Summary of Contents for ElectiQ eiQ90CANOPYSTEEL
- Page 1 INSTALLATION AND USER MANUAL CANOPY COOKER HOOD eiQ90CANOPYSTEEL Thank you for choosing electriQ Please read this user manual before using this product and keep it safe for future reference. Visit our page www.electriQ.co.uk for our entire product range...
-
Page 2: Table Of Contents
CONTENTS SAFETY UNPACKING AND PRODUCT OVERVIEW OPTIONS FOR VENTILATION INSTALLATION OPERATION FILTER REPLACEMENT BULB REPLACEMENT MAINTENANCE TROUBLESHOOTING TECHNICAL SPECIFICATION SUPPORT... -
Page 3: Safety
SAFETY PRECAUTIONS • Whilst this product is compliant with all safety requirements, incorrect or inappropriate use can lead to both personal injury and potential damage to property. Please read the contents of this instruction booklet thoroughly before fitting or using the appliance. •... - Page 4 • If the hood is being installed so that the air is vented outside, there MUST be adequate ventilation of the room when the hood is used at the same time as appliances burning gas or other fuels – use of the hood may be dangerous as it could draw back the fumes from the other appliances which would otherwise be vented outside.
-
Page 5: Unpacking And Product Overview
UNPACKING YOUR HOOD • Please take great care when unpacking; a sharp blade should not be used to open the box, as it may go deep enough inside to damage components. Components damaged or marked by careless unpacking are not covered under the guarantee. -
Page 6: Options For Ventilation
OPTIONS FOR VENTILATION This hood supports both external venting and recirculation. The type of setup should be decided before commencing installation. EXTERNAL VENTING A 150mm diameter flexible pipe is provided which allows the cooking odours to be extracted outside. If this is the chosen installation method a suitable vent pipe should be purchased (150mm diameter) and consideration to the route of the vent pipe should be made. -
Page 7: Installation
INSTALLATION 1. The cooker hood should be placed at a height of 65- 75cm (26-30inch) from the cooking surface for the best effect. 2. Cut a hole in the cupboard, with the dimensions of 865 x 265 mm. Make sure that the edges of the hole are at least 35mm from the edges of the cupboard. -
Page 8: Operation
8. Use the supplied screws to fix the hood into the cabinet. 9. Use the 4 screws previously removed to fix the panel into body and reattach the aluminum grease filter Plug in the hood and connect the opposite end of the vent pipe (if required) OPERATION Your cooker hood is provided with two easy to use slide switches. -
Page 9: Filter Replacement
CARBON FILTER (Available Separately) Activated carbon filters can be used to trap odours, and must be used if the hood is not vented to the outside. They are available from the same stockist you purchased the hood from under the following reference: eiqcf110 eiQCF110 (Twin Pack of Carbon Filters) In order to install the activated carbon filter, the aluminum anti-grease filter should first be detached. -
Page 10: Bulb Replacement
BULB REPLACEMENT IMPORTANT: The light fitting must be replaced by the manufacturer, its service agent or similarly qualified persons Your cooker hood is supplied with 2 long life LED light fittings, although these are designed to have a very long lifespan, should one fail, replacements are available from the supplier of the hood and the guide below can be followed to replace it. -
Page 11: Maintenance
MAINTENANCE Before cleaning, switch the unit off and pull out the plug, or switch off at the relevant mains switch if the unit has been hard-wired. Make sure the unit has no power being fed to it. Regular Cleaning Use a soft cloth moistened with hand-warm mildly soapy water or household cleaning detergent. -
Page 12: Troubleshooting
TROUBLESHOOTING Fault Cause Solution The fan blade is Light on, but Switch off the unit. Repair to be jammed. fan does not carried by qualified service motor work personnel only. damaged. Both light Light has blown. Replace the lamp with correct rating. and fan do Power cord loose. -
Page 13: Technical Specification
TECHNICAL SPECIFICATION Symbol Value Unit Model identification eiQ90CANOPYSTEEL Annual Energy 61.4 kWh/a hood Consumption Time increase factor Fluid Dynamic 23.2 hood Efficiency Energy Efficiency 67.6 hood Index Measured airflow rate 322.6 at the best efficiency Measured air pressure at best efficiency point 615.7... -
Page 14: Support
INFORMATION FOR DISMANTLING Do not dismantle the appliance in a way which is not shown in the user manual. The appliance should not be dismantled by user. At the end its life, the appliance should not be disposed of with household waste. Check with you Local Authority or retainer for recycling advice.
