Explanation of icons

Symbol Description
Indicates technical aspects which the u-
ser must observe.
Switch off machine
Switch on machine
Incorrect / Invalid
Correct / Valid
Input
Navigation
Output
Time representation (e.g.: wait 4 s / ac-
tuate)
Interruption in the menu display (other
setting options possible)
Tool not required/do not use
Tool required/use
099-008268-EW501
21.02.2022
Symbol Description
Activate and release / Tap / Tip
Release
Press and hold
Switch
Turn
Numerical value – adjustable
Signal light lights up in green
Signal light flashes green
Signal light lights up in red
Signal light flashes red
