Thiele Streamfeeder EFS Pro Manual page 11

STEP 1:
Separator Adjustment
(continued)
Excessive lowering of the separator assembly can damage envelopes
or lead to premature wear of the O-rings or feed belts.
A wider gap between envelopes and belt provides
the highest tolerance for curled and bent edges.
Feeding problems will occur with either too
many envelopes in the hopper, or too large a
gap between the separator assembly and the
envelope.
EFS P M
ro anual
1. Slide a single envelope between the feed belt and the separator.
2. Rotate the separator adjustment knob either up or down until the
envelopes can be pulled from under the separator assembly with a
slight amount of drag.
3. Repeat the drag tests and adjust as needed to achieve acceptable
Separator
Adjustment
clearance.
Knob
4
