- Page 1 TORQUE 2 + i3 QUICK RELEASE CONTROL SYSTEM USER MANUAL ISO 21853:2020 Certifi ed...
-
Page 2: Table Of Contents
RELEASES & AGREEMENTS..................3 WARNING & SAFETY PRECAUTIONS ..............4 -5 CONTROL SYSTEM OVERVIEW Torque 2 + i3 55 & Torque 2 + i3 50 Control System............6 LINE CONNECTIONS Attaching Flying Lines to a 4-line Kite ................7 Attaching Fool Proof Connectors ................... 8 Changing from 24 m to 22 m ..................... -
Page 3: Releases & Agreements
To waive any and all claims that you have or may have in the future against Naish International, a division of Nalu Kai Incorporated, or any of its agents, resulting from use of this product and any of its components. -
Page 4: Warning & Safety Precautions
WARNING & SAFETY PRECAUTIONS Kiteboarding is a dangerous sport. Always use extreme caution when using this product. • Misuse of this product can cause serious injury or death. • Never use this product unless you are in good physical health and you are an experienced swimmer. •... - Page 5 WARNING & SAFETY PRECAUTIONS FLYING LINES Never touch the flying lines when this product is in use. Flying lines are extremely dangerous while • under tension and can cause serious injury or death. Never allow yourself or anyone else to go between the control system and the kite when the kite is •...
-
Page 6: Control System Overview
CONTROL SYSTEM OVERVIEW TORQUE 2 + i3 55 & TORQUE 2 + i3 50 CONTROL SYSTEM A) Control System Bar B) Floaters C) Bar Ends D) Leader Lines (Red/Blue) E) Flying Line Adjuster F) Kite Leash G) Kite Leash Attachment Ring... -
Page 7: Line Connections
WARNING: Naish flying lines and bridles feature foolproof connectors to reduce the risk of incorrect connection between front and steering (rear) line connection points. Be sure to always use authentic Naish flying lines and bridles when using Naish kites and control systems. Front Front... -
Page 8: Attaching Foolproof Connectors
LINE CONNECTIONS ATTACHING FOOLPROOF CONNECTORS To create a lark's head loop, fold the loop Insert the knotted end of the other line over and pull the line through the loop as through the lark's head loop as shown. shown. Pull the lines tight to secure the connection as shown. -
Page 9: Torque 2 + I3 Control System
(rear) fl ying lines. Knot A: Decreases the length of the steering (rear) ying lines. Knot B: Naish control systems are delivered in the Knot B position. Knot C: Increases the length of the steering (rear) ying lines. - Page 10 TORQUE 2 + i3 CONTROL SYSYEM ADJUSTING TORQUE 2 STEERING (REAR) FLYING LINES (CONTINUED) Pull the knot out of the Locking Cavity (1). Adjust the leader line to the desired knot using the Adjusting Cavity (3). Lock the desired knot securely in position using the Feed the end of the leader line back through the Locking Cavity (1).
-
Page 11: Operating The Chicken Finger
TORQUE 2 + i3 CONTROL SYSYEM OPERATING THE CHICKEN FINGER The chicken finger is designed to hold the i3 Quick Release loop in position in the harness hook. WARNING: To release yourself from the kite in an emergency situation, you must activate the i3 QR when the chicken fi nger is installed. -
Page 12: Operating The I3 Quick Release
OPERATING THE i3 QUICK RELEASE To release yourself from the kite in an emergency situation, you must activate the i3 Quick Release. WARNING: Always use a kite leash when using a Naish Control System. Grab the red release slide and push the slide away from your body. -
Page 13: Operating The Torque 2 Trim Cleat
TORQUE 2 + i3 CONTROL SYSYEM OPERATING THE TORQUE 2 TRIM CLEAT To depower the kite: 1) Pull the trim line towards your body to depower the kite. 2) Lock the trim line back in the trim cleat at the desired position. -
Page 14: Kite Leash
KITE LEASH ATTACHING THE KITE LEASH All Naish Control Systems are delivered with a kite leash. When activating the i3 Quick Release (page 13) in an emergency situation, the kite leash will keep the rider attached to the kite while the kite depowers. -
Page 15: Operating The Kite Leash Quick Release
KITE LEASH OPERATING THE KITE LEASH QUICK RELEASE WARNING: To completely free yourself from the kite in an emergency situation: A) Activate the i3 Quick Release loop (page 13). B) Then activate the kite leash quick release: 1) Grab the quick release handle and push it away from your body as shown. 2) Immediately let go of the quick release handle so you are completely free from the kite. -
Page 16: Maintenance
MAINTENANCE AND SERVICE WARNING: It is necessary to rinse your bar and release mechanism after every use. TRIM CLEAT Make sure to remove the trim line from the cleat. • Thoroughly rinse the cleat to remove salt and sand after each session. •... -
Page 17: Warranty Policy
If a product is deemed to be defective by Naish, the warranty covers the repair or replacement of the defective product only. Naish will not be responsible for any costs, losses or damages incurred as a result of loss of use of this product. - Page 18 Naish.com © 2021 Naish International, a division of Nalu Kai Incorporated PO Box 703 Haiku, Hi 96708...
