BELL LABS INNOVATIONS Lucent Technologies DEFINITY 8410 Quick Reference

Enterprise communications server, voice terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
®
DEFINITY
Enterprise Communications Server (ECS)
Release 5
8410 Voice Terminal
Quick Reference
555-230-764
Comcode 107672974
Refer to the procedures on this card to use the
features on your 8410 voice terminal. The features
here are listed in alphabetical order. In the spaces
provided, write the feature access codes for your
system. For more information about any of these
features, see your system manager or refer to the
®
DEFINITY
Enterprise Server (ECS), Release 5
8410 Voice Terminal User's Guide , 555-230-763.
USING THE SOFTKEYS
If your 8410 has a display, you may be able to access
up to 12 features with the softkeys. You can activate
available softkey features by pressing
the softkey below the feature abbreviation. If the
feature you want to use is not on the bottom line of the
display, press
Next
feature you wish to access. When the feature is active,
an arrow appears above the feature. (However, if the
feature requires you to dial a telephone number or
extension, such as Call Forwarding, you will
temporarily see the digits you are dialing, rather than
the arrow, above the feature name.)
ABBREVIATED DIALING (AD)
To program/reprogram an AD button
1 Pick up handset.
NOTE: For speakerphone users, press a call
appearance button or press
2 Press softkey below Prog (for display users)
or Press
Program
or Dial AD Program access code _________.
3 Press AD button to be programmed.
and then
Menu
or
until you see the
Prev
.
Speaker
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lucent Technologies DEFINITY 8410 and is the answer not in the manual?

Questions and answers

Summary of Contents for BELL LABS INNOVATIONS Lucent Technologies DEFINITY 8410

  • Page 1 All manuals and user guides at all-guides.com ® DEFINITY Enterprise Communications Server (ECS) Release 5 8410 Voice Terminal Quick Reference 555-230-764 Comcode 107672974 Refer to the procedures on this card to use the features on your 8410 voice terminal. The features here are listed in alphabetical order.
  • Page 2 All manuals and user guides at all-guides.com 4 Dial outside number, extension, or feature access code you want to store (up to 24 digits). 5 Press 6 Repeat Steps 3 through 5 to program additional buttons. 7 Hang up. To place an AD call 1 Pick up handset or press Speaker 2 Press selected AD button.

  • Page 3: Automatic Callback

    All manuals and user guides at all-guides.com AUTOMATIC CALLBACK AUTOMATIC CALLBACK AAUTOMATIUTOMATIC CALLBACK To automatically place another call to an extension that was busy or did not answer 1 During call attempt, press softkey below AutCB (for display users) or Press AutoCallBk 2 Hang up.

  • Page 4: Call Forwarding All Calls

    All manuals and user guides at all-guides.com CALL FORWARDING ALL CALLS To temporarily redirect all calls to an extension or outside number 1 Press softkey below CFrwd (for display users) or Press Call Fwd or Dial Call Forward access code _______. 2 Dial extension or number where calls will be sent.
  • Page 5 All manuals and user guides at all-guides.com CONFERENCE To add another party to a call (for a total of up to 6 parties) 1 Press Conf 2 Dial number of new party and wait for answer. 3 Press again. Conf 4 Repeat Steps 1 through 3 for additional conference connections.

  • Page 6: Last Number Dialed

    All manuals and user guides at all-guides.com HOLD To put a call on hold 1 Press Hold To answer a new call while active on another 1 Press Hold 2 Press call appearance of incoming call. To return to held call 1 Press call appearance of held call.

  • Page 7: Reset Speakerphone

    All manuals and user guides at all-guides.com RESET SPEAKERPHONE NOTE: You can use this feature only if the Reset Spkr label appears under the button. Speaker To adjust the speakerphone to the surrounding room acoustics 1 While on-hook, press Shift and then press Speaker •...

  • Page 8: Send All Calls

    All manuals and user guides at all-guides.com SEND ALL CALLS To send all calls (except priority calls) to coverage 1 While on-hook, press softkey below SAC (for display users) or Press Send Calls or Dial Send All Calls access code _______. To cancel Send All Calls 1 While on-hook, press softkey below SAC (for display users)
  • Page 9 All manuals and user guides at all-guides.com To end a speakerphone call 1 Press again to hang up. Speaker NOTE: With a DEFINITY G3V3 or later, if the person you are talking with hangs up first, the call will be disconnected.
  • Page 10 All manuals and user guides at all-guides.com TIMER (display feature) To see elapsed time 1 To start timer, press Menu and the softkey below Timer (for display users) or Press Timer 2 To stop timer, press and the softkey Menu below Timer or Press again.
