Photoelectric Beam Detector
EL-PB60S
Features
EL-PB60S Photoelectric Beam Detector ( 60M )
Wide angle adjustment
External light protection
Protection against frost/dew, Guaranteed quality of front cover
High convenience for installation and wiring
Safety Approval: CE
Specification
Protection range: Outdoor : 60m Indoor : 120m
Detection method: Simultaneous breaking of 2 beams
Infrared beam: Double modulation pulsed beams by LED
Response Time: 50 ~ 700mS
Supply voltage: DC 10.8 ~ 25VDC(Non-polarity)
Current: Max. 57mA
LED: Tx : Power(Green LED),
Rx :Sensitivity good (Green LED),
When an alarm is initiated (Red LED)
Alarm output: Dry contact relay output form C,
Contact action : Interruption time +delay time(1~3 sec),
Contact capacity : 30V(AC/DC) 1A or Less
Tamper output: Dry contact relay output form N.C(Rx only),
Contact action : Activated when cover is detached,
Contact capacity : 30V (AC/DC) 1A or Less
Temperature: -20
Beam Adjustment: Horizontal : 180˚(±90˚), Vertical : 20˚(±10˚)
Mounting site: Indoor/Outdoor
Material: Cover : PC resin, Base : ABS resin
Dimension: 63 x 163 x 75mm (W x H x D)
Weight: Rx : 330g, Tx : 315g
Function: Monitor jack output, Frost proof cover
IP rating: IP 44
~ 60
EL-PB60 S
