- Page 1 Installation Guide RSD PEFS-PL80S-11/21 www.projoy-electric.com...
- Page 2 RSD PEFS-PL80S CONTENT Operation Manual of Panel Level Rapid Shutdown 1. Scope and General 2 Safety instructions and regulations 2.1 Symbols explanation 2.2 Safety instructions 3 Technical Data/Specification and product information 3.1 Parameters Table 3.2 Product Information 4 Installation 5 Trouble shooting 6 Maintenance and Repair 7 Warranty commitment 8 Contact us...
- Page 3 RSD PEFS-PL80S 1 Scope and General The manual only used to PEFS-PL80S-11,PEFS-PL80S-21 model Panel-level Rapid Shutdown. Version Date Remark Chapter V1.0 2021-10-15 First Edition 2 Safety instructions and regulations For your safety and effective operation, please read the safety instructions thoroughly before using the product.
- Page 4 7) One rapid shutdown can control 1,2, or 4 solar modules, Suitable for residential and commercial solar systems. 4 Installation Normal installation of PEFS-PL80S-11/PEFS-PL80S-21 will be the connection of one/two PV panels in series to one RSD unit (typical wiring example below). Where the combined rating of two panels exceeds the rating of the PEFS-PL80S-11/PEFS-PL80S-21, or to meet regulatory compliance, 1-to-1 connection of the PV module to the FireRaptor can be used.
- Page 5 Power out Where reference has been made above to the use of the PEFS-PL80S-11/PEFS-PL80S-21 as the source of supply of the 24VDC, it can also be considered that power can be supplied to the RSD units by an alternative suitably rated UL Approved 24VDC Class II power supply (AC/DC or DC/DC types).
- Page 6 RSD PEFS-PL80S 2) Please remove the product first and check the temperature of the product. If it is very hot (over 120°C), do not deal with it at this time. After the temperature of the product is lowered, it will resume normal operation. 3) Check the input and output connectors, whether they are correctly connected and inserted, as shown in the figure below：...
- Page 7 RSD PEFS-PL80S This regulation is applicable to PEFS-PL80S-11,PEFS-PL80S-21 model Panel-level Rapid Shutdown produced by PROJOY. All products purchased through regular channels shall enjoy the full range of quality assurance services provided by the company, except for the following situations: 1. Beyond the warranty period;...
