Needle path detector
SK3
User's manual
WARNING! Prototype versions bear no indication of SW version.
This manual applies to program versions 1.2 and higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for bianco SK3

  • Page 1 Needle path detector User’s manual WARNING! Prototype versions bear no indication of SW version. This manual applies to program versions 1.2 and higher...

  • Page 2: Table Of Contents

    Images illustrating the completion kit installation procedure:..........10 Installing an SK3 kit: ........................12 Images illustrating the installation procedure of an SK3 kit:........... 13 Calibration and alignment of the projector with the microcamera: ......... 14 Calibration by means of an oscilloscope:..................14 Calibration by means of VDTEX SW:..................

  • Page 3: Foreword

    Hw ad hoc: In the design of the SK3 detector, we started out by considering the objectives to be reached, without setting for ourselves any time or cost limitations. Only after defining the characteristics of each individual part, a market survey got underway to assess actual feasibility.

  • Page 4: Set-Ups And Configurations

    Page 4 of 46 SET-UPS AND CONFIGURATIONS POSSIBLE CONFIGURATIONS: Depending on type of installation, the SK3 needle path detector is available in two different • configurations. Each configuration can be supplemented by a “completion kit”, selected from a choice of versions •...

  • Page 5: Schematic View Of Photodetector Fitted To Basket

    SK3 NEEDLE PATH DETECTOR Page 5 of 46 Schematic view of photodetector fitted to basket: S. Microcamera support P. Infrared projector for transparency lighting M. Microcamera con C. Stecche C. Basket rods proiettore IR per cesto illuminazione in riflessione V. Basket U.

  • Page 6: Installation

    SK3 NEEDLE PATH DETECTOR Page 6 of 46 INSTALLATION: Completion kits are necessary when you wish to install an SK3 needle patch detector. Depending on type of installation, it is necessary to choose the most appropriate completion kit. The mounting procedures for the SK3 described below use the various kits available.

  • Page 7: Images Illustrating The De-Installation Procedure

    SK3 NEEDLE PATH DETECTOR Page 7 of 46 Images illustrating the de-installation procedure: 1)Disconnect the cables from the box fitted to the basket 2)Disconnect the limit switch and remove it 3) Remove the electronics box 4) Remove the box supporting plate...
  • Page 8 SK3 NEEDLE PATH DETECTOR Page 8 of 46 Remove bracket+photodetector support 8) Remove motor assembly 9) Remove bracket supporting motor/projector 10) Remove U bracket...

  • Page 9: Fitting The Completion Kit Ee5900010226

    8. 11. For an upgrade with SK3 box version, fit back the box supporting bracket. The mechanical parts now are ready for the installation of the SK3 upgrade kit...

  • Page 10: Images Illustrating The Completion Kit Installation Procedure

    SK3 NEEDLE PATH DETECTOR Page 10 of 46 Images illustrating the completion kit installation procedure: Install the U bracket towards the handwheel 2) Fit back the projector/motor supporting bracket 3) Insert the new photodetector mechanical parts 4) Replace the blade guard with the new guard supplied...
  • Page 11 SK3 NEEDLE PATH DETECTOR Page 11 of 46 7) Adjust the photodetector support at a distance of 10mm from the base 8) and the motor assembly at a distance of 60 mm from the support 9) Adjust the photodetector at a distance of a few mm from the basket and 10) Make sure that the rods do not...

  • Page 12: Installing An Sk3 Kit

    • 8 and 13 mm wrenches Procedure: 1. Insert wire of the SK3 photodetector + the limit switch wire in the tube connecting the photodetector mechanical parts with the rest of the machine. 2. Insert the limit switch wire into the connection box fastened to the bracket using the PG located in the portion facing the basket opening handwheel.

  • Page 13: Images Illustrating The Installation Procedure Of An Sk3 Kit

    SK3 NEEDLE PATH DETECTOR Page 13 of 46 Images illustrating the installation procedure of an SK3 kit: 1) Insert the photodetector+limit switch wires into the ad hoc tube 2) Connect the limit switch to the wire from the electric panel by means of the ad hoc box...

  • Page 14: Calibration And Alignment Of The Projector With The Microcamera

    SK3 NEEDLE PATH DETECTOR Page 14 of 46 Calibration and alignment of the projector with the microcamera: This process is indispensable for correct system operation, it must be performed in the event of first installation and must be checked and, if necessary, repeated in the event of malfunctioning (e.g.
  • Page 15 SK3 NEEDLE PATH DETECTOR Page 15 of 46 RE: Calibrating the TGL SK3 by means of an oscilloscope. 1) Turn off the machine 2) Set switch SW2-1 on “ON” 3) Connect probe no. 1 (CH1) to board C352 terminal M5-5, connect 0V (potential) of probe no.1 to TP1 on board C318.
  • Page 16 SK3 NEEDLE PATH DETECTOR Page 16 of 46 6) zoom ... Direct light signal Reflex signal 7) zoom in further ... Direct light signal Needle path Adjust the camera up/down, left/right to obtain... A) The analog signal from the camera will be similar to the previous image.
  • Page 17 SK3 NEEDLE PATH DETECTOR Page 17 of 46 ... now on the right ..now on the left ... 9) Check the level of the direct line signal (without any obstacles between the camera and the direct light projector); in the next image you can see the signal reaching the highest level, ca +10Vdc.

  • Page 18: Calibration By Means Of Vdtex Sw

    SK3 NEEDLE PATH DETECTOR Page 18 of 46 9) If you obscure the signal by interposing an obstacle between the camera and the projector you will see the signal drop to ca –10Vdc. Obstacle Signal dropped to the minimum level...
  • Page 19 SK3 NEEDLE PATH DETECTOR Page 19 of 46 Procedure: • On C352 board: open, if closed, selector S7 (two-way selector, leave both ways free). If S7 was closed previously, memorise point of connection to be able to reset it later.
  • Page 20 SK3 NEEDLE PATH DETECTOR Page 20 of 46 Images of VDTEX screens described in previous procedure: Trasparence signal:The signal Trasparence Trasparence should appear as flat as possible,the light centre part which is highest on average reference position around the centre.
  • Page 21 SK3 NEEDLE PATH DETECTOR Page 21 of 46 Calibration by means of tester: This is perhaps the simplest method, but the correctness of the calibration of the calibration process completed will not be determined with the same level of confidence.

  • Page 22: Upgrading The Software

    Viale industria, 4 12051 ALBA(CN) Specify the BIANCO part number of the machine on which the photodetector is installed or at least the SW version installed on the latter (the SW version is read on a label glued to board C318).
  • Page 23 SK3 NEEDLE PATH DETECTOR Page 23 of 46 2) Follow the instructions that appear on the screen, until the end of the installation procedure 3) After the installation, an icon called “flash” appears on the desktop: use it to run the program.
  • Page 24 SK3 NEEDLE PATH DETECTOR Page 24 of 46 Download software program installation procedure 1. Execute file stfl22.zip 2. The following Winzip screen appears, click “I Agree”...
  • Page 25 SK3 NEEDLE PATH DETECTOR Page 25 of 46 3. Then the following window appears: 4. Click the “EXTRACT” button to view the following window: 5. Tick “All files” and “Use folder names”, click EXTRACT...
  • Page 26 SK3 NEEDLE PATH DETECTOR Page 26 of 46 6. The files and directories (see image) are stored in the chosen directory: 7. Select “Disk1” and launch “Setup.exe”. 8. The following image appears, click “Next” 9. Answer Yes to the question and click the “Finish” button that appears.
  • Page 27 SK3 NEEDLE PATH DETECTOR Page 27 of 46 10. Launch “Setup.exe”, the following screen appears. This screen will probably appear the first time you launch the program, if so, follow the instructions displayed. 11. Click “Next”. At the end of the installation process, the following window appears:...
  • Page 28 5. Launch “ST10 Flasher 2.02” from the “Start -> programs” menu of your PC. 6. If the electronic board of the SK3 has been properly connected to the serial port of your PC with the upgrade cable, you will see the following screen: NOTE1: You can change the parameters of the serial communication line using the “Set Port”...
  • Page 29 SK3 NEEDLE PATH DETECTOR Page 29 of 46 7. Click “File to program”, select the SW file that you want to download and press “OK” 8. Click “Program and Verify”, “*PROGRAM FLASH MEMORY” is displayed. When “*PROGRAM FLASH MEMORY appears, the new SW has been -->OK”...

  • Page 30: Indicators And Controls

    SK3 NEEDLE PATH DETECTOR Page 30 of 46 INDICATORS AND CONTROLS: The user is provided with a certain number of indicators and controls for the use and control of the SK3 photodetector. Some of these devices are optional and are mounted only for some special applications.
  • Page 31 SK3 NEEDLE PATH DETECTOR Page 31 of 46 Automatic mode telltale: • Gives out fixed light when system is in automatic mode, whether or not enable signal is present. • Flashes at ½ sec. intervals if fabric legibility is close to or lower than threshold set by means of alarm sensitivity trimmer.

  • Page 32: Using The Equipment

    USING THE EQUIPMENT: We describe below the optimal utilisation method for the SK3 needle path detector. 1) When the machine is powered and started, the operating mode is manual. 2) The operator performs the drawing-in process and places the fabric in front of the microcamera.
  • Page 33 SK3 NEEDLE PATH DETECTOR Page 33 of 46 14) In the event of the line being stopped by a reason other than an alarm condition, for instance when it is stopped by the operator, the automatic mode is maintained, and will be effective again as soon as the line is restarted.

  • Page 34: Electronic Control Units

    SK3 NEEDLE PATH DETECTOR Page 34 of 46 ELECTRONIC CONTROL UNITS The electronic control units can be located in a stainless steel box on board the machine, near the sensor, or be housed in an electric panel of the line.
  • Page 35 SK3 NEEDLE PATH DETECTOR Page 35 of 46 Board C352 (board C318 is mounted on C352 and board C336 is mounted on C318) Board C336 (mounted on C318) Board C318 (mounted on C352)

  • Page 36: Protective Fuses

    SK3 NEEDLE PATH DETECTOR Page 36 of 46 We provide below a description of the main LED’s, fuses, switches, test points and terminal strips present on these boards, in order to be able to identify the causes of possible problems and to remedy them.
  • Page 37 SK3 NEEDLE PATH DETECTOR Page 37 of 46 LD9 led 3mm Luminosity proportional to reference given to transparency projector (OFF green if ref =0) LD10 led 3mm Monitors status of alarm output static relay (ON if relay is closed = ALARM)

  • Page 38: Setting Switches And Jumpers

    SK3 NEEDLE PATH DETECTOR Page 38 of 46 1.÷F. = system errors, contact the technical service = prototype SW version LED’s on board C354 LD1 led 3mm Monitors motor start external enable status (OFF is motor is enabled) yellow LD2 led 3mm...
  • Page 39 SK3 NEEDLE PATH DETECTOR Page 39 of 46 S6 2-pos selector Selects serial electric protocol C: pos1 = RS422 pos2= RS485 Default = pos 1 S7 2-pos selector Selects serial electric protocol A: pos1 = RS422 pos2= RS485 Default = open...
  • Page 40 SK3 NEEDLE PATH DETECTOR Page 40 of 46 Board operating mode – Default = OFF OFF SW2-7 Normal mode HW test, digital part Calibration of the lenses HW test, analog part Selects analog input voltage range from photodetector – Default OFF OFF ON ON...

  • Page 41: Test Points

    SK3 NEEDLE PATH DETECTOR Page 41 of 46 Switches on board C354 B1 weld-on Closed = disables / Open = enables power outputs of board C352 and jumper projectors Default = OPEN B2 weld-on Factory setting = open jumper B3 jumper N.O.

  • Page 42: Terminal Strips

    SK3 NEEDLE PATH DETECTOR Page 42 of 46 Test points on board C354 TP1,2 0V power 0V motor Terminal strips Terminal strips on board C352 M1 3.5mm 6-way Field bus (CAN Bus) M1-1 +5 V external power supply of optoisolators (in the case of optoisolated...
  • Page 43 SK3 NEEDLE PATH DETECTOR Page 43 of 46 M3-8 Common for lamps M3-9 Negative for optoisolated output no.4 (NOT USED) M3-10 Positive for optoisolated output no.4 (NOT USED) M3-11 Negative for optoisolated output no.3 (NOT USED) M3-12 Positive for optoisolated output no.3 (NOT USED)
  • Page 44 SK3 NEEDLE PATH DETECTOR Page 44 of 46 M5-14 M5-15 GROUND (for screen connection) M5-16/17 Microcamera analog signal differential input +/- line M5-18 GROUND (for screen connection) M5-19/20 Auxiliary sensor analog signal differential input +/- line (NOT USED) Digital inputs and serial lines M6 3.5mm 20-...

  • Page 45: Diagnostics

    Cause Remedy After the SW update, the Jumper B1 left closed on Open B1 TGL SK3 seems to work but C354 board the basket will not move. The TGL SK3 no longer 1. Mechanical parts out of Follow procedure to realign...

  • Page 46: Technical Data

    SK3 NEEDLE PATH DETECTOR Page 46 of 46 TECHNICAL DATA U.o.m Typ Max. Notes. Electrical characteristics Voltage 21.5 26.5 Box version x 110 50/60 Panel version x 220 x 380 Power input Operating temperature °C ------- +60 Storage temperature Humidity -...
  • Page 47 Annex I...
  • Page 48 Trimmer P1 --------------------------------------------------------------------------------------------------------------- 2) Please check and inform our service department software version installed on SK3 control group. To check the software version it should be turned off and on again the unit, the first 2 numbers that appear on the red display of the board C336 identify the version of software: example “3.”...
  • Page 49 3) Report the serial number of the machine and / or serial number of the device and if possible the year of installation. Report and other information that would help in solving the problem, such as the fact that we are working on a sensor or installed as an upgrade on an existing line.
  • Page 50 4) Check the wiring between the card C352 and the card C354, between the card C352/C354 and the sensor SK3. Also check any wiring interconnection with the rest of the line: the enables, commands, buttons, lamps. (follow the wiring diagram of the...
  • Page 51 6) Check the voltage of the auxiliary board C352: - Verify that there is a negative voltage between -9.5 and -12.0 Vdc between M5.3 (-) and M5.2 (0V) - Verify that there is a positive voltage of 5.0Vdc between TP2 (+) and TP1 (0V) --------------------------------------------------------------------------------------------------------------------...
  • Page 52 7)Check the correct AUTO e MAN lamps functioning. If the lights are powered directly through the card C352, bridge B1 must be closed .If they are powered from external, B1 should remain open otherwise can damaged the operation of the card, up to total failure.
  • Page 53 This LED turns off for a moment in time when the alarm light comes on. 14) Now perform the calibration of the positioning of the sensor and transmitter SK3 in order to ensure the reading of the deviation of the needle in the AUTO mode.
  • Page 54 You need to have special connection cable between C336 e il PC supplied with the bianco’s unit.(flat cable with 10 terminals). If the PC doesn’t have a serial port RS232 available you must have a coverter adapter RS232-USB (not supplied...
  • Page 55 To calibrate the sensor SK3, you must move the camera vertically to get the blue line (transparency) as flat as possible, or with the two ends slightly lower, as seen in photos. BEST SIGNAL OBTAINED AFTER CALIBRATION INSERT A SCREWDRIVER BETWEEN THE CAMERA AND THE PROJECTOR AND CHECK THAT THE LINES T (TRANSPARENCY) AND R (REFLEX) FOLLOW THE FAKE SLITTING LINE.
  • Page 56 CENTRE SLITTING LINE RIGHT SLITTING LINE LEFT SLITTING LINE Once you reach the optimal position, firmly tighten the screws loosened to move the camera. And WE recommended,( with a permanent marker), to make marks on the supporting arm at the setting position so if the camera is removed for any maintenance, you can reassemble without repeating the steps of calibration.
  • Page 57 15) Insert a fabric with slitting line to start the machine, select the reading mode in TRANSPARENCY ("0." On the display card's C336), adjust the alarm threshold, enter the AUTO mode and see that the basket rotates to bring the deviation of the missing needle in the center.
