Summary of Contents for Casals SFC
- Page 1 USER AND INSTALLATION MANUAL DPT 500 www.casals.com CV102021-1...
- Page 2 MANUAL CONNECTION FOR OVERPRESSURE CONTROL SYSTEM DIFFERENTIAL PRESSURE TRANSMITTER (DPT) - FREQUENCY SPEED CONTROLLER (SFC) DPT 500: FIGURE VALUE Placement of the jumpers Move the switch from “I” to “V” Sensor range selection jumpers -500...+500 Pa 0...+50 Pa 0...+100 Pa 0...+250 Pa...
