Micro Rain MR 32 Instruction Manual For Operation And Maintenance

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MR 32
Instruction Manual For Operation
and Maintenance
KID Group
15250 Sunshine Rd.
Yukon, OK. 73099
800-373-9325

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR 32 and is the answer not in the manual?

Questions and answers

Summary of Contents for Micro Rain MR 32

  • Page 1 MR 32 Instruction Manual For Operation and Maintenance KID Group 15250 Sunshine Rd. Yukon, OK. 73099 800-373-9325...
  • Page 2 Safety is the main priority and failure to follow these instructions may cause serious injury. Micro Rain is not responsible for machine failure or personal injury if these procedures and operation instructions are not followed.

  • Page 3: Identification Data

    Identification Data The identification plate includes the model and serial number for your machine. Machine Controls & Components Optional tow hitch Drum Gear (under cover) Grease zerk for inlet seals (Open small valve to add grease) Anti reverse pawl Shut off bar Gearbox engage/disengage Speed control lever on bypass valve...
  • Page 4 Conditions For Machine Operation The MR32 is designed for clean water suitable for irrigation. The machine is not designed for water that includes large pieces of debris or slurry/wastewater conditions. Start Up Procedure/Operation 1) Push the machine to the desired location. Position the ma- chine with the sprinkler cart facing the direction to be irrigated.
  • Page 5 Start Up Procedure/Operation, continued **IMPORTANT: ALWAYS PULL CART OUT STRAIGHT AND TIGHTEN LOOSE WRAPS BEFORE START UP! Always Pull Tube Out Straight! Keep Wraps Tight! 5) Move anti-reverse lever to the engage position as shown. Ratchet the drum by hand to remove any loose coils remaining on the drum.
  • Page 6 This is corrected by starting over and making sure the level wind guide is lined up correctly. Call your Micro Rain servicing dealer with any questions regarding machine timing.
  • Page 7 MR32 Depth Control Plate Keeps front of machine level in loose soil conditions. MR32 Boost Pump Option 110v Booster kits to boost incoming pressures by 30 to 50 psi. Gas driven booster kits also available. Call your Micro Rain dealer for details.

  • Page 8: Maintenance Schedule

    Maintenance Schedule Inlet seals: Grease inlet seals every 100 hours. Grease drum gear every 100 hours. Drum gear: Level Wind: Grease level wind every 100 hours, replace level wind knife every 1000 hours. Change gearbox oil once a season with 80W/90 gear oil. Gearbox: Performance Chart RUN TIME(HRS)
  • Page 9 Parts Diagrams F650 DRUM F25.40.13 LE32NB01 LE3240A80 LE3240B14 LE3240B15 IO60 32MM240 F25.40.13 CD390 LE32B5B0 Frame/Chassis LE32BB00 PF40/M80 C6D28000 LE32B004 LE32NB08 LE32NB140 C3D14 LE32NB11 CM100000 LE32NB13 13007 13x650x6 0032K LE3240D90 13506 LE32ND04 LEND10 0030K 0031K...

  • Page 10: Parts Diagrams

    Parts Diagrams Drive System IN180000 MV18MF00 LE32ND14 IO45 IN14L32N (Standard Speed) P45.35.7 IN22L32N (High Speed) GMAD4535 LE32E140 974100010 50252 LED10000 VZ100 LEE170000 PM100000 FZ131095 LEE32ND01 VS3/4MF LEE32ND02 50204 LEE020000 E014 AT1110000 VIM10000 GOR30430 LEE22CN0 F100 GOR46250 RZ343800 TCE06x020 LEE240000 50204 Sprinkler Cart LE32F100 0073K...
  • Page 11 Parts Diagrams Level Wind Assy. CA50/4950 VCE08x010 LE32C600 LE32CO800 Chain MC120000 PF204000 CP3x30000 LE3240C10 PI133206 VCE08x010 Set Screw VB40LE32 LE32C050 PF204000 Funny Sprinkler...
  • Page 12 If KID Group, Inc. determines that the above warranty was breached with respect to any part or component provided by the manufacturer (Ocmis Irrigation) of Micro Rain equipment, (and if all conditions set forth below have been satisfied) then, KID Group, Inc.
