings. Other: View system information, legal information, etc.
-
Page 21: Safety Precautions
User Guide Safety Do not wear the earbuds in unsafe areas, such as on roads or crosswalks. Doing so can slow your response to external risks Pre- and result in an accident. Cautions Maintain a safe distance between the product and any object that may be affected by magnetic fields. - Page 22 User Guide Do not place the device near magnetic objects (magnets, televisions, monitors, speakers, etc.). The manufacturer shall not provide exchanges or compensation for any product damage or loss resulting from the customer’s negligence. Do not use the product in any way other than for the intended purpose.
-
Page 23: Troubleshooting
User Guide Trouble- Common issues and solutions shooting 1. The product won't turn on. The battery may be low. Charge the product for at least one hour and try again. Reset and turn on the product again. 2. The earbud doesn't work. If an earbud’s proximity sensor does not make contact with your ear, the earbud may not work. - Page 24 User Guide 5. The battery won’t charge correctly. Check if your charger is a manufacturer-approved model. Check if the earbud charging pins are in good contact with the pins in the charging case. Check the connection between the charger and the charging case.
- Page 25 User Guide 10. The sound quality during phone calls and when playing music is poor. Wireless phones, wireless network devices, etc., can make noise that interferes with calls and music playback. Your earbuds should be as far away as possible from devices that use or generate radio waves.
-
Page 26: Copyright
Companies, organizations, products, people, and events used in the examples are fictional. Dreamus Company has no intention to be associated with any company, institution, product, person, or incident through this instruction book, and no such inference should be made. -
Page 27: Disclaimers
The information in this user manual was written based on current product specifications. The manufacturer, Dreamus Company, regularly adds new features via OTA updates and will continue to apply new technologies in the future. Product specifications may be changed without prior notice. -
Page 28: Specifications
User Guide Specifi- Bluetooth version cations Bluetooth Profile HFP, A2DP, AVRCP Codec SBC, AAC, aptX™adaptive Driver Knowles BA AKM AK4332ECB SPL(Sound Pressure Level) 94dBSPL/1mW@1kHz Earbuds weight about 7g Case weight about 65g Firmware Upgrade OTA (Over-The-Air) with APP Miscellaneous...
