35-GUB105 GRASS AND LEAF COLLECTOR Carefully read the operating instructions before using the product! Operating instructions translated from Swedish...
INTRODUCTION Thank you for choosing a product from Kellfri AB. Compliance with the general safety instruc- tions, operating instructions and common sense will guarantee many years of enjoyment using the product. Kellfri’s equipment and products are aimed at self-employed farmers who have stringent performance demands.
If the instruction manual gets damaged or in any other way cannot be used, new copies may be ordered from: Kellfri AB, Munkatorpsgatan 6, SE-532 37 SKARA, Sweden. Tel.: +46 511 242 50 The general safety instructions can also be downloaded from Kellfri’s website: www.kellfri.co.uk.
SURROUNDINGS Check that the work area is free from bystanders, children and objects before hitching or using the equipment. There is a risk of serious injury. Be extra careful if there are children in the vicinity of the area where the equipment or product is used or stored. Check that there are no low-hanging electrical cables within the work area.
Page 5
Right arm Left arm Adjustment lever Tow bracket (straight) Tow bracket Collection bag Connection rail The collector’s unit The collector’s bag arms 10. Attachment 11. Support pins 12. Side tube frame-lower part (right) 13. Side tube frame-lower part (left) 14. Side tube- upper part (right) 15.
Page 6
Assembly instructions [35-GUB015 Leaf collector] Lock nut M8 Angle bracket NOTE: Right hand (R.H.) and Left hand (L.H.) are determined from the operator’s position while he/she is sitting on the tractor. Bolt M8x16 (Illustration 1) Fit the angle bracket on the collec- tor’s cover with M8x16 hexagonal screw and lock nut M8.
Page 7
At this point, tighten the four bolts which secure the arms on the cover. Next step, tighten the bolts which keep the arms together. Then Bolt M8x50 Locking pin tighten the bolts which hold the brackets. Flat bar (Illustration 4 or 5) Fit the cotter pin, spacers Spacers and locking pin on the tow bracket.
Page 8
Connection rail (Illustration 9) Fit the bar on the cover, use bolts M6x12 and lock nuts M6 Bolt M6x12 M6 lock nut Fitting bag on the collector 1. (Illustration 10) Turn the middle tube (upper part) so that the holes on the tube are Eyes, sewn on inside of the bag turned downwards.
Page 9
Side tube - upper part 5. (Illustration 13) Position the assembled lower frame on the bottom of the bag. Locking pin 6. (Illustration 13) Fit the ends on upper and clevis pin lower frame together with a clevis pin Ø9.5x25, secure with a locking pin Ø3.
Page 10
9. (Illustration 16) Tip the collection bag over and fit support pins in the holes, bend the pins just enough to fit in the holes. Important! Do not bend the support pins too much. Overbending can cause the pins to lose their tension. Support pins Upper hole Lower hole...
Page 11
12. (Illustration 19) Knot the cord on the upper frame tube Clevis pin 13. (Illustration 20) To fit the bag on the collector, thread in the bag arms on the ends of the collector arms and secure with clevis pin Ø6x37 and locking pin Ø2 R-clip Compliance with the safety instructions requires that the product is only used as described in these instructions.
STEPS TO TAKE BEFORE USE Carefully read the safety instructions and the operating instructions. Make sure that you understand the safety instructions, operating instructions and warning decals. Use common sense when using the product and suitable personal protective equipment. Always check the performance of the machine combination to be used. It is important that these are compatible and work satisfactorily together.
Carry out maintenance, service and checks in line with recommendations. Only use spare parts with equal performance to reduce the risk of injuries and breakdowns. For spare parts: contact Kellfri Service Check that all nuts and bolts are tightened after maintenance and service work. Always test the machine before starting work.
Page 15
DESCRIPTION QUANTITY DESCRIPTION QUANTITY Cord Connection rail Plastic cover Bolt M6x12 Frame tube Dust guard bracket Attachment Lock washer Support pins Bushing Collection bag Spacer bushing Side tube – lower part (left) Spacer for axle Side tube – upper part (left) Plastic screw Bolt M6x18 Lock nut Ø5...
You are always welcome to give feedback or ask us about our equipment and products. Kellfri AB has a policy of continuous product development and therefore reserves the right to make modifications, e.g. to the design and appearance of the product, without prior notice.
