- Page 1 LCD Monitor User’s Guide...
- Page 2 Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. HP supports lawful use of technology and does not endorse or encourage the use of its products for purposes other than those permitted by copyright law.
-
Page 3: About This Guide
Preface About This Guide This guide is intended for anyone who uses the v216 LCD Monitor. It describes the monitor’s features, setup, and operation. The sections are as follows: • Safety and Maintenance Guidelines • Setup • Using the Monitor •... -
Page 4: Safety And Maintenance Guidelines
Safety and Maintenance Guidelines Important Safety Information The power cord is designed for use with your monitor. To use a different cord, use only a power source and connection compatible with this monitor. For information on the correct power cord set to use with your monitor, Power Cord Set Requirements. -
Page 5: Cleaning The Monitor
• Do not open your monitor cabinet or attempt to service this product yourself. If your monitor is not operating properly or has been dropped or damaged, contact your HP authorized dealer, reseller, or service provider. • Adjust only those controls that are described in the operating instructions. -
Page 6: Attaching The Base
Setup Base and Tilt Attaching the Base 1 Set the base on a flat surface, such as a table top. 2 Using both hands, position the pedestal over the base and press down firmly to lock in place. Make sure that the base is securely locked in place before continuing with the setup procedure. -
Page 7: Removing The Base
Removing the Base 1 Set the panel face-down on a flat, protected surface. 2 Squeeze the tabs in the bottom of the base to release the lock. 3 Remove the base from the pedestal. CAUTION: To prevent damage, avoid applying pressure to the panel front. Adjusting the Tilt For optimal viewing, adjust the screen tilt to your own preference, as follows: 1 Face the front of the monitor and hold the stand so that you do not topple the monitor while changing the tilt. -
Page 8: Attaching The Cables
Cables Attaching the Cables 1 Turn off your computer. 2 Connect the built-in monitor speakers to the computer, using the audio cable (green connector). 3 If you are attaching a VGA cable, connect one end of the 15-pin D-Sub VGA cable (blue connector) to the back of the monitor and connect the other end to the computer VGA port. - Page 9 4 Connect one end of the power cord to the back of the monitor and plug the other end into a grounded outlet. 5 Turn on your monitor and computer. If your monitor displays an image, installation is complete. If it does not display an image, Technical Support FAQs Using the Monitor.
- Page 10 Wall Mounting Arm Preparing to Install a Wall Mounting Arm (Not supplied) This monitor can be attached to a wall mounting arm that you purchase separately. CAUTION: Before disassembling the monitor, turn off the monitor power, and disconnect all power, video, and audio cables. 1 Disconnect the cables from the monitor.
-
Page 11: Using The Monitor
Using the Monitor Operating Instructions Control buttons are located on the front of the panel, as shown below. Use the Menu button (C) to adjust the display settings to your personal preferences: • Set up the monitor, attach the cables, and adjust the tilt as described in the •... -
Page 12: External Controls
External Controls Menu Mute Auto Power – (minus) button + (plus) button Menu button Mute button Auto button Power button Power LED Technical Support FAQs for more information. Navigates backward through the OSD menu and decreases adjustment levels. If the OSD menu is inactive, activates the Volume decrease. Navigates forward through the OSD menu and increases adjustment levels. -
Page 13: Setting The Optimal Resolution
Settings Setting the Optimal Resolution The recommended resolution for this monitor is 1680 x 1050. To configure the monitor to this resolution, complete the setup procedure and make sure that the monitor is connected to the computer. Turn the monitor on and do the following: 1 Click the Windows Start Button 2 Under Appearance and Personalization, click Adjust Screen Resolution. - Page 14 Adjusting On-Screen Display Settings Use the OSD menu to adjust the screen image and change settings. To access the OSD menu: 1 If the monitor is not already on, press the Power button to turn the monitor on. 2 Press the Menu button to activate the OSD menu. 3 Press the –...
-
Page 15: Osd Menu
OSD Menu The table below shows the OSD menus and their functions at each level. OSD Menu Levels Level 1 Level 2 Brightness Adjustment Scale Reset Cancel Save and Return Contrast Adjustment Scale Reset Cancel Save and Return Volume Adjustment Scale Image Control Auto Adjustment Horizontal Position... - Page 16 OSD Menu Levels (continued) Level 1 Level 2 Language Deutsch Simplified Chinese Japanese English Español Français Italiano Nederlands Cancel Save and Return Management Power Saver Power On Recall Mode Display Power-On Status Display DDC/CI Support Sleep Timer Cancel Save and Return OSD Control Horizontal OSD Position Vertical OSD Position...
-
Page 17: Using The Auto-Adjustment Function
Installing Drivers and Using the Auto-Adjustment Feature Downloading Drivers and Software To download the latest version of drivers and software files from the HP Support Web site: 1 Refer to: http://www.hp.com/support 2 Select your country/region. 3 Select Download Drivers and Software. - Page 18 • Check the monitor’s video cable and make sure none of the pins are bent. • Make sure the HP monitor drivers are installed (HP monitor drivers are available at: http://www.hp.com/support) • Adjust the contrast and brightness controls. •...
- Page 19 (1680 x 1050). • Make sure that the latest supported driver is installed for the graphics card. For HP and Compaq systems, you can download the latest graphics driver for your system from: http://www.hp.com/support For other systems, refer to the Web site for your graphics card.
-
Page 20: Specifications
Specifications All specifications represent the typical specifications provided by HP’s component manufacturers; actual performance may vary either higher or lower. v216 Display Type Viewable Image Size Tilt Face Treatment Maximum Weight (unpacked) Dimensions (including pedestal) Height Depth Width Optimum Display Resolution... -
Page 21: Preset Display Modes
Preset Display Modes Preset Pixel Format 640 x 480 640 x 480 720 x 400 800 x 600 800 x 600 832 x 624 1024 x 768 1024 x 768 1152 x 720 1152 x 870 1152 x 900 1280 x 768 1280 x 960 1280 x 1024 1280 x 1024... -
Page 22: Power Cord Set Requirements
18AWG, and the length of the cord must be between 4.94 ft (1.5 m) and 12 ft (3.6 m). If you have questions about the type of power cord to use, contact your HP-authorized service provider. A power cord should be routed so that it is not likely to be walked on or pinched by items placed upon it or against it. -
Page 23: Lcd Monitor Quality And Pixel Policy
This is common to all LCD displays used in products supplied by all vendors and is not specific to the HP LCD Monitor. These imperfections are caused by one or more defective pixels or subpixels. -
Page 24: Declaration Of Conformity For Products Marked With Fcc Logo, United States Only
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Hewlett-Packard Company may void the user’s authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods to maintain compliance with FCC rules and regulations. -
Page 25: European Union Regulatory Notice
European Union Regulatory Notice This product complies with the following EU directives: • Low Voltage Directive 2006/95/EC • EMC Directive 2004/108/EC Compliance with these directives implies conformity to applicable harmonized European standards (European Norms) which are listed on the EU Declaration of Conformity issued by Hewlett-Packard for this product or product family. -
Page 26: Japanese Notice
Disposal of Waste Equipment by Users in Private Households in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. -
Page 27: Japanese Material Content Declaration
July 1, 2006. To view the JIS C 0950 material declaration for this product, visit www.hp.com/go/jisc0950. Korean Notice Materials Disposal This HP product contains Mercury in the fluorescent lamp in the display LCD that might require special handling at end-of-life. Disposal of this material can be regulated because of environmental considerations. For disposal or recycling... -
Page 28: Hp Recycling Program
HP offers product end-of-life return programs for HP and other manufacturers’ hardware in several geographic areas. The terms and availability of these programs vary by geography because of differences in regulatory requirements and local customer demand. For information on the HP recycling program, refer to the HP Web site http://www.hp.com/recycle ®... - Page 30 Part number: 453601-001...
