Summary of Contents for Oxus RAK-U06M
- Page 1 Medical Oxygen Supply System User Manual User Manual MODEL RAK-U06M RAK-U04M OXUS...
- Page 2 Oxus medical oxygen supply system is • A high purity oxygen generating device that uses a physical method of filtration and ab- sorption of air to separate oxygen and nitrogen. The oxygen is then supplied to oxygen breathing apparatus connected to patients through gas equipment in hospital.
-
Page 3: Table Of Contents
Table of contents Precautions for safety …………… 4 Precautions related to installation …… 4 Precautions related to power supply … 5 Precautions during the use …………… 6 Precaution during cleaning and storing 8 Names of the parts ………………… 9 Product part name and function ……… 9 Control panel ……………………………10 Display window …………………………... -
Page 4: Precautions For Safety
OXUS RAK-U06M / RAK-U04M Precautions for safety The following contents aim to keep the user safety and prevent property loss and inconvenience. These precautions must be read carefully and the product should be correctly used. Warning it indicates general warning or precaution. -
Page 5: Precautions Related To Power Supply
Medical oxygen supply system User Manual Once the installation is complete, do not change the configuration of the product and pipe. If you require re-installation, please contact the place of purchase or service center. Precautions related to power supply Do not pull the electric wire and handle the prod- Do not bend the electric wire by force and do not uct with wet hands. -
Page 6: Precautions During The Use
OXUS RAK-U06M / RAK-U04M Precautions during the use Do not spray insecticide or flammable gases to Do not put fingers or foreign materials to the air the product. intake vent or outlet vent in the product. It is harmful to human body as well as causing There is a risk of product failure or electric shock. - Page 7 Medical oxygen supply system User Manual Do not apply excessive impact on the product If you feel abnormal vibration and irregular noise, artificially. call the place of purchase and service center im- It can cause a product failure or fire. mediately.
-
Page 8: Precaution During Cleaning And Storing
OXUS RAK-U06M / RAK-U04M Precaution during cleaning and storing Cleaning and maintaining the product should be Do not spray water to clean the product and do done after power is off and the oxygen generator not wipe out the product with benzene, thinner, or is stopped. -
Page 9: Names Of The Parts
Medical oxygen supply system User Manual Names of the parts Product part name and function ① ② ③ ⑦ ⑨ ④ ⑤ ⑧ ⑥ Front Back Side Name Description If the oxygen storage tank indicates lower pressure than the set thresh- Low pressure old during the product use, the low pressure alarm lamp is flashed and ①... -
Page 10: Control Panel
OXUS RAK-U06M / RAK-U04M Control panel ① ④ ② ⑤ ⑥ ⑦ ③ ⑧ ⑨ Name Description It displays oxygen concentration state and filter replacement, and Display window ① regular inspection time. Unit condition LED It displays each unit working condition inside the product. -
Page 11: Display Window
Medical oxygen supply system User Manual Display window ④ ⑤ ① ⑥ ⑦ ② ③ ⑧ ⑨ ⑩ ⑪ Name Description Oxygen concentration display It displays the discharge oxygen concentration with 20 ① LED lamps. Oxygen concentration status It displays a discharge oxygen concentration state, which ②... -
Page 12: Product Part Name And Function
OXUS RAK-U06M / RAK-U04M Product part name and function ② ③ ① ④ ⑦ ⑤ ⑥ ⑫ ⑧ ⑨ ⑩ ⑪ Name Description Power failure and It is a voltage port to utilize additional external alarms upon power low pressure alarm ①... -
Page 13: Checklist Before The Use
Medical oxygen supply system User Manual Checklist before the use Installation check Check whether the following conditions are met for the installation of the product. • Even and no slope place • No blocking of the air intake and outlet vent (sufficient air flow ensured) •... - Page 14 OXUS RAK-U06M / RAK-U04M Required temperature and humidity for the oxygen generator Operating temperature: Between approximately 0℃ and 40℃ - If the product is operated under surrounding temperatures with significantly large fluctuation by external factors, dew condensation occurs thereby shortening the filter life and causing a product failure.
-
Page 15: How To Use
: After the operating switch is turned on and approximately five sec later, the unit status LED is illuminated with green color. (Checks whether the oxygen generator unit and booster unit mounted inside the product are working correctly) [Normal status: Seven LED lights are all illuminated] [Normal status: Five LED lights are illuminated] [Model: RAK-U06M] [Model: RAK-U04M]... -
Page 16: Turning Off The Operating Switch
OXUS RAK-U06M / RAK-U04M 3. Check the display window indicator status : Once the product is running normally, the following screen is displayed in the display window after 20 sec. Company logo Date and time Total runtime Oxygen pu- rity indicator... -
Page 17: Product Operation Step
Medical oxygen supply system User Manual Product operation step Initial operation step 1. Discharge bypass step - The oxygen purity discharged initially is lower than 90% and will reach at 90% or higher after 2 min later approximately. After around 5 min from the product operation, the product can reach at the maxi- mum oxygen purity that the product can get (around 93% to 94%). -
Page 18: Normal Operation Step - High Purity
OXUS RAK-U06M / RAK-U04M 2. High-purity oxygen compression step - After around 2 min from production operation, the bypass step is complete and high-purity oxygen pressure step is to compress high-purity oxygen discharged from the individual oxygen unit to the oxygen storage tank with high pressure through the booster compressor. -
Page 19: Check The Product Display
Medical oxygen supply system User Manual Check the product display information Oxygen concentration indication information In the oxygen purity indicator in the display window, the number of LED light illuminated varies de- pending on oxygen concentration to display the oxygen concentration status message. LED light count and color indication according to oxygen concentration Oxygen concentration LED light count... -
Page 20: Filter Replacement And Regular Inspection
OXUS RAK-U06M / RAK-U04M Filter replacement and regular inspection information • Times to filter replacement and regular inspection are displayed using number and LED count. • Filter replacement countdown time LED is decreased by one in every 100 hour and regular inspec- tion countdown time alarm LED is decreased by one in every 450 hour. -
Page 21: Alarm Function Information
Medical oxygen supply system User Manual Alarm function information 1. Low pressure alarm function - If the oxygen tank pressure is lower pressure state than the set pressure, oxygen discharge flow rate is lower and purity is degraded thereby generating a low pressure alarm. - If the low pressure alarm goes off, the lamp is flashed and alarm sound (90dB) is resounded. -
Page 22: Maintenance And Storage
OXUS RAK-U06M / RAK-U04M Maintenance and storage Outside cleansing • Cleaning and maintaining the product should be done after power is off and the product operation is stopped. • The outside of the product is cleaned with soft cloth soaked with warm water to remove moisture as much as possible and wiped out gently. -
Page 23: Troubleshooting
Medical oxygen supply system User Manual Troubleshooting Symptoms Checklist Corrective actions - Check whether the external power supply lamp is illuminated. - If the power outage alarm operating switch is turned into [OFF], no power outage alarm goes off even if power is not supplied. - Page 24 OXUS RAK-U06M / RAK-U04M Symptoms Checklist Corrective actions - Check that all unit status LEDs are illuminated as [ON] normally and if any of them is turned off, open the front door of the product and check all operating switches of individual Check that any of units are [ON]status and red lamps are illuminated.
-
Page 25: Product Specification
Medical oxygen supply system User Manual Product specification Specification Unit RAK-U06M RAK-U04M Discharge flow rate ±3 (40±3) ±3 (26±3) Discharge pressure ±0.2 4±0.2 Oxygen purity 93±3 93±3 Operational voltage/Frequency 220/60 (230/50) 220/60 (230/50) VAC/Hz Power consumption 3.4 (2.7) 2.5 (2.0) -
Page 26: Product Warranty
• Please contact the service center in case of malfunction of the product. 1. Oxus will provide the free of charge A/S during the warranty period if the malfunction is caused by the mechanical defects. - Page 28 Life Oxygen & Technology Service and product inquiry Oxus Co., Ltd. PN R360210 (Rev.0)
