- Page 1 Carolina Bed TOV-IHB68217/TOV-IHB68218 TOV-IHB68219/TOV-IHB68220 CAROLINA Adina ASSEMBLY INSTRUCTIONS...
- Page 2 PARTS LIST PICTURE LABEL DESCRIPTION HEADBOARD RAIL FOOTBOARD SLAT Support Bar Slat Support BED LEG HARDWARE LABEL PICTURE DESCRIPTION Cross Slat Bolt M8*25MM Spring Washer Metal Gasket Slat Support Leg Bolt M8*45MM Plastic Bolt Bed Leg Bolt Wrench Wrench Wrench...
- Page 3 Do NOT assemble on flooring or carpet. Assemble on a clean non- Step 1 marring surface (ex: packing foam) Assembly Steps Save all packaging until assembly is completed Need a part? Call TOV at 516-888-3355 or email service@tovfurniture.com ASSEMBLY STEPS STEP Attach the side rails to the headboard and Step 2 footboard using the pre attached hardware.
- Page 4 A SSEMBLY STEPS STEP Carefully turn over the bed by two adults, Attach the bed legs(G) and ensure all legs are securely attached I J M STEP Attach the 3 support legs to the support bar and ensure all legs are securely attached. Connect the support bar to the HB and FB, secure them using the Cross Slat Bolt.
- Page 5 STEP Assembly is complete. CARE & MAINTENANCE Do not put hot items directly on furniture surface. Do not clean furniture with harsh cleansers or polish. Dust and pick up spills using a clean,non-colored, lint-free cloth. Stains may be removed withamild soap solution and a damp cloth. Do not place furniture under direct sunlight.
