- Page 1 MIDI Pronomic SA-15 SUB/SA-18 SUB 00057895/ 00057897 Active Subwoofer MIDI Manual Version 04/2019...
- Page 2 PRECAUTIONS Please read carefully before proceeding Warning: Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from: electrical shock, short-circuiting, damages, fire or other hazards. These precautions in- clude, but are not limited to, the following: Power supply / power cord (devices with power cords/power supplies): •...
- Page 3 • Do not use the device or headphones for a long period of time at a high or uncomfortable vol- ume level, since this can cause permanent hearing loss. If you experience any hearing loss or ring- ing in the ears, consult a physician. •...
- Page 4 Control Panel 1 Phase switch This switch reverses the polarity of the sub- woofer. 2 Crossover switch This switch activates the high pass filter for the outputs. 3 POWER LED SIGNAL LED LIMIT LED 4 Line level controll Rotary level control: Attenuates the level of the signal sent to the subwoofer speaker.
- Page 5 Examples of Use Fullrange Configuration High Pass Crossover Configuration...
- Page 6 Technical Specifications MODEL SA-15 SUB SA-18 SUB Vented Box Subwoofer System Type Vented Box Subwoofer 15“ 18“ LF CONE 2“ VC 2,5“ VC LF VOICE COIL LINE INPUT 2 x XLR-F IN 2 x XLR-F IN LINE OUTPUT 2 x XLR-M OUT...
- Page 7 WEEE Declaration Your product is designed and manufactured with materials and components of high quality, which are recyclable and can be reused. The symbol means that your product should be disposed of separately from household waste when it reaches its end of life.
