Defender MAX II Quick Start Manual

MAX II SOLAR SECURITY LIGHT
High Powered PIR Security Light

Introduction

The Defender Max II Solar Security Light is a robust floodlight made from casting aluminium. The
light is extremely bright, with 80 super bright white LEDs which provide 850 lumens of light. The
unit is easy to install and comes with 4.8m of cable to attach the solar panel to the light unit.
The unit has a manual On-Auto-Off switch which allows the user to keep the light on
constantly, off or on automatic, which uses the PIR to automatically switch on the light when
somebody walks past.

Contents

1 x Solar Light
1 x Solar Panel (with cable)
6 x Wall Plugs
6 x Screws
Caution
• Do not install the light close to people or cars. Keep out of reach of children.
• Do not install the unit close to flammable items.
• Do not stare directly into the light.

Charging the Battery

To charge the unit, connect the solar panel to the light unit using the attached cable ensuring the
solar panel jack is fully inserted into the socket in the light unit. Ensure the solar panel is facing the
sun and wipe the panel regularly as dirt can affect the battery efficiency.

Installation

The Defender Max II Solar Security Light comes with a 4.8m cable to connect the light unit and
the solar panel, allowing the two units to be 4.8m apart. Decide on the location of the light,
ensuring the solar panel is in a location that receives full, direct sun for a minimum of 8 hours a
day. Mount the light unit 2-3 meters above the ground on a solid surface capable of supporting
the light even in windy conditions. The unit must be installed high enough to provide effective
motion detection and light distribution.
Use the mounting bracket provided as a template, mark the holes that need to be drilled, ensuring
there is no cables or electrical lines behind the wall. Drill the holes and install the wall plugs. Place
the mounting bracket back over the holes and thread the enclosed screws to secure the bracket in
position. Do the same for the solar panel unit. When both units are mounted on the wall, carefully
position the power cord to the light. Adjust the motion detector head below the light by moving it
left or right so that it faces the desired area. Move it up or down by using the screw located on the
neck of the motion detector head.
defendersecurityproducts.co.uk
Product Code: OT01052
