Summary of Contents for Rem M-Vac Series
- Page 1 Installation Guide M-Vac Series For models: 1M4.10 / 1M4.16 / 1M4.25 / 2M4.10 / 2M4.16 / 2M4.25 1.800.668.8736 www.basevacdental.com BV-112.0 Manufactured by R.E.Morrison Equipment Inc., an ISO 9001 and ISO 13485 certified company.
- Page 2 BaseVac™ M-Vac Series Installation Guide Important Information Intended Use To provide vacuum suction during general examinations and procedures conducted by qualified dental professionals. Disposal of Equipment At the end of product life, the unit(s), accessories, and other consumable goods may become contaminated from normal use.
-
Page 3: Product Specifications
BaseVac™ M-Vac Series Installation Guide | Product Specifications Model # 1M4.10 2M4.10 1M4.16 2M4.16 1M4.25 2M4.25 (5”-25”Hg Max Number of (HV) Users Operatories Power (HP) 0.60 0.60 0.94 0.94 Power (AMP) Voltage 110V, 1 Phase 110V, 1 Phase 220V, 1 Phase... -
Page 4: Loose Parts
BaseVac™ M-Vac Series Installation Guide Loose Parts (Included with 220 single phase versions) © R.E.Morrison Equipment Inc. 2012... - Page 5 BaseVac™ M-Vac Series Installation Guide | Collection Tank Setup Note: • Tank must be elevated above drain • All connection hardware except for drain piping is included. Assemble inlet kit and fasten onto tank inlet. Connect the tank drain outlet hardware to the drain connection located at the bottom of the tank.
-
Page 6: Exhaust Connections
BaseVac™ M-Vac Series Installation Guide Exhaust Connections NOTE 1 Pump exhaust piping should run to an outdoor source. Assemble piping as shown. Use PVC glue to fasten piping. Extension to outside is to be supplied by others. Connect hose barb located on bottom of p-trap and elbow to drain. (Hose is not supplied) To outside source. - Page 7 BaseVac™ M-Vac Series Installation Guide | Electrical for Version 1 Systems Warning All electrical connections are to be completed by qualified personnel only. Note The standard panel is a 220 Vac 1 phase connection. A minimum of 218 Vac 1/ph and a maximum of 226 Vac 1/ph is to be connected.
- Page 8 BaseVac™ M-Vac Series Installation Guide Switch Wiring for Version 1 Systems © R.E.Morrison Equipment Inc. 2012...
- Page 9 BaseVac™ M-Vac Series Installation Guide | Version 2 (optional) Electrical www.basevacdental.com...
-
Page 10: Troubleshooting Guide
BaseVac™ M-Vac Series Installation Guide Troubleshooting Guide Problem Potential cause Symptom Solution Electrical Activate remote - Check main fuse or breaker, reset or replace - Main fuse failure switch, nothing happens Electrical Activate Pump panel - Check and reset overload in pump control panel. - Page 12 Our products perform extremely well. Our company performs even better. We work to ensure you are satisfied with the performance of our products, today & everyday. We are here to help. basevacdental.com 1.800.668.8736 1.800.668.8736 www.basevacdental.com BV-112.0 Manufactured by R.E.Morrison Equipment Inc., an ISO 9001 and ISO 13485 certified company.
