MS|3000

User Manual / Warranty

Table of Contents

Summary of Contents for Buvan Majestic MS 3000

Page 1 MS|3000 User Manual / Warranty...
Page 2: Table Of Contents
Table of Contents Preface Product Performance Safety Instructions Usage and Operation Battery and Charger Electrical Schematic Diagram Controller Maintenance Tech Support Warranty Detail video explanation for Usage and Operations and Remote Pairing please visit our Youtube Channel. Detail information on page 9th. For all your spare parts need, please visit www.ComfyGoMobility.com Don't forget the register your product, detail information on page...
Page 3: Preface
Preface - This manual contains operations, assembly methods, and simple faults solutions. The manual applies to our model: MS|3000 - This manual contains both scooter maintenance tips and trouble- shooting methods so please store it where you can access as re- quired.
Page 4: Product Performance
1. Product Performance - This series of electric scooters are powered by Li-ion batteries and use DC motors. Users can control direction and adjust speed by using the controls located on the arm. This scooter can be used at low speeds, good road conditions and will handle low slope.
Page 5 1. Product Performance Application Range This electric scooter is engineered specifically to serve people weigh- ing less than 100 (220 lbs.). Please do not use this unit on motorways.
Page 6: Safety Instructions
2. Safety Instructions 2.1 Main Security Features - Classified based on the type of protection: Against electric shock, Internal power. - Classified based on the type of protection: Against electric shock, Type B ap- plication. - Classified based on the degree of inlet liquid protection: IPX - Classified based on the safe of use in a flammable anesthetic mixture with air or gas mixed with oxygen or nitrous oxide flammable anesthetic gases occurs: Non-AP/APG type.
Page 7 2. Safety Instructions - Please take effective safety measures before driving MS|3000. You must wear safety helmets and other protective gear. Be vigilant during driving and maintain a reasonable safety distance with pedestrians and other vehicles. - Do not lend the MS|3000 to someone who does not operate it to avoid injury. Please be responsible for the safety of your friends.
Page 8 2. Safety Instructions 2.3 Other Important Notices Repair and Refit - If your wheelchair requires repair or a refit, please contact your seller or ser- vice department. Do not attempt to modify your wheelchair by yourself as this may cause accident or wheelchair malfunction. - Do not add weight, other than approved accessories to this chair, as this may cause an imbalance and impact vehicle function.
Page 9 2. Safety Instructions 2.7 Prohibited Actions - It is forbidden to use the laws of the country/region and the relevant adminis- trative units to prohibit the use of such vehicles area us this vehicle. - It is forbidden to drive horizontally on the slope. - It is forbidden to exceed the safety warning line of each telescopic part of MS|3000.
Page 10: Usage And Operation
3. Usage and Operation Please visit YouTube for detailed Usage and Operations explanation. Simply search "ComfyGo MS|3000 Electric Scooter - Foldable Mo- bility Scooters" on YouTube or scan the QR code with your smart- phone's camera. www.youtube.com/c/ComfyGoMobility...
Page 11 3. Usage and Operation 3.1 Learning to Drive - Practice in a safe and empty place until you can get on the bus safely and comfortably, skillfully controlling, steering, parking, and get- ting off. Do not drive the MS|3000 out to complex driving conditions and road conditions before you are skilled.
Page 12 3. Usage and Operation 3.1 Folding and unfolding steps Folding - The MS|3000 is parked in a flat position, and the large red sphere on the right side is pulled up to fold successfully. Picture (1, 2, 3) - After folding, you can pull the MS|3000 direction bar to drag. If you need to put it into the car or transport it, you can open the directional bar quick release handle and rotate the loose nut to adjust to the lowest height.
Page 13 3. Usage and Operation 3.2 Direction bar and child seat adjustment Adjust the freight of the direction bar - First, open the quick release handle and rotate the loose nut. Adjust the direction lever to the appropriate height according to your height. After the adjustment is completed, tighten the nut and lock the quick release handle.
Page 14 3. Usage and Operation...
Page 15: Battery And Charger
4. Battery and Charger 4.1 Charger Requirements The charger should only be used for charging the batteries. Do not use your scooter while it is charging. Charger Technical Data Input voltage: AC220V (110V) ±10% Output voltage: 36V/DC Output current: 1.5~5A Ingress protection level: IPX1 Meets requirement: GB 4706.1-2005 and GB 4706.18-2005...
Page 16 4. Battery and Charger - The charging port is under the left pedal of the MS|3000 body, and the charging port cover is opened and the charging interface is dry. (Picture 13) - Please insert the positioning groove of the charging port of the char- ger at the charging port of the car body first, and then connect the charger plug to the ac power socket.
Page 17 4. Battery and Charger 4.3 Battery Use and Maintenance - Incorrect insertion of the battery may cause danger of explosion. Only use batteries that are provided with this unit. Visit www.ComfyGoMobility.com or contact with us via support@ComfyGoMobility.com if you need replacement batteries. - While inserting the battery, ensure that the battery poles are placed correctly.
Page 18: Electrical Schematic Diagram
5. Electrical Schematic Diagram Motor 2 Controller 2 Throttle Hall Current Sensor Charging Port Breake Lever Power Supply Reversing - Third Gear Electric Lock with headlights on Controller 1 Breake Light Motor 1 Horn...
Page 19: Controller
6. Controller - LCD instrument assembly, lock, LED headlights and power display. Insert the key clockwise to turn on the power switch once, otherwise, turn off the power switch, turn clockwise twice to turn on the LED headlights. - Horn switch, press the horn button to sound, to remind the passing pedestrians and vehicles, to avoid some unnecessary traffic acci- dents.
Page 20 6. Function Controller Break...
Page 21 6. Controller...
Page 22: Maintenance
7. Maintenance - Do not place the MS|3000 at temperatures above 40 °C or in low temperatures below -20 °C (for example, do not place this product or its battery pack in a car exposed to summer exposure). Do not put the battery pack into fire.
Page 23 7. Maintenance Non-professionals are forbidden to disassemble the battery pack at will, otherwise serious safety accidents may result from electric shock or short circuit! At the same time, the battery pack cannot be removed at will. If you need to replace the battery, please contact our company or local distributor, we will provide you with quality professional services.
Page 24: Tech Support
8. Tech Support Please visit https://www.comfygomobility.com/product-registration/ and register your product now. When you register your ComfyGo Electric Wheelchair, you ensure that you may be eligible for an extended warranty service. You will also receive product updates and important news from Comfy Go Mobilities.
Page 25 9.Warranty Policy - Our goal is to ensure you are delighted with your purchase. - According to our warranty agreement, All new products have a limit- ed warranty. All batteries have a six month warranty. Spare parts have a one year warranty. The limited warranty does not include: labor or device failure due to owner misuse or negligence, non-durable com- ponents and components subject to normal wear and need replace- ment from time to time (for example rubber materials, accessories,...
Page 26: Www.comfygomobility.com
makes life easier www.ComfyGoMobility.com...
