CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . .1,2
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Step 1 - Check Jobsite . . . . . . . . . . . . . . . . . . . . . . . . 2
Step 2 - Check Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
• STORAGE
• PROTECTION
• INSPECT UNIT
Step 3 - Locate Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
• FIELD CONVERSION OF DISCHARGE AIR
Step 4 - Mount the Unit . . . . . . . . . . . . . . . . . . . . . . . . . 8
Step 5 - Check Duct System . . . . . . . . . . . . . . . . . . . . 8
• SOUND ATTENUATION
• EXISTING DUCT SYSTEM
Step 6 - Install Condensate Drain . . . . . . . . . . . . . . . 8
• HORIZONTAL UNITS
• VERTICAL UNITS
• VENTING
Step 7 - Pipe Connections . . . . . . . . . . . . . . . . . . . . . . 9
• GOUND LOOP APPLICATIONS
KIT
Step 8 - Wire Field Power Supply . . . . . . . . . . . . . . 10
• POWER CONNECTION
• 208-VOLT OPERATION
• 460-VOLT OPERATION
Step 9 - Wire Field Controls. . . . . . . . . . . . . . . . . . . . 22
• WATER FREEZE PROTECTION
• ACCESSORY CONNECTIONS
• WSHP OPEN WIRING
PRE-START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24,25
System Checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
PSC Blower Speed Selection . . . . . . . . . . . . . . . . . . 24
FIELD SELECTABLE INPUTS . . . . . . . . . . . . . . . .26,27
Complete C Control Jumper Settings. . . . . . . . . . . 26
Complete C Control DIP Switches. . . . . . . . . . . . . . 26
Deluxe D Control Jumper Settings . . . . . . . . . . . . . 26
Deluxe D Control DIP Switches . . . . . . . . . . . . . . . . 26
Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Water Valve (Slow Opening) . . . . . . . . . . . . . . . . . . . 27
Outside Air Damper (OAD) . . . . . . . . . . . . . . . . . . . . 27
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-33
Operating Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Scroll Compressor Rotation. . . . . . . . . . . . . . . . . . . . . 28
Unit Start-Up Cooling Mode . . . . . . . . . . . . . . . . . . . . . 28
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53500049-01
Compact High-Efficiency Water Source Heat Pumps
Installation, Start-Up, and
Service Instructions
Printed in U.S.A.
with PURON
Unit Start-Up Heating Mode . . . . . . . . . . . . . . . . . . . . . 31
Page
Unit Start-Up with WSHP Open Controls . . . . . . . . 31
Flow Regulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Flushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Antifreeze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Cooling Tower/Boiler Systems . . . . . . . . . . . . . . . . . . 33
OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33-37
Power Up Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Units with Aquazone Complete C Control . . . . . . . 33
Units with Aquazone Deluxe D Control . . . . . . . . . . 33
Units with WSHP Open Multiple Protocol. . . . . . . . 34
Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
WSHP Open Test Mode. . . . . . . . . . . . . . . . . . . . . . . . . . 37
Retry Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Aquazone Deluxe D Control LED Indicators . . . . . 37
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38-40
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Water Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Condensate Drain Pans . . . . . . . . . . . . . . . . . . . . . . . . . 38
Refrigerant System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Fan Motors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Condensate Drain Cleaning . . . . . . . . . . . . . . . . . . . 38
Air Coil Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Condenser Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Checking System Charge . . . . . . . . . . . . . . . . . . . . . 39
Refrigerant Charging . . . . . . . . . . . . . . . . . . . . . . . . . 39
Air Coil Fan Motor Removal . . . . . . . . . . . . . . . . . . . . . 39
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 40-42
Thermistor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Control Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
WSHP Open Controller . . . . . . . . . . . . . . . . . . . . . . . . . . 40
CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . 43-48
50PCH,PCV START-UP CHECKLIST . . . . . CL-1, CL-2
IMPORTANT: Read the entire instruction manual before
starting installation.
SAFETY CONSIDERATIONS
Installation and servicing of air-conditioning equipment can
be hazardous due to system pressure and electrical compo-
nents. Only trained and qualified service personnel should
install, repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance func-
tions of cleaning coils and filters and replacing filters. All other
operations should be performed by trained service personnel.
When working on air-conditioning equipment, observe
precautions in the literature, tags and labels attached to the unit,
and other safety precautions that may apply.
Form 50PC-1SI
AQUAZONE™
50PCH,PCV015-060
®
Refrigerant (R-410A)
