Woodhaven Micro Adjuster 3265 Assembly Instructions

Identify and verify that you have all the parts listed.
Read the instructions at least once, familiarizing yourself
with the parts before beginning. You'll need a #3 Phillips
screwdriver and a 7/16" wrench for assembly.
Part# Description
NUT015 Nut
Assemble the 4523 Micro Adjuster according
to the instructions that come with it. You will
not use the 1" stud, 10-24 nut, 10-24 set screw
or 3/32" allen wrench. It should look like the
image on the right when assembled. See fig. A
NUT015 x1
5772B x1
WL002 x1
Install the lock washer (WL002) on the
1" screw (5772B) and insert it thru the hole in
the short edge of the bracket (3265A). Install a
washer (WB002) and nut (NUT015) on the screw.
Screw the nut on until almost tight. See fig. B
Install a washer (WB002) on the 1/2"
screw (5770B), insert the screw thru the hole
in the long face of the bracket and start a
nut (NUT015) on the screw. See fig. B
Qty. Part# Description
2 WB002 Washer
B
NUT015 x1
3265A
5770B x1
WB002 x1
Micro Adjuster
Please Read Carefully!
Parts listed below are not shown in the hardware
drawings. Refer to photos in the instructions:
Part Description
4523 Micro Adjuster . . . . . . . . . . . . . . . . . . . . 1
Qty. Part# Description
2 5772B 1" Screw
4523

Assembly

3265

Parts List:

Quantity
Qty. Part#
1 WL002
A
Part#
5770B
C
Screw the knurled knob
of the Micro Adjuster on the
1" screw until it's about 1/16"
away from the nut. Assembly
is complete. See fig. C
Description Qty.
Lock Washer 1
Description Qty.
1/2" Screw 1
