- Page 1 XPM170Y ChoisTechnology IMAGE POINTER New Concept Wireless Presenter ChoisTechnology IMAGE POINTER XPM170Y...
-
Page 2: Table Of Contents
XPM170Y ChoisTechnology IMAGE POINTER Table of Contents 1. Components ………………………………………………………. 2. Installation ………………………………………………………..3. Button Function ………………………………………………… 4. LED status light ………………………………………………..5. Powerpoint Use ………………………………………………..6. Explanation about ImagePointer mode ……………… 7. Battery replacement ………………………………………… 8. Installing and running the ImagePointer software …... -
Page 3: Components
XPM170Y ChoisTechnology IMAGE POINTER Components Transmitter Receiver Battery Manual... -
Page 4: Installation
XPM170Y ChoisTechnology IMAGE POINTER Product Installation ① ② ③ 수신기 수신기 송신기 1. After turning on the computer and inserting receiver into USB port, please wait until the LED on the receiver blinks at regular intervals. 2. When the receiver LED is blinking, the product is recognized. 3. -
Page 5: Button Function
XPM170Y ChoisTechnology IMAGE POINTER ImagePointer Button Function ① ① LED color change by status Shows wheter it is connected or whether button is working Shows whether battery is charging ② ③ (Blinks red for 5 seconds when battery is low) ②... -
Page 6: Led Status Light
XPM170Y ChoisTechnology IMAGE POINTER ImagePointer LED Status Light When touching or clicking the button GREEN LED on and flickering When the battery is less than 15% and the button is clicked RED LED blinks for 5 seconds During calibration GREEN LED blinks quickly for 2~3 seconds... -
Page 7: Powerpoint Use
XPM170Y ChoisTechnology IMAGE POINTER Use ImagePointer in PowerPoint 1. Run the PowerPoint presentation file and start the slideshow. 2. Present your presentation while moving the pages by using ②Back/④Touch buttons. 3. When you touch the ④Touch button, ①Green LED lights on and it performs air-mouse function. -
Page 8: Explanation About Imagepointer Mode
XPM170Y ChoisTechnology IMAGE POINTER Explanation of ImagePointer Mode Free Drawing function ImagePointer function : User can draw lines, figures : User can use an image as a and highlighter during the presentation mouse pointer. User can use a moving image(PNG,GIF) Highlight function Circle pointer function : User can point the part which... -
Page 9: Battery Replacement
XPM170Y ChoisTechnology IMAGE POINTER Battery Replacement 1. When the red LED lights up in the LED section, the battery needs to be replaced. 2. Open the rear case and put the two AAA batteries with the correct orientation. 3. When the battery exchange is complete, the green LED is turned on. -
Page 10: Installing And Running The Imagepointer Software
① After logging on to the website and signing up as a member, please download the program. (www.x-pointer.com -> Customer Support -> Download -> [XPM170Y]ImagePointer software download ② If you download and run the attachment in the post, the ImagePointer software will be installed and the program will run when you click the shortcut icon on the desktop. -
Page 11: Solutions
XPM170Y ChoisTechnology IMAGE POINTER Problem Shooting 1. When the mouse pointer moves automatically or continuously flows in a specific direction without moving the transmitter after connecting the receiver a) Please put the product down on the flat place like the desk or ground and Please press button ②&④... -
Page 12: Specification
XPM170Y ChoisTechnology IMAGE POINTER Specification Transmitter Frequency 2.4020~2.480GHz Number of channels 40 channel 65,536 Distance of use Max. 50m(Open Field) Antenna power less than 10mW Modulation system GFSK Operating time lkaline AAA Standard: Approx. 50 Consumption current Under 20mA Button 3 buttons, 1 touch Battery AAA x 2... - Page 13 XPM170Y ChoisTechnology IMAGE POINTER ImagePointer program specification ImagePointer Software *Private program Operating System Support Windows 7 & 10 macOS High Sierra & Mojahve ImagePointer Circle Highlight/Magnifier/Custom image Supports JPG, PNG, GIF, animation GIF, ICO, etc. PC screen enlargement Zoom Pointer Line drawing Official Supporting Program Apple Keynote...
-
Page 14: Cautions
XPM170Y ChoisTechnology IMAGE POINTER Cautions There is no compensation for accidents caused by misuse. - Please be sure to read the following information carefully. 1) Be careful not to let liquids such as water and drinks get into the product. 2) Do not expose to direct sunlight for a long time that causes discoloration. -
Page 15: Certification
According to the regulation of safety management for laser products, this product acquired KC Certificate( The National Representative Certification Mark) from Korea Testing Laboratory. 1. Product Name (Model No.): X-pointer(XPM170Y) 2. Certification Number: Transmitter : R-C-WCT-XPM170Y, Receiver : MSIP-REM-WCT-XPRAT2 3. Manufacturer: ChoisTechnologyCo., Ltd 4. -
Page 16: As & Warranty
XPM170Y ChoisTechnology IMAGE POINTER FCC Statement and Legal Notices This device complies with part 15 of the FCC Rules. Operation is su • bject to the following two conditions: (1) This device may not caus e harmful interference, and (2) this device must accept any interfer ence received, including interference that may cause undesired op eration. - Page 17 If there are some problems or something to improve while using the product, please contact us. We will consult about it kindly. E-mail : choistec@choistec.com TEL : +82 32-246-3409, FAX : +82 32-246-3406 Homepage : www.x-pointer.com Company Name : ChoisTechnology Co., Ltd.
- Page 18 XPM170Y ChoisTechnology IMAGE POINTER Warranty We warrant this product is manufactured by ChoisTechnology Co., Ltd. and any defect of the product caused by materials and mechanical problems will be covered for free for a year. If our model you purchased is found to be defective within that time, we will promptly repair or replace it.
