Atoll Electronique TU 80 Owner's Manual

C :
ONNECTING
Rear of appliance :
1 2
1) Aerial Input (75 Ω).
2) Stereo output Left (L) and Right (R).
3) Power plug.
D O :
ETAILS F FUNCTIONS
Front of appliance:
7 8 9

4) Display

(see details below).
5) Stereo reception Led.
6) Stand-by :
led 15) appears.
7) Memory mode
(see details below).
8) & 9) Previous & next channel in
memory.
3
4 5
10 11 12 6
10) & 11) auto SCAN keys : 10) & 11) Previous & next automatic
with a
scan of Band.: short press you can scan the band by 0,5Mhz
A short press scans on
steps. A longer press starts the auto-SCAN.
manual by 0,5Mhz step. A long press scans
The SCAN will stop on every station found .
automatically till it finds a station.. Auto scan
stop each time a station is found or with a
press on inverse SCAN.
12) Sélection du mode de réception
12) Selection of reception Mono or
Mono ou Stéréo:
en mode stéréo, le
Stereo: o
n stereo mode led n° 5) switch
témoin 5) s'allume.
on.
A :
DVISES
- To optimise the performances your Tuner, you should switch it on at least half an
hour before any listening, the time for output stage to reach their ideal working
temperature. Between two utilisation, it's better to use the stand-by position, so
that the output stages remains at their optimal temperatures.
- We advise you to use good wires to link with the other elements. Don't hesitate to
take advise from your dealer.
D :
ISPLAY
13
13) Memorised number of channel.
14) Stations frequency (or channel name).
15) Stand-by Led.
M :
EMORISATION OF PROGRAM
The program mode is done with keys "MEM" and "CHAN - & +" of the front panel or
with the keys of the remote control. You are able to program, for each channel, a line
of 7 letters and/or numbers. You can program 60 channels.
A- place yourself on a frequency to program.
B- Push on MEM :
Channel's number twinkles :
C- choose the channel with keys CHAN - or +.
D- To confirm, push on the key MEM.
Then the first digit twinkles.
E- you can select with keys CHAN - & +, a letter
(from A to Z), a number (from 0 to 9) a -, or a
space.
F- To confirm, push on MEM. Repeat sequence (E) for the 6 other digit.
After programming last digit, the message "MEM" indicates the end of program. Then,
appears the correspondent frequency and finally the name of the channel.
14
15
