Summary of Contents for Ascon Pool TURMION PRO TXF1
- Page 1 TURMION PRO WIFI TXF MODELS TXF1 & TXF2 The sun always shines with Ascon Pool Associated Controls ABN 816 2280 2644 251 Rawson Street, Auburn, NSW 2144, Australia. Tel: 1300 1ASCON (1300 127 266) Email: sales@ascon.com.au Web: www.asconpool.com.au Ascon Pool...
-
Page 2: Table Of Contents
Turmion Pro WiFi Transformer (TXF) Table of Contents WiFi TRANSFORMER SPECIFICATIONS--------------------------------- INSTALLATION---------------------------------------------------------------- GENERAL SAFETY RULES--------------------------------------------------- WiFi APPLICATION METHOD---------------------------------------------- WARRANTY-------------------------------------------------------------------- SAFETY INSTRUCTIONS: - Read prior to installing. When using Ascon Turmion Pro WiFi Transformer for LED pool lights, this equipment must be installed and serviced by a qualified technician. -
Page 3: Wifi Transformer Specifications
WiFi TRANSFORMER SPECIFICATIONS Wi-Fi connectivity: 802.11a/ b/g/n 2.4G/5G Channel 1-14@2.4GHz; 36-177@5GHZ Support WPA／WPA2 safe mode 802.11b mode + 20dBm output power Support STA/AP/STA+AP work mode Support SmartConfig function (including Android & iOS devices ) Onboard PCB antenna Electrical specification: Input: 240V AC 50HZ Output: 30VA/60VA 12V AC Fuses: Resettable fuse inside... -
Page 4: Installation
INSTALLATION The Ascon Turmion Pro WiFi Transformer (TXF) can be installed either indoors or outdoors. However, the TXF must be positioned so the electrical terminal connections are facing downward to the ground to ensure maximum protection of all electrical terminal connections. Choose a location for the WiFi TXF to ensure the distance between the WiFi TXF and the LED pool lights being connected complies with the LED pool lights maximum power cord length. -
Page 5: General Safety Rules
GENERAL SAFETY RULES 1. The installation of the Ascon Turmion Pro WiFi Transformer should be carried out in accordance to the safety instructions of swimming pools especially Standard HD 60364-7- 702:2010, Install & protection output circuit in accordance with AS/NZS61558.2.6, AS/NZS 3000:2007 or as amended and the specific instructions for each facility. -
Page 6: Wifi Application Method
WiFi APPLICATION METHOD 1. Download and install the app – AsconSmart. Using your smartphone or tablet go to App Store or Google Play. Download the AsconSmart app, and install the app. 2. Register AsconSmart account. Open the AsconSmart app, register with mobile phone number or E-Mail. P a g e... - Page 7 3. Run AsconSmart app. Click “+” or button (ADD DEVICES) to add WiFi transformer. 4. Power on WiFi transformer and confirm the WiFi indicator light flashes rapidly (flashes every 1 second). If not flashing, press and hold WiFi button for over 5 seconds.
- Page 8 5. Click “Confirm indicator rapidly blink” button on AsconSmart app. Then input the WiFi password. Note1: Mobile phone should have connected to the WiFi before running AsconSmart app. Note2: AsconSmart app only supports 2.4GHz & 5GHz WiFi signal. After WiFi transformer is added, the indicator LED will stay on. 6.
- Page 9 7. Ascon Turmion Pro WiFi Transformer is added in AsconSmart app now. 8. After the device is added successfully, click “Check Device Network” to check WiFi signal strength. Click “pencil“, go to “Details of device” Click “Check Device Network“ P a g e...
- Page 10 If all good, To operate different Multi-coloured pool lights **The first time the TXF is operated, please Click Select – Reset for the app to set to the correct colour** Programming sequences for the following pool lights have been added to this version of the Turmion Pro Wifi TXF: AquaQuip Multicolour Pool Lighting AquaQuip InstaTouch Enabled Pool Lighting...
- Page 11 Functions of button switches. WiFi button - Press and hold for over 5 seconds to WiFi reset. On/Off button – Power on/off Multicoloured pool lighting manually. Next button – Go to next colour. Save button – Save your favourite colour. When powering off and powering on again, the WiFi TXF will flash to your favourite (saved) colour.
- Page 12 TROUBLESHOOTING IF ‘FAILED TO ADD DEVICE’. If ‘failed to add device’, use AP MODE to add device. Make sure WiFi indicator flashes every 2 seconds, if not press and hold the WiFi button for over 5 seconds. Click “AP MPDE” Click “Confirm indicator slowly blink”...
- Page 13 Click “Continue” Note: If you are using 5GHZ WiFi signal, ignore the warning message, click “Continue”. Follow the APP instructions, find and add Ascon Turmion Pro WiFi Transformer to APP. Please also check: If the device is powered on. Whether mobile phone is connected to the Wi-Fi. Whether the device is ready for configuration.
-
Page 14: Warranty
Router’s wireless MAC filtering function is enabled. Remove the device from the filter list and make sure that router is not prohibiting device from connection. Make sure the password entered in App is correct when adding new Device. WARRANTY The Ascon Turmion Pro WiFi Transformer is covered by a 1-year warranty for domestic and commercial installations.
