AUTOTECH CRI205 Manual

CRI205 High pressure common rail injector tester user manual
Support electromagnetic and piezoelectric injectors (BOSCH, DENSO, DELPHI, SIEMENS,

PIZEO,CUMMINS , CAT-L, CAT-H);
Over current and short circuit protection function;

Impedance measurement of injector;

Onboard temperature sensor, which can play a role of overheating protection;

The function of accumulating user usage times;

The startup LOGO can be customized;

The interface, operation mode, appearance of the chassis, etc. can be customized according to

customer needs;
Support AHE measurement

1 Accessories and Interface Description

1.1 Check the accessories

The function of the CRI205 high pressure common rail injector tester is to drive common rail
injectors and injector AHE function tests. It also provides control signals for common rail injectors such
CRI205 HIGH PRESSURE COMMON RAIL
INJECTOR TESTER
V1.0
