Page 1
• Depending on the input signal, full-size display may not be possible in some cases. Refer to the number of display pixels above. • Although the projector can display signals with resolution up to UXGA (1600x1200), the signal will be converted to the projector’s panel resolution before being displayed.
Page 2
Initial set signals Initial set signals The following signals are used for the initial settings. The signal timing of some PC models may be different. In such case, adjust the items V POSITION and H POSITION in the IMAGE menu. Back porch (B) Active video (C) Data...
Page 3
Connection to the ports NOTICE ►Use the cables with straight plugs, not L-shaped ones, as the input ports of the projector are recessed. COMPUTER IN, MONITOR OUT D-sub 15pin mini shrink jack <Computer signal> • Video signal: RGB separate, Analog, 0.7Vp-p, 75Ω terminated (positive) •...
Page 4
Connection to the ports (continued) S-VIDEO Mini DIN 4pin jack • System: NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43, PAL (60Hz) Color signal 0.286Vp-p (NTSC, burst), 75Ω terminator Color signal 0.300Vp-p (PAL/SECAM, burst) 75Ω terminator Brightness signal, 1.0Vp-p, 75Ω terminator Ground Ground VIDEO RCA jack...
Page 5
AUDIO IN Ø3.5 stereo mini jack • 200 mVrms 47kΩ terminator AUDIO OUT Ø3.5 stereo mini jack • 200 mVrms 1kΩ output impedance Connection to the ports (continued)
Page 6
COMPONENT VIDEO OUT VCR/DVD/Blu-ray Disc player To input component video signal to the COMPUTER IN port of the projector, use a RCA to D-sub cable or adapter. For about the pin description of the required cable or adapter, refer to the...
