1.
Specifictions
ITEM
Built-in Li-ion Battery
Solar panel max output power
Output voltage
Max output current
Output plug
Power adaptor
Mounting
Waterproof
Operation temperature
Operation humidity
Voltage and Current of AC Adapter
Charging time/Battery life
Dimensions
2.
Keys and Indicators
Battery level will be displayed after pressing the button. There are 4 red indicators, which respectively represent 25%, 50%, 75%, and 100% of
the battery level.
3.
Installation Procedure
(1)
Disassemble the bracket and remove the
rotating head.
Solar Power Kit
SE5200
User Manual
(VER.202008)
5200mAh
5W(5V1A)
5V/6V or 5/9V or 5/12V
2A(5V/6V) /1.2A(9V) /1A(12V)
4.0*1.7*10.0mm(DC002)
input AC110-220, output: 5V 2.0A
tripod
IP65
T: -22 to +158° F/-30 to +70° C
5%-95%
5V and 2A
4 hours fully charged by DC(5V/2A); 30 hours fully charged by sunshine,
enough for 31000 night time pictures with all IR LED on
200*180*32mm
(2)
Fix the rotating head on the solar host.
Specification
(3)
Fix the bracket base on the wall
or tree.
1
Advertisement
Summary of Contents for BUSHWACKER SE5200
- Page 1 Solar Power Kit SE5200 User Manual (VER.202008) Specifictions ITEM Specification Built-in Li-ion Battery 5200mAh Solar panel max output power 5W(5V1A) Output voltage 5V/6V or 5/9V or 5/12V Max output current 2A(5V/6V) /1.2A(9V) /1A(12V) Output plug 4.0*1.7*10.0mm(DC002) Power adaptor input AC110-220, output: 5V 2.0A...
- Page 2 Install the bracket rotating head. Adjust the solar panel to align with the sun. Please note that the arrow is up during installation. Packing List Solar Panel x1 pcs； Bracket x1 pcs； Screw-A x4 pcs； Screw-B x4 pcs； Hexagon Wrench x1 pcs...
